Project Name: DH Network Camera
Product Construction Instruction Manual (Passenger Flow Solution)
File No.: DH-IPC-ZC015
Security Level: Confidential
DH Network Camera Product
(Passenger Flow Solution)
Construction Manual
Prepared by:
IPC Technical Support Dept.
Revision date:
Reviewed by:
IPC Technical Support Dept.
Review date:
Product Construction Instruction Manual (Passenger Flow Solution)
V3.1
Apr. 10, 2019
Apr. 10, 2019
1
DH Network Camera
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dahua DH-IPC-HDW8341X-3D Series
Summary of Contents for Dahua DH-IPC-HDW8341X-3D Series
- Page 1 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) Project Name: DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) File No.: DH-IPC-ZC015 Security Level: Confidential DH Network Camera Product Construction Manual (Passenger Flow Solution) V3.1 Prepared by: IPC Technical Support Dept.
- Page 2 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) Revision History Revision Description Revision Date Revised Version No. Revised by Approved by First create Apr. 10, 2019 V1.0 Chen Jiawei Xu Jianchun...
-
Page 3: Table Of Contents
DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) Table of Contents Table of Contents ..........................................3 I. Introduction ............................................. 4 Stereo Vision Passenger Flow Camera ....................4 II. Site Survey and Type Selection ....................................5 Overall Standard ............................ 5 8341 Stereo Vision Camera ......................... -
Page 4: Introduction
Stereo vision passenger flow products can be top mounted or ceilings mounted, and are mainly used for indoor passenger flow surveillance. The easy installation makes them the preferred products in passenger flow count. Model Picture Features IP67 rating DH-IPC-HDW8341X-3D series 2.8 mm, 3.6 mm IP54 rating DH-IPC-HD4140X-3D series 2.1 mm, 2.8 mm... -
Page 5: Site Survey And Type Selection
DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) II. Site Survey and Type Selection Overall Standard 1. The installation site must be bright enough, at least to ensure the head and shoulder contour of people in the detection area is clear. 2. - Page 6 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) Camera image of angle mounting...
-
Page 7: 8341 Stereo Vision Camera
DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) 8341 Stereo Vision Camera Type selection principles: Select a proper focal length of lens according to the installation height. 3 MP HDW8341X-3D stereo vision dome camera NOTE Detection thickness: regional people counting. Top-mounted 8341 stereo vision camera Arming width for Product P/N Material... - Page 8 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) 58*78.5 3.0≤H＜5.0 ≧0.55h Installation requirements Installation diagram of stereo vision dome camera...
- Page 9 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) Arming requirements: Top mounted, with the lens forming a 90° angle with the horizontal plane. Sufficient lighting in the region covered by the detection image. No blocking of sight in the region covered by the detection image (along the passenger flow direction).
-
Page 10: 4140 Stereo Vision Camera
DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) 4140 Stereo Vision Camera Type selection principles: Select a proper focal length of lens according to the installation height. DH-IPC-HD4140X-3D series high definition (1.3 MP) stereo vision top-mounted dome network cameras Figure 6 DH-IPC-HD4140X-3D series cameras NOTE... - Page 11 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) Angle-mounting manner: Installation Maximum detection Installation angle Focal length Height width Maximum detection 30-70° 2.1 mm 2.2-3.3 m width 5 m Maximum detection 30-70° 2.8 mm 2.5-3.8 m width 4 m Angle-mounting-the pairing of parameters is given as follows: Installation Installation...
- Page 12 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) mind, an arming specification list is given as follows for reference: An arming list of top-mounted 4140 stereo vision cameras factoring in top door edge blocking The horizontal distance between the camera and Segment (mm) FOV (°) Height range (m)
- Page 13 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) The optical axle of the camera lens form an 80-90° angle with the ground, and 2.5-3.8 m above the ground. Keep the underneath of the lens horizontal as much as possible for easy calibration and counting.
- Page 14 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) Angle-mounting instructions: Figure 11 Angle mounting of (DH) IPC-HD4140X-3D-0210B When angle-mounting the camera, make sure the optical axle of the camera lens forms an angle with the horizontal plane from 30° to 70°, the larger the better in this range. Install the camera at 2.2-3.3 m;...
