- Page 1 LMD6124PBEB0 LMD6124PBCS0 LMD8124PBEB0 LMD8124PBCS0 PM01...
-
Page 3: Table Of Contents
contents Important Safety Instructions ............... 4 Packing list ....................7 Machine components ................8 Control panel ..................9 Installation instructions ................. 9 Installing the lint filter ................9 Install the drain hose ................10 Install the washer legs ................. 11 Install the water inlet hose .............. -
Page 4: Important Safety Instructions
important safety instructions • Your own safety is important for us. Please read this information before using your new product. • Do not use extension cords. • Do not plug other electric appliances to the same power outlet. • Hold the connector by the power plug, not by the cord. •... - Page 5 • Insert the power cord into a rated voltage outlet. Be sure to use a single-phase three pin outlet. • The terminal of the outlet must be grounded. • Insert the power plug in a location where it can be easily inserted and extracted by hand.
- Page 6 • Do not reach into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. • Do not attempt to disassemble, repair or alter the machine by yourself. • Do not put hot or heavy objects on the washing machine.
-
Page 7: Packing List
Water inlet hose Spin cap Twin-tub washing machine Owner's manual Draining hose Draining hose models LMD6124PBEB0, models LMD8124PBEB0) LMD6124PBCS0, LMD8124PBCS0) Bottom leg Hose clamp (on mod- els LMD8124PBEB0) -
Page 8: Machine Components
machine components 1. Drain selector knob 10. Spin tub exterior cover 2. Wash type selector knob 11. Spin tub interior cover 3. Wash timer 12. Spin timer knob 4. Wash tub cover 13. Spin tub frame 5. Water inlet port 14. -
Page 9: Control Panel
. set up the drain hose on models (LMD6124PBEB0 LMD6124PBCS0, LMD8124PBCS0) The drain hose when laid down on the floor , should not be higher than 10 cm, otherwise the drainage will not flow at the proper rate causing an incomplete process. -
Page 10: Install The Drain Hose
set up the drain hose on models (LMD8124PBEB0) Before using the washer, hang the drain hose on a suitable location. The height of the drain hose should be between 0.8 - 1.2 m install the drain hose The drain hose is packed inside the wash tub at the factory. Before using the machine, screw the drain hose on the drain valve. -
Page 11: Install The Washer Legs
install the washer legs 1. Carefully tilt the washing machine to the back and install the bot- tom legs at the front of the base. Make sure that the legs are in- stalled in place. (Figure 1). 2. Carefully tilt the washing machine to the front and install the bot- tom legs at the back of the base. -
Page 12: Washing Tips
washing tips • The maximum capacity during washing and spinning cycles refers to the maximum weight of standard dry clothes that can be washed or spined at the same time. The load size during any wash- ing cycle should be lower than the rated capacity. •... -
Page 13: Proper Use Of Laundry Products
proper use of laundry products Powder detergent Method 1: Dissolving it in the wash tub: 1. Add a small amount of water into the machine. 2. Add the powder detergent. Run washing machine for 30 seconds to dissolve it completely. 3. -
Page 14: Washing Sequence
washing sequence 1. Water Inlet Selector. Set the selector to the WASH setting. 2. Add water. Let the water enter the washer tub. Add the diluted detergent and make sure the water level reaches the desired level. 3. Add the wash load into the tub. Add more water as necessary. -
Page 15: Spin
spin 1. Distribute the load into the spin tub evenly and smoothly. Properly place the spin cap, even when the load size is small. Press down spin cap Press down Unbalanced Correct Without Correct load spin cap position 2. Spin the load. 3. -
Page 16: Rinse
rinse 1. Place the load into the washing tub. Select the appropriate wash type according to the load. 2. Adjust the water level and let the water into the tub. 3. Use the WASH TIME selector knob to set a time of to 5-7 minutes to perform the rinse. - Page 17 once the wash is completed WARNING: UNPLUG THE WASHER FROM THE POWER SUPPLY BEFORE PERFORMING ANY CLEANING OR SERVICE JOB. After each use, be sure to clean the lint as well as any foreign mate- rials from the lint filter and the overflow filter. Removing lint is im- portant for the good operation of the machine.
- Page 18 cleaning the overflow filter Too much lint in the overflow filter will affect the normal operation of the machine. Clean it once every two months. 1. Remove the overflow filter. Nip the elastic fixing claw and pull in the direction of the arrow to remove the overflow filter (as shown in the illustration).
-
Page 19: Cleaning The Unit
cleaning the unit • Wipe the entire unit using a soft moist cloth. • Use a neutral detergent, if the machine is very dirty. • Do not use water directly when cleaning. • After washing, disconnect the water inlet hose. •... -
Page 20: Troubleshooting
troubleshooting If a breakdown occurs, unplug the power cord before inspecting the machine. The following situations do not always indicate a breakdown. Please double confirm before sending the machine to be repaired. If an actual breakdown occurs, visit the special maintenance depart- ment or after-sales service department of our company. -
Page 21: Specifications
Model LMD6124PBEB0 LMD6124PBCS0 Rated washing power 420 W 420 W Rated spinning power 280 W 280 W Rated voltage/frequency 110 V/60 Hz 220 V/50 Hz Capacity 16 kg 16 kg Model LMD8124PBBEB0 LMD8124PBCS0 Rated washing power 430 W 430 W... - Page 22 notes...
