panthera S3 Assembly Instructions

1) Loosen the back rest upholstery to ac-
cess easily to mount the torso support..
4) Then fit the screw into the threaded
hole in the attachment
Panthera AB, Gunnebogatan 26, SE-163 53 Spånga, Sweden, +46-8-761 50 40, www.panthera.se
ASSEMBLY INSTRUCTIONS
TORSO SUPPORT S3 VER. 2
Assembly instructions for:
Torso support S3 ver. 2
art.nr. 6770300 Torso support complete pair VER2
art.nr. 6770307 Assembly kit torso support S3 R VER2
art.nr. 6770308 Assembly kit torso support S3 L VER2
Tools needed:
Allen key 4 mm
2) Disassebble the support for easy
mounting on the backrest.
5) Tighten the screw firmly with allen key
4 mm.
art.nr. mont-S3-bålstöd-ver.2
QR link t0
assembly video
3) Enter the M6 screw into the hole in the
reiforcement plate on the backrest.
6) Place the bracket over the backrest
tube.
Rev.2018-01
