Coemar ISPOT 575 EB Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

SPOT
575 EB
manuale
di istruzioni
instructions
manual
1^ edizione, luglio 2002
st
1
edition, july 2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ISPOT 575 EB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Coemar ISPOT 575 EB

Summary of Contents for Coemar ISPOT 575 EB

  • Page 1 SPOT 575 EB manuale di istruzioni instructions manual 1^ edizione, luglio 2002 edition, july 2002...
  • Page 2 Prendete nota, nello spazio apposito, dei dati relativi al modello e al rivenditore del vostro ISPOT 575 EB : in caso di richiesta di informazioni, pezzi di ricambio, servizi di riparazione o altro ci permetteranno di assistervi con la massima rapidità...
  • Page 3 11.3. Quick guide to menu navigation 11.4. Rapid scrolling 12. DMX 512 channel functions 13. Aligning the lamp in the optical path Turning on the ISPOT 575 EB without movement Resetting the counter 16. Automatic realignment 17. Opening up the projector 18.

  • Page 4: Important Safety Information

    3. Important safety information Fire prevention: 1. ISPOT 575 EB utilises a Phillips 575 MSD or 575 MSR/2 lamp; the use of any alternative lamp is not recommended and will null and void the fixture’ s warranty. 2. Never locate the fixture on any flammable surface.

  • Page 5: Lamp: Installation And Replacement

    4. Lamp: installation and replacement ISPOT 575 EB utilises a Philips 575 MSD or a Philips 575 MSR/2 lamp at 575 watts with a GX 9,5 lamp base. The lamp is availa- ble from your authorised coemar sales agent. Philips 575 MSD Philips 575 MSR/2 coemar cod.

  • Page 6: Operating Voltage And Frequency

    13 for instructions about this procedure. 5. Operating voltage and frequency The projector may operate at voltages including 100, 115, 208, 230 or 240 V. coemar presets (barring specific requests) a voltage of 240v.

  • Page 7: Installation

    For truss mounted installations coemar includes 2 cam-lock mounting devices (A). You may fit the cam-locks in 2 different positions on the base of the ISPOT 575 EB. The cam-lock fittings are of the type which need a 1/4 turn. To be used correctly the fittings must be correctly fitted with some care.
  • Page 8 We recommend the use of a safety chain fitted through the “B “slot of the ISPOT 575 EB and to the suspension truss in order to avoid the fixture accidentally falling. If using an after-market safety chain not manufactured by coemar, ensure that it is of sufficient rating to hold the weight of the unit.

  • Page 9: Mains Connection

    10 mm, rated 300/500V, tested to 2KV, operating temperature -40° +180°, coemar cod. CV5309). Mains connection ISPOT 575 EB can operate at voltages from 208V-230V-240V at 50 or 60Hz (operating voltage and frequency can be selected as described in section 5 of this manual).

  • Page 10: Signal Connection

    Control signal is digital, and is transmitted via two pair screened ø0.5mm cable. Connection is serial, utilising XLR 3 male and female sockets located on the base of the ISPOT 575 EB, labeled DMX 512 In and OUT (see diagram).

  • Page 11: Dmx Addressing

    To ensure that each projector accesses the correct signal, it is necessary to correctly address each fixture. Any number between 1 and 490 can be generated via the multifunction panel of the ISPOT 575 EB. This procedure must be carried out on every ISPOT 575 EB.

  • Page 12: Function Settings (Func)

    English 11. Display panel functions The display panel of ISPOT 575 EB shows all the functions available; it is possible to change some of those parameters and to add some functions. Changing the setting made by coemar can vary the functions of the device so that it will not respond to the DMX 512 controller used to control it.

  • Page 13: Inverted Display

    English inverted display iSpot 575 EB As indicated above, the allows the display in the led display panel to be inverted for ease of use should the pro- jector be operated with its base on the ground. function display A O O 1 To change DMX address use (+) and (--);...

  • Page 14: Measure And Test(Meas)

    English 11.2. Measure and test(MEAS) Ispot 575 EB The internal microprocessor of the allows for several diagnostic and output parameters to be displayed. You may record, in this menu, the position in which the projector will come to rest when turned on with no dmx signal attached.

  • Page 15: Rapid Scrolling

    DM I N R A T E HOUR 11.4. Rapid scrolling iSpot 575 EB Via the display, it is possible to rapidly scroll through the various numbers displayed in the menu which apply to the following 3 uses: 1) Pressing down and holding the + or - buttons will cause the numbers to scroll more quickly than by simply pressing buttons repea-...
  • Page 16 12. DMX 512 channel functions If you have correctly followed all the steps described up to this point, your DMX 512 controller will allow you complete control of all the functions of the ISPOT 575 EB as described in the following table: Channel...
  • Page 17 English Channel Function Type of Control Effect Decimal step no gobo 0-10 gobo 1 11-40 gobo 2 41-70 rotating gobo step or proportional gobo 3 71-100 selection on wheel selectable via gobo 4 101-130 channel 20 gobo 5 131-160 gobo 6 161-192 proportional continuous rotation of the gobo wheel from slow to fast...

  • Page 18: Aligning The Lamp In The Optical Path

    English 13. Aligning the lamp in the optical path Aligning the lamp in the optical system is achieved via the 3 adjusters at the rear of the projector. This procedure should be under- taken to properly align the lamp in the optical system and to avoid the possible overheating of the internal components due to the incorrect focusing of the beam onto components not intended to be exposed to this.

  • Page 19: Resetting The Counter

    Turning on the ISPOT 575 EB without movement This function may be useful should you need to power up the ISPOT 575 EB inside its roadcase or for any other reason where you may wish to power up the unit without it moving.

  • Page 20: Opening Up The Projector

    English 17. Opening up the projector By removing the casing, complete access is available to the internals of the projector. Attention Always remove mains power prior to accessing the internal components of the projector. 1) Use a screwdriver to remove the screws which affix the front and rear housings. 2) Lift the housing to gain access to the internals of the fixture.

  • Page 21: Interchanging Gobos

    English 18. Interchanging gobos ISPOT 575 EB utilises a mechanical system which allows the fixture’ s gobos to be removed without the need for specialised equip- ment. Replacement gobos should be made of either heat resistant glass or metal. An ever-increasing range of gobos is available from your coemar sales network.
  • Page 22 240V 50Hz 60Hz 3) Close up the base with the housing covers as they were originally. 4) Note on the sticker on the outside of the ISPOT 575 EB the new voltage which you have selected.(as shown in the diagram)

  • Page 23: Thermal Protection

    NOTE: it is important to remove power from the fixture if the lamp has reached the end of its life and to replace the lamp. 22. Maintenance Whilst every possible precaution has been taken to ensure the trouble-free operation of your ISPOT 575 EB, the following perio- dic maintenance is highly recommended.

  • Page 24: Electronic Motor Alignment

    This section is reserved only for technical and specialist personnel. The display panel of the ISPOT 575 EB allows for the electronic alignment of the projector’ s motors in the optical system. This pro- cedure is performed by coemar at the factory. It may be useful to perform this procedure in the case of internal components being replaced.

  • Page 25: Error Messages

    The initial parameter settings are incorrect or corrupt; the projector has reloaded its factory default settings. Turn the projector off and on again. Should the error reoccur, refer the unit to your authorised coemar ser- vice centre to have the EEPROM check and possibly replaced.

  • Page 26: Spare Parts

    25. Spare parts All the components of the ISPOT 575 EB are available as replacement spares from your authorised coemar sales agent. Accurate description of the fixture, model number, and type will assist us in providing for your requirements in an efficient and effec-...

This manual is also suitable for:

Iwash 575 mb
