Chapter 1 Introduction

1.1Objective

To instruct the engineering and technical personnel, engineering refer to standard construction,
device installation to meet regulatory requirements, to ensure construction quality.

1.2 Scope

The instructions apply to model for the installation guide DH-ITC231 HD ANPR camera.

1.3 Range of Reader

Products Division, regional technicians, installation personnel, and customers are not included.

1.4 System Composition

This system is composed of front-end subsystem and rear-end platform software. Front-end subsystem
mainly snapshot plate, analyze plate info, analyze vehicle behavior, store snapshot and etc. Platform
software mainly stores picture, count vehicle flow (statistics), arm and etc.
This installation guide is for front-end subsystem, so only introduce you to installation and debugging of
the subsystem.

1.4.1 Front-end Subsystem Composition

Front-end subsystem is composed of picture snapshot module（HD camera and HD lens）, vehicle
detection module（radar）, strobe light module（LED fill light）, picture backlight module（exposure light）,
data storage module（ITC terminal management device）.
DH-ITC231 camera G-CMOS is 2.0 MP, so 1 channel is recommended, see chart below：
No. Device
All-in-one snapshot
1 unit
Cardan joint
4
bracket
ITC MINI terminal
5 management
device
Model Quanti
1
ITC231-RU1A-IRL
1
8018
ITSE0804-GN5B-D 1
ty
All-in-one device can configure (optional
built-in light-L, heat unit-H, heat and built-in
light-HL); after you select all-in-one device,
you do not need to select separate camera
and housing
Optional
1
Note
