Page 1: Document Control
Service Manual D ate Product WMA07DXESXS MANUAL DESERVICIO | MODELO WMA07DXESXS... -
Page 2: Table Of Contents
Issue Service Manual Rev. Order NO.TL1610S009 Chapter 1: General Infromation 1-1. Table of Contents ......................1 Document control Chapter 1. General Information ................2 ....................................n i l ............................Chapter 2. Product Feature ..................4 ....................................c i f .................. - Page 3 Issue Service Manual Rev. Order NO.TL1610S009 1-2. General Guidelines When servicing,observe the original lead dress.If a short circuit is found, replace all parts which are overheated or damaged by the short circuit.After servicing ,see to it that all the protective devices such as insulation barriers ,insulation papers shields are properly installed .Confirm that the screws,parts and wiring which were removed in order to service are put in the original positions, or whether there are the portions which are deteriorated around the service places serviced or not.
-
Page 4: Chapter 2. Product Feature
Issue Service Manual Rev. Order NO.TL1610S009 Chapter 2: General Infromation 2-1 FEATURES Soak wash make cleaner wash. Fashionable appearance, transparent top lid Efficaciously reduce noise Self-adjustment to unbalance of laundry in spinning Fuzzy computer control, self-program function, more convenient washing 2-2 Net Dimension Unit:mm... - Page 5 Issue Service Manual Rev. Order NO.TL1610S009 2-2 SPECIFICATIONS WMA07DXESXS Model Free standing Built under EAN code Energy efficiency class Features for use Wash capacity Spin capacity 15/21/27/33/39/43/48/54 Level/Volume Preset Residual dampness <115 Control model Controller Normal computerized Fuzzy computerized Frequency conversion...
-
Page 6: Chapter 3. Safety Precautions
Issue Service Manual Rev. Order NO.TL1610S009 Chapter 3. Safety Precautions 3-1. Safety Please plug the plug on special The power cord plug should be convenient receptacle to be pluged in or pluged out with hand with rated voltage. Be sure to use while the washing machine runs normally. - Page 7 Issue Service Manual Rev. Order NO.TL1610S009 3-2.Warning and Cautions Do not decompose, repair or alter the Do not stretch hands into the working machine by yourself. machine. It is dangerous even if the rotation is slow. Take special care of the children.
-
Page 8: Chapter4 Installation And Accessory Parts
Issue Service Manual Rev. Order NO.TL1610S009 Chapter4 Installation and accessory parts 4-1.Key points in installation Please install and adjust the machine according to the requirement of the mannual. It is very important to your security and correct operating the machine. 4-2. -
Page 9: Usage Of Operation Buttons
Issue Service Manual Rev. Order NO.TL1610S009 4-4.Usage of operation buttons Description of the function of the buttons Flashing Normal Deep Clean 7.0kg Warm Delicate Cold Quick Temp Indicator display Remaining /Delay Display Delay(Hours) Child lock function The function is intended for children safety and preventing the washing program from accidental changes by children. - Page 10 Issue Service Manual Rev. Order NO.TL1610S009 A “ ” button Power Power Power Start Power Pause Start B “ ”button Pause After the power is switched on,press it to start the machine . During working, push it to pause. During pause,push it to restart and go on working. C “...
-
Page 11: Product Briefs
Issue Service Manual Rev. Order NO.TL1610S009 4-5 Product Brief 1)Computer sequencer It adopts pouring seal with polyurethane on the surface. The light-emitting diode is sealed with insulation bushing to avoid humidity. T o avoid splashing, the surface of computer plate and box and the operation components of the control panel seat are coated with control panel film. -
Page 12: Adding Washing Powder
Issue Se r vice Manual Rev. Order NO.TL1610S009 Adding washing powder 4-6. It is suggested to dissolve detergent before adding to the tub, see as below: 1. Prepare warm water (<35 °C) in a container 2. Add washing powder, stirring to dissolve it completely. or detergent box. - Page 13 Issue vice Manual Rev. Order NO.TL1610S009 Attention : Do not lift the control panel seat by force ,otherwise the safety switch control rod may get transformed.and the jointer part of the connecting pipe of the water level sensor may be loosened ,therefore influence the normal operation of the microswitch and water level sensor .
-
Page 14: Chapter 5. Parts And Functions
Issue Service Manual Rev. Order NO.TL1610S009 Chaper5.PARTS AND FUNCTIONS Drainage hose Liquid whitener inlet Back cover Drainconnector Adjustable foot film... -
Page 15: Chapter 6. Maintenance Service And Trouble Shooting
Issue Service Manual Rev. Order NO.TL1610S009 Chapter. 6 MAINTENANCE SERVICE AND TROUBLE SHOOTING... -
Page 16: Trouble Shooting Charts
Issue Service Manual Rev. Order NO.TL1610S009 6-2 Trouble-shooting charts If you replace the computer sequencer without checking the other components carefully , the computer sequencer may be damaged again .Therefore,please first check if the other components working normally before replacing the computer sequencer in maintenance . 6-2-1 No acting (The indicator is off ) Confirm that there is no power failure , and the power plug is inserted reliably. -
Page 17: No Water Filling
Issue Service Manual Rev. Order NO.TL1610S009 6-2-2 No water filling Switch on the power .Push the START button Remove the foreign materials of the water There is sound Confirm the action sound inlet valve filter screen or raise the water of the water inlet valve ? pressure to 0.03Mpa-1Mpa before use There is no sound... -
Page 18: No Draining
Issue Service Manual Rev. Order NO.TL1610S009 Set rinse or spin start 6-2-4 No draining the machine. Roll up normally Check the drain system like the Check if the drain motor acts? drain pump etc. Measure the voltage Exist Check the drain motor. of the two ends of the drain motor. -
Page 19: No Spinning
Issue Service Manual Rev. Order NO.TL1610S009 6-2-6 No spinning The washing and draining are normal. No On/Off point Check the On/off point of Replace the microswitch or stop the microswtich and stop switch. switch. Normal Check if the clutch pawl is Replace the drain motor. -
Page 20: Too Much Noise In Washing
Issue Service Manual Rev. Order NO.TL1610S009 6-2-8 Too much noise in washing If the noise of the motor Replace the motor. is too much? If the motor fastened tightly? Fasten the motor. The pulsator is rubbing the Add pulsator gasket. bottom of the inner tub 6-2-9. -
Page 21: Brake Time Out
Issue Se r vice Manual Re v. Order NO.TL1610S009 9. Brake time out 6-2-10 Is the brake moment of the retarder Adjust the brake moment. lower than 6N.m? Is the reset spring of the retarder loose? Adjust the reset spring. Check if the pawl can leave the ratchet for 2mm Is the gap between the connecting arm block and the brake arm of retarder less... -
Page 22: Chapter 7 Wiring Diagram
Issue Service Manual Rev. Order NO.TL1610S009 Chapter 7 WIRING DIAGRAM Wiring Diagram Fuse Brown Bl u e/ W hi t e Yel l o w Door Swi t c h Yel l o w Yel l o w/ G reen Grey Col d I n l e t Val v e Orange... - Page 23 MANUAL DESERVICIO | MODELO WMA07DXESXS...
