panthera PUSH HANDLE S3 Assembly Instruction

PUSH HANDLE S3 HEIGHT ADJUSTABLE
1) Open up one of the attachments and
place it around the backrets tube and fit
the hole in the attachment over the knob
on the tube. Note that there is a left and a
right versions av the attachment.
4) Finaly tighten the screw firmly with al-
len key 4 mm using a wrench
Panthera AB, Gunnebogatan 26, SE-163 53 Spånga, Sweden, +46-8-761 50 40, www.panthera.se
ASSEMBLY INSTRUCTION
Assembly instruction(adjustment page 2) for:
Push handle S3 Height adjustable
art.no. 4252060
Tools needed:
Allen key 4 mm
Allenkey 2.5 mm
Spanner 8 mm
2) Stick the push handle tube into the at-
tachment and lock it..
5) Done.
art.nr. mont-S3-körhandtag-HS-eng
3) Squeeze the attachment to help fit the
screw into the threaded hole. Tighten the
screw a few turns by hand.
Rev.2017-02
