- Page 1 Verso Pro 2 Installation Manual...
-
Page 3: Table Of Contents
6.1. Control panel C5.1 ..................................38 6.2. Starting the Unit With a Computer............................39 6.3. Calibration of Clean Filters ............................... 42 6.4. Quick Inspection ..................................43 UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 4: Introduction
Recovered heat/cold capacity is changed by adjusting the rotor speed. When heat recovery is not required, the wheel stops. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... - Page 5 Maximum air volume may be limited according to the order, for example, if lower power fans are used or higher air vo- lume is not required by the project requirements. For exact maximum air volume see the technical data print-out of the specific unit. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02...
-
Page 6: Unit Components And Sections
1 – fan assembly with an installation frame 2 – fan control board (C5_VM), 3 – bag filters, 4 – fan section label, 5 – filter section label UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 7: Counter-Flow Heat Exchanger (Cf) Section
3 – counter-flow heat exchanger, 4 – drop eliminator, 5 – condensate trays, 6 – air bypass control board (C5_PM or C5_MDS), 7 – automatic switch, 8 – CF section label UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 8: Rotary Recuperator (R) Section
1 – rotor wheel, 2 – automation box, 3 – automatic switch, 4 – rotor wheel brush seals, 5 – rotor belt, 6 – rotor gear motor, 7 – rotor section label UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 9: Recirculation Section
Recirculation section is intended for mixing extract and supply air for heating or cooling thereof by reducing energy consumption of heaters/coolers. Fig. 4. Recirculation section 1 – air mixing damper, 2 – damper actuator, 3 – recirculation section label UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 10: Cooler And Heater Sections
(see Chapter “Requirements for Electrical Connection”). A water heater is fitted with a return water temperature sensor, which protects the heat exchanger against freezing. Sensor installation procedure is described in Chapter “Installation of External Heating/Cooling Devices”. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 11: Air Dampers
Fig. 7. Air closing dampers 1 – air damper, 2 – electric damper actuator UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 12: Silencers
L1 Air duct for supply air connected on the left bottom side of the unit VERSO R VERSO CF VERSO S L2 Air duct for supply air connected on the left upper side of the unit VERSO R VERSO CF UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... - Page 13 R1 Air duct for supply air connected on the right bottom side of the unit VERSO R VERSO CF VERSO S R2 Air duct for supply air connected on the right upper side of the unit VERSO R VERSO CF UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02...
-
Page 14: Unit Transportation
Max. 60° Max. 60° Fig. 10. Lifting of individual sections Lifting means (pipes, belts, ropes, traverses) are not included. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... - Page 15 Reinforced mounting frame has special retractable lifting holders, for fixing belts or ropes. A - A Max. 60° >L Fig. 11. Lifting AHU fully assembled onto reinforced mounting frame Lifting means (pipes, belts, ropes, traverses) are not included. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02...
- Page 16 (dust, rain, cold, etc.). UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02...
-
Page 17: Mechanical Installation
0.3 mm for 1 m in the longitudinal direction and 0.5 mm for 1 m in the transverse direction. 19,4 Fig. 12. Installation frame with adjustable feet UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 18: Inspection Area
1610 1610 1810 1810 1810 2010 2010 2010 2210 2210 2210 Measurements in the table are approximate. For exact unit measurements see the technical data print-out. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 19: Door Handles And Hinges
As large unit sections may be difficult to connect properly on site and the unit door may warp, it is necessary to adjust the hinges. Loosen the lock screw to raise/lower the door by a few millimetres. Fig. 15. Adjusting the hinges UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 20: Connection Of Sections
2–3 mm. If the unit is ordered with an installation frame, additionaly sections shall be tightened through the designated holes in the installation frame. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... - Page 21 Fig. 18. Internal connection in a fan section 1 – fan section tightening angle-piece, 2 – wall to which the fan is mounted, 3 – other section tightening angle-piece, 4 – grommet d29 UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02...
-
Page 22: Installation Of External Heating/Cooling Devices
AHU and sealed in the same way as other sections (see Chapter “Connection of Sections”). Fig. 19. Examples for installation of heater/cooler sections UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... - Page 23 PPU must be installed as close to the water coil as possible. It is recommended to use PPU made by Komfovent. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02...
