ASSEMBLY INSTRUCTIONS
SHE
F
F
IELD CHAIR
SMSHEFPU / SMSHEFPK / SMSHEFBL
SMSHEFGR
Quality Assurance Guide
Weight capacity: 80kgs
This stool has a load rating of 120kgs
This design and instruction booklet is subject to copyright.
1 CTN
www.officeworks.com.au
For spare parts or hardware call :(03)93103011 or email:Hardware@kyvas.com.au
1 / 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Studymate SMSHEFPU
Summary of Contents for Studymate SMSHEFPU
- Page 1 ASSEMBLY INSTRUCTIONS IELD CHAIR SMSHEFPU / SMSHEFPK / SMSHEFBL SMSHEFGR Quality Assurance Guide Weight capacity: 80kgs This stool has a load rating of 120kgs This design and instruction booklet is subject to copyright. 1 CTN www.officeworks.com.au For spare parts or hardware call :(03)93103011 or email:Hardware@kyvas.com.au...
- Page 2 20min (03) 9310 3011 NOTE • Please check you have all hardware before assembly. • If you are missing any hardware, please contact Kyvas on (03) 9310 3011 or email hardware@kyvas.com.au • Please ensure you have the name of the item, required hardware part and quantity. •...
- Page 3 Furniture Assembly Instructions Style Guide PART LIST HARDWARE LIST M6 X 30MM M6 X 20MM 3 / 8...
- Page 4 Furniture Assembly Instructions Style Guide Step 1 Note: Turn the Star Base (E) upside down. Push the Castors (F) into holes at the end of each leg. Turn the Star Base (E) upright and insert Gas Lift (D) into the center hole of Star Base (E). Step 2 3 Pcs 3 Pcs...
- Page 5 Step 3 4 Pcs 4 Pcs 4 Pcs 4 Pcs M6 x 20MM used to complete used to complete this step. this step. 4 Pcs 4 Pcs 4 Pcs 4 Pcs used to complete used to complete this step. this step. FRONT FRONT Note: Align the Seat Plate (C) so the FRONT of the Seat Plate matches the FRONT label...
- Page 6 Step 5 Your Sheffield Chair is now complete and ready for use IMPORTANT NOTE: Periodically check and re-tighten screws. Care Instructions - fabric chair Spot clean fabric with upholstery shampoo or dry cleaning powder only. Do not saturate fabric. Apply proprietary cleaning products strictly according to instructions. ...
- Page 7 Furniture Assembly Instructions Style Guide IELD CHAIR Functionality - To increase chair height pull lever upward while lifting body weight slightly off the seat. - Release lever at desired height. - To lower chair height sit fully into the chair and pull lever upward. - Release lever at desired height.
- Page 8 Fur ni t ur e Warranty 3 years Product Warranty – valid for Australian customers only Officeworks Ltd warrants that this product will be free from defects and work as intended for 3 years from the date of purchase by the original customer. If the product has any defects or does not work as intended during the Warranty Period, Officeworks will, at its election and at its expense, repair or replace the product.
