- Page 1 Digitally Steerable Line Array Loudspeaker Systems IC Live FRO Series USERS MANUAL Installation Instructions ICL-FRO-M ICL-FRO-M-WR ICL-FRO-DUAL-M ICL-FRO-DUAL-M-WR ICL-FRO-TRIP-M ICL-FRO-TRIP-M-WR...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 13. Only use attachments/accessories specified by the manufac- 2. Keep these instructions. turer. 3. Heed all warnings. 14. Disconnect this apparatus during lightning storms or when 4. Follow all instructions unused for long periods of time. 5. - Page 3 IMPORTANT WEATHER RESISTANT SAFETY INSTRUCTIONS 1. Read these instructions. THE INSTALLATION SHALL BE CARRIED OUT IN 2. Keep these instructions. ACCORDANCE WITH ALL APPLICABLE INSTALLATION RULES IN COMPLIANCE WITH THE NATIONAL 3. Heed all warnings. ELECTRICAL CODE, ANSI/NFPA 70 AND CANADIAN 4.
-
Page 4: Installation
WALL MOUNTING The following instructions assume that the column array(s) will be mounted using the included Renkus-Heinz HK series hinge kits. The hinge kits will be packed in one of the cartons. Each mounting plate has hinges on both the right and left sides of the plate to provide for either “right”... -
Page 5: Important Mounting Instructions
Each male mounting plate is provided with 6 mounting holes. Only two fasteners in each male mounting plate, securely attached to a wall, and two 1/4” toggle bolts are needed to fully satisfy mounting needs and safely secure the Renkus-Heinz IC-Live loudspeakers to the wall. - Page 6 Wall Mounting Detail Female Mounting Hinge Attached to Column Cabling Note: When the loudspeaker position relative to its cable drop does not allow the conduit to enter from below, the conduit must go down behind the loudspeaker and loop back up to enter the connector pocket. The loudspeaker must not be installed upside down.
-
Page 7: Rear Panel Connectors
Hardware Inputs, Outputs & Indicators To connect an IC-R-II array to the RHAON network, you first make the hardware connections, and then (if you are using CobraNet for digital audio distribution) assign signal routing using RHAON software. Make power and analog connections first since they will become inaccessible once CobraNet and AES/EBU are connected. - Page 8 19201 Cook Street, Foothill Ranch, CA USA Phone: +1 949 588 9997 • Fax: +1 949 588 9514 sales@renkus-heinz.com • www.renkus-heinz.com RH 814 Rev B, August 2019...