-
Page 24: Connection Of A Condensate Drain
Condensate collection location must be easily accessible for cleaning and disinfection. Fig. 24. Condensate drain connection to sewer system UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 25: Connection To Air Ducts
If the unit was ordered for outdoor installation, each section of the unit will be fitted with a protective roof. Separately ordered protective roof shall be installed once the unit is fully assembled. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... - Page 26 + 120 Fig. 27. Installation of a separately ordered protective roof Part count and measurements may differ depending on the unit type or project requirements. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02...
-
Page 27: Electrical Installation
Air handling units designed for 400 VAC, 50 Hz supply voltage, connected through the main circuit breaker (QS1 in wiring diagrams). 5 L 3 3 L 2 1 L 1 Fig. 28. Main circuit breaker UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... - Page 28 (Cu) 5 × 4,0 mm (Cu) 5 × 6,0 mm (Cu) 5 × 10,0 mm (Cu) 5 × 16,0 mm (Cu) 5 × 25,0 mm (Cu) UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02...
-
Page 29: Connection Of Electrical Components
Fig. 31. Main board of the C5 control panel 1 – control panel connection, 2 – Intranet or Internet connection, 3 – inner connections of components, 4 – terminals for external components UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... - Page 30 B5 (9–10) – when a water heater is installed, this terminal is used for connecting a return water temperature sensor (NTC 10kΩ) which protects against freezing. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02...
- Page 31 B8/B9 (25–30) – terminals for air quality and humidity sensors, which are used for the following functions (see “User Manual”): • Air quality control (AQC). • Recirculation control (REC). • Operation on demand (OOD). • Humidity control (HUM). UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02...
- Page 32 Fig. 36. Automation box cover If the DX device was not predefined in the controller software, these outputs will be inactive. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02...
-
Page 33: Control Panel Installation
Fig. 38. Control panel cable wiring Do not use sharp tools for pinning contacts in the control panel (e.g., screwdriver). Please use a pencil or a ballpoint pen. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 34: Connection Of Cables And Wires Between Sections
(fans, valves, rotor wheel). If necessary, use special ties to attach the wires to the unit housing. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 35: Connecting The Unit To The Internal Computer Network Or The Internet
Internet. In case of a computer, the unit is controlled via a web browser, and in case of a smart phone - via the Komfovent app. Use CAT5 type cable to connect your AHU to the computer network (RJ45 connection;... -
Page 36: Filters
Replace filters if they are visibly dirty even though it is not time yet and a filter change message is not displayed yet. Filter type, dimensions, filtering class, number and exact location is specified in the technical data print-out for the spe- cific unit. Depending on the order. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 37: Commissioning And Inspection Of The Unit
• Do not use the unit with a temporary electrical power supply as unstable power can damage the electronic components. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 38: Control Panel C5.1
If the unit is connected to the mains, the control panel will display a home screen or a screen saver that you can switch off with a single tap. To start an air handling unit or change a ventilation mode: Change operation mode? UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 39: Starting The Unit With A Computer
Chapter 4.3. Run the Internet browser on the computer and disable the use of all Proxy servers that may block the connec- tion in the settings. In the web browser address bar, enter the IP address of the unit: C5 Komfovent 192.168.0.50 UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... - Page 40 If you login attempt is successful, “Overview” window is opened. AHU control On/Off Operation mode Active functions Alarm status No alarms If the password was changed, use the changed password. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02...
- Page 41 2. Select a desired ventilation mode from the list. 3. Enter desired air flow and temperature in the selected mode settings. 4. Press “Save” button at the bottom of the screen. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02...
-
Page 42: Calibration Of Clean Filters
Calibration of filters with a computer: Select Point “Warnings/States”: If filters ordered with the unit are used (same manufacturer and filtration class), calibration of clean filters is not required. UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... -
Page 43: Quick Inspection
Connected external devices are working The condensate easily flows from the unit and the drainage piping is watertight Other comments: Installer Company Tel. No. Date Signature UAB KOMFOVENT we reserve the right to make changes without prior notice VERSO PRO2_2_20-02... - Page 44 LITHUANIA PARTNERS UAB KOMFOVENT J. PICHLER Gesellschaft m. b. H. www.pichlerluft.at TECHNINĖS PRIEŽIŪROS SKYRIUS / Ventilair group www.ventilairgroup.com SERVICE AND SUPPORT ACB Airconditioning www.acbairco.be Phone: +370 5 200 8000 Email: service@komfovent.com REKUVENT s.r.o. www.rekuvent.cz www.komfovent.com WESCO AG www.wesco.ch RUSSIA SUDCLIMATAIR SA www.sudclimatair.ch...
