Summary of Contents for mabe LMD1841B
- Page 1 LMD1841B LMD1842B PM01...
-
Page 3: Table Of Contents
Before using the washer, please carefully read this owner's manual. Keep this manual for future reference. contents Parts of your new washer ..............4 Safety Precautions ................. 5 Installation and Setup ................7 Installing the Lint Filter ................. 7 Drain Hose ....................7 Drain Hose Direction ................ -
Page 4: Parts Of Your New Washer
parts of your new washer 1. Drain Selector Knob 11. Drain Hose 2. Wash Selector Knob 12. Pulsator 3. Wash Timer Knob 13. Cabinet Handle 4. Water Inlet 14. Wash Tub 5. Water Inlet Selector 15. Base 6. Control Panel 16. -
Page 5: Safety Precautions
safety precautions For your own safety, before us- Do not install the washer in a ing the washer carefully check damp area, for example in a the outlet and the ground con- bathroom. Never clean the nection. washer with water or put damp clothes on the control panel. - Page 6 Do not reach into a machine in Do not disassemble, repair or operation. It is dangerous even modify the machine yourself. though the spin rotation is slow. Be specially careful to keep chil- dren away from the machine. Do not wash items that are dampened or soiled with volatile substances, such as paint, sol- Do not place hot or heavy items...
-
Page 7: Installation And Setup
installation and setup The washer must be installed and adjusted in accordance with the instructions contained in this manual. It is very important for your safety that you have the correct operating conditions for the ma- chine. how to install the lint filter Place the bottom portion of the filter inside the overflow filter, then push in the top portion. - Page 8 • If the drain hose is too long, cut it to the correct length. For best results, cut the drain hose with an angle at the front end. • If a longer drain hose is needed, please buy a new one. The inside diameter of the hose must not be less than 40 mm, and the length must not exceed 1,5 m If the new drain hose is too long, cut it at point A or point B.
-
Page 9: Drain Hose Direction
changing the drain hose direction 1. The following illustration shows the factory position of the drain hose. Note: Extend the drain hose from the side of the spin tub. 2. Place a soft item on the floor. Gently tilt the machine with the front surface facing the floor. -
Page 10: Preparation Before Washing
install the water inlet hose and select the water level 1. Insert the fill hose in the water inlet port located in the control panel (to disassemble the water inlet pipe, simply press the con- trol panel as shown in the figure and pull outward). 2. -
Page 11: Tips And Notes
• Do not overload the washer. • When the propeller is operating, the buttons from clothes may cause noise. To obtain a quiet operation, wash garments that have buttons with clothes that do not have buttons. • Make sure all clothes can be machine washed. •... -
Page 12: Bleach And Detergent
bleach and detergent using bleach 1. Fill the tub with water to the desired level. In a separate con- tainer, dilute bleach in water. 2. Slowly pour the diluted solution in the wash tub. • Avoid using bleach with clothes having patterns and colors, as they will discolor or stain. -
Page 13: Wash Instructions
washing instructions wash 1. Place the water inlet selector in the WASH setting and the water level selector in the desired setting. 2. Fill the tub up to the desired level and add liquid detergent or dissolved in water powder detergent. Run the wash cycle for a few minutes to completely dissolve the detergent in the water. -
Page 14: Wash Sequence
wash sequence Wash timer Wash Type If you want to set less than 2 You can select Normal or Heavy. minutes, go to the 6 minutes set- ting, then back. drain selector Spin timer During washing, do not select If you want to set less than a the drain position. -
Page 15: Spinning A Load At The Middle Of The Cycle
spinning a load at the middle of the cycle 1. Load the clothes in the tub, evenly distribute the load. 2. Spinning: a. Place the top cover of the spin tub properly. The top cover should be properly placed even if the load is small. b. -
Page 16: Rinse
rinse rinsing with clear water 1. Place the clothes in the wash tub. Select the desired water flow according to the load. 2. Adjust the water level: Set the water level with the water level adjustment lever according to the size of the load. Then fill the tub continuously until reaching the desired water level. -
Page 17: Cleaning The Filters After A Wash Cycle
cleaning the filters after a wash cycle UNPLUG THE APPLIANCE FROM THE POWER SUP- PLY BEFORE PERFORMING ANY CLEANING AND MAINTENANCE JOB. The lint and overflow filters should be cleaned as recommended. The washer will not work properly if lint and foreign materials are left inside it. -
Page 18: Maintenance Of The Unit
2. Remove the corrugated hose. Disassemble the upper part of the corrugated hose which is located inside the overflow filter. 3. Clean the lint around the filter and rinse it under running water. 4. Reinstall the overflow filter: a. Replace the corrugated hose. b. -
Page 19: Troubleshooting
troubleshooting if clothes get trapped on the outer side of the spin tub If clothes fall on the outer side of the spin tub, contact the nearest service center. Do not try to repair the appliance yourself. if the residual water is frozen Prevent the water to freeze by draining all the water after each use. -
Page 20: Parts Included
Problem Check Abnormal sound • Are there pins, coins or metallic objects in- during wash. side the tub? There are abnor- • Is the machine located on an uneven or mal sounds and vi- slanted floor? bration during the • Is the top cover is evenly placed over the spin cycle. -
Page 21: Specifications
Model LMD1841B LMD1842B Power supply tension or 110 V ~ 220 V ~ Rated tension (Volt) Operation frequency or 60 Hz 50 Hz Rated frequency (hertz) Rated current (Amper) 4,70 A / 2,1 A 2,40 A / 1,1 A... - Page 22 notes...