- Page 15 In calibration, draw a large frame if possible to frame the ground inside. If abnormal data keeps coming up, contact Dahua’s after-sales service; 5. Use this device where there is sufficient lighting;...
-
Page 16: Configuring Images
DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) III. Configuring Images The monocular passenger flow system comprises traditional bullet cameras and can also be used as a traditional camera system for surveillance. In outdoor and angle-mounting applications where the monocular passenger flow system is installed, you likely have to handle backlight and low luminance scenarios, so an additional section is dedicated to image adjustment in this situation. - Page 17 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) 4. Adjusting the overall color: The overall cast can switch to the white balance mode, which can be done with the Outdoor or Road Lamp settings. 5. In a backlight scenario, enable Backlight WDR to adjust the picture quality.
-
Page 18: Function Config
DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) IV. Function Config 8341 Stereo Vision Camera The system counts the passenger flow into and out of the detected region. When the counted passenger flow exceeds the preset alarm-triggered quantity, an alarm is triggered, followed by linked settings. - Page 19 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) People counting (1) Figure 3-2 Set the Rule to Region People Counting. Select Enable to turn on region people counting. Click Draw Area to draw the detected area in the surveillance image. For passenger flow and region people counting, drawing one closed area is enough.
- Page 20 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) Parameters Description Set up the sensitivity of triggered alarm. The higher the sensitivity, the Sensitivity easier the alarm is triggered. Maximum Set up the maximum detection height that triggers alarm when an detection object or person stands up.
- Page 21 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) The system uses People Counting to count the passenger flow into and out of the region. When the counted passenger flow exceeds the preset alarm-triggered quantity, an alarm is triggered. Select Setup >...
-
Page 22: Calibration Config
DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) Parameters Description Select Record and when an alarm occurs, the system will Record automatically record the alarm. NOTE When the alarm is over, the alarm recording will stop for an extended Record Delay period of time. -
Page 23: People Counting Report
DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) 4. People Counting Report Exports people counting data in a report. Select Setup > Event > People Counting > People Counting Report. The People Counting Report interface is displayed. See 0. Report Figure 3-5 Set up the search conditions. - Page 24 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) Parameters Description Choose Display No. to show the number of persons entering or exiting in Display No. the people counting report. Click Search to complete the report. You can export the report by clicking Export.
-
Page 25: 4140 Stereo Vision Camera
DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) 4140 Stereo Vision Camera 1. Selecting Smart Plan To enable passenger flow, turn on the icon and click Save Note: An icon turns yellow when enabled; 2. Enabling Rule After smart plan selection, enable the corresponding rule by checking StereoNumber . People counting Here are critical configuration parameters: ... -
Page 26: Calibrating Ground
DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) Maximum detection height: Objects above this height are not detected; Minimum detection height: Objects below this height are not detected; 3. Calibrating Ground After enabling the rule, set up corresponding parameters; Select Calibration Config;... - Page 27 DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) right, with the direction pointing downward; When drawing the rule direction for passenger flow counting, draft the trigger line from right to left, with the direction pointing upward; Remarks: In the case of Customer Count or Region People Counting, the rule frame needs to be determined based on the specific scenario, and can be of an irregular shape;...
-
Page 28: Notes
Calibrate a large frame as much as possible to make sure the ground is framed. If abnormal data keeps coming up, contact Dahua’s after-sale service. The tracking frame deviates from the objects. ... -
Page 29: Examples Of Wrong Installation Scenarios
DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) 2. Examples of Wrong Installation Scenarios Random flow direction Example of installation where people flow in various directions Enters: 163 Exits:150 Lighting conditions vary and are uneven Example of installation where lighting is unstable Enters:9 Exits:1... -
Page 30: Other
DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) 3. Other Passenger Flow Data Classification Software data, hardware data. Definitions Software data: The entry and exit data displayed on OSD. Hardware data: Data in the summary table of passenger flow count over days, usually not ... -
Page 31: Appendix
DH Network Camera Product Construction Instruction Manual (Passenger Flow Solution) VI. Appendix Model Monocular cameras: Types Model Shape Stereo vision HDW8341X-3D series Stereo vision eyeball camera cameras Stereo vision HD4140X-3D series Stereo vision dome camera cameras...
