- Page 1 VX-TR Network Installation OctOber 20, 2015...
- Page 2 BLANK PAGE...
-
Page 3: Table Of Contents
Settings - electric Heat ....... 16 configuring the equipment Settings - reversing Valve ....17 configuring the energy Saving Settings ......... 18 Testing Thermostats ................ 19 Confirming Network Connectivity .............20 Troubleshooting ................21 Warranty ..................22 Technical Specifications ..............24 Verdant VX-tr Network Installation... - Page 4 BLANK PAGE...
-
Page 5: Whitelisting The Server
ON tHe SerVer WItH DHcP AND tHe AbILItY tO cONNect OUtWArD VIA tcP tO A reMOte MAcHINe. CONTACT THE PROPERTY SYSTEM ADMINISTRATOR TO WHITE LIST THE SERVER MAC ADDRESS FOR CONNECTING TO THE INTERNET. THE SERVER MAC ADDRESS IS PRINTED ON THE SERVER. Verdant VX-tr Network Installation... -
Page 6: Installing The Online Connection Kit
BEFORE YOU BEGIN DETERMINE THAT THE SERVER INSTALLATION LOCATION IS SUITABLE. INSTALL THE SERVER IN A ROOM ADJACENT TO ROOMS IN WHICH VERDANT THERMOSTATS WILL BE INSTALLED. THE MAXIMUM DISTANCE WILL VARY DEPENDING ON THE TYPE OF THE BUILDING CONSTRUCTION. -
Page 7: Connecting The Ethernet Cable
(UNINTERUPTED POWER SUPPLY) UNIT. LOGIN TO THE REMOTE MANAGEMENT WEBSITE TO CONFIRM THE SERVER IS CONNECTED TO THE INTERNET. IF THE SERVER IS NOT CONNECTED TO THE INTERNET, STOP THE INSTALLATION AND CONTACT VERDANT TECHNICAL SUPPORT. Verdant VX-tr Network Installation... -
Page 8: Installing Thermostats
THE ROOM. THERMOSTAT MUST NOT BE INSTALLED NEAR OR ON METAL STRUCTURES OR SURFACES INCLUDING METAL AIR DUCTING THAT MAY BE IN THE WALL. METAL STRUCTURES AND SURFACES SIGNIFICANTLY REDUCE THE RANGE OF THE WIRELESS SIGNAL. Verdant VX-tr Network Installation... -
Page 9: Programming The Thermostat With The Network Programmer
If the red light on the Network Programmer is blinking or is not steadily lit, the thermostat has not been programmed correctly. Unplug the Network Programmer connector from the thermostat and repeat the steps above. 4.3. Unplug the Network Programmer from the thermostat; Verdant VX-tr Network Installation... -
Page 10: Wiring The Thermostat
Fan High Green Fan High Purple Fan Low Purple Fan Low NOTE: If the PTAC unit has only one (1) fan speed, connect both fan control wires – Green and Purple – to the fan terminal (G). Verdant VX-tr Network Installation... -
Page 11: Mounting The Thermostat To The Wall
Use the supplied wall anchors and mounting screws to secure the thermostat to the wall; 6.3. Follow the “thermostat configuration” instructions to correctly configure the thermostat. 6.4. replace the thermostat cover and screw in the fixing screw; Verdant VX-tr Network Installation... -
Page 12: Configuring Thermostats
➤ NOTE: If the thermostat is connected to a network, the equipment and the energy saving settings configured on the thermostat will be ignored and the settings configured on the Remote Management Website will be applied. Verdant VX-tr Network Installation... -
Page 13: Setting The Thermostat Clock
Press the “Fan” button to set the minutes; ➤ Use the “Up” an “Down” buttons to set the minutes; ➤ Press the “F/c” button to advance to the next menu; ➤ SETTING THE CLOCK CORRECTLY IS CRUCIAL FOR PROPER OPERATION OF THE THERMOSTAT. Verdant VX-tr Network Installation... -
Page 14: Entering The Room Number
Use the “Up” and “Down” buttons to change the digit; ➤ Press the “Fan” button advance to the next digit; ➤ Press the “F/c” button to advance to the next menu; ➤ ENTERING THE ROOM NUMBER CORRECTLY IS CRUCIAL FOR PROPER OPERATION OF NETWORKED THERMOSTATS. Verdant VX-tr Network Installation... -
Page 15: Configuring The Equipment Settings - Compressor Type
COMPRESSOR TYPE Use the “Up” and “Down” buttons to change the compressor type by ➤ changing the first digit; No compressor Heat Pump Air conditioner Press the “Fan” button to advance to the next setting; ➤ Verdant VX-tr Network Installation... -
Page 16: Configuring The Equipment Settings - Electric Heat
ELECTRIC HEAT Use the “Up” and “Down” buttons to change the electric Heat ➤ setting by changing the second digit; No electric Heat electric Heat ➤ Press the “Fan” button to advance to the next setting; Verdant VX-tr Network Installation... -
Page 17: Configuring The Equipment Settings - Reversing Valve
Press the “Fan” button to advance to the next setting; ➤ Press the “F/c” button to advance to the next menu; ➤ Verdant VX-tr Network Installation... -
Page 18: Configuring The Energy Saving Settings
Use the “Up” and “Down” buttons to select one of energy Saving ➤ presets; energy Savings Off - No temperature Setback; Lowest energy Savings; Lower energy Savings; Standard energy Savings; Higher energy Savings; Highest energy Savings ; Verdant VX-tr Network Installation... -
Page 19: Testing Thermostats
Press the “Up” button to change the temperature setpoint above ➤ the current room temperature to confirm that the thermostat initiates heating. change the fan speed by touching the “Fan” button to test if the ➤ thermostat is controlling the fan speed. Verdant VX-tr Network Installation... -
Page 20: Confirming Network Connectivity
Management ➤ Website with the correct room number; IF INSTALLED THERMOSTAT(S) ARE NOT CONNECTING TO THE NETWORK AND DO NOT APPEAR ON THE VERDANT’S REMOTE MANAGEMENT WEBSITE, STOP THE INSTALLATION AND CONTACT VERDANT TECHNICAL SUPPORT Verdant VX-tr Network Installation... -
Page 21: Troubleshooting
HVAc unit is set to “external thermostat” (class 2) ➤ mode. Error Codes ERR 1 thermostat temperature Sensor Hardware Defect ERR 2 thermostat radio Hardware Defect ERR 3 thermostat radio Software Defect ERR 5 thermostat Memory Defect Verdant VX-tr Network Installation... -
Page 22: Warranty
Should a covered defect occur during the warranty period and customer notifies Verdant’s sole and exclusive remedy will be, at Verdant’s sole option and expense, to repair or replace the product. replacement products or parts may be new or reconditioned or a comparable version of the defective item. - Page 23 BLANK PAGE...
-
Page 24: Technical Specifications
6,786,421; 6,619,555; 6,581,846; 6,578,770; cANADIAN PAteNtS: cA2615065; cA2633113; cA2633121; cA2633200; OtHer PAteNtS PeNDING. Verdant environmental technologies, Inc. reserves the right to make changes, without notice, in design or components as progress in engineering and manufacturing methods may warrant. Product appearance may vary.
