panthera 9900301 Assembly Instructions

1) Take the crutch apart
4) Tighten one of the screws slightly.
With a small philips head screw driver.
(Bits PH 0)
Panthera AB, Gunnebogatan 26, SE-163 53 Spånga, Sweden, +46-8-761 50 40, www.panthera.se
ASSEMBLY INSTRUCTIONS
CRUTCH HOLDER S3
Assembly instructions for:
Crutch holder S3
art.no. 9900301
NOTE! The mounting could vary depending on type of crutch.
Tools needed:
Small Philips head screw driver (Bits PH 0)
2) Remove the plastic hose from the up-
per part of the crutch.
5) Remount the plastic hose.
art.nr. mont-kryckkäppshållare-S3-eng
Link to assembly Link to user manual
video
3) Slide the upper attachment onto the
upper part of the crutch. The upper at-
tachment fits tube diameter 19,2 to 23
mm, including the plastic bushings.
6) Remove the rubber shoe from the lo-
wer part of the crutch.
Rev.2018-03
