InSync
L Lock Usage Instructions
Lock Usage Instructions

Unit Configuration

Unlocking your door from the outside

1. Fully insert your RFID key into the
lock port.
2. Wait until the GREEN light flashes
once.
3. Rotate the lever downward to retract
the latch bolt to open the door.

Locking and unlocking the door from the inside

To lock the door from the
inside, rotate the thumb turn to
the horizontal position.
To unlock the door from the
inside, rotate the lever
downward or return the thumb
turn to the vertical position.
Notes:
If the lever is used when the door is locked, the thumb turn will always return to the vertical position
and the door will remain unlocked. To lock the door from the outside, insert the key and wait for the
RED light to flash once.
If the door is locked from the inside and entry if made from the outside, the thumb turn will remain in
the horizontal position and the door will re-lock in approximately five seconds.
All information contained herein, including but not limited to product pricing and other intellectual property, is confidential and
intended for the sole use of the addressee(s) so named. Any misuse of this confidential information contained herein may result in
legal action by Computerized Security Systems dba SAFLOK and its parent company.
© SAFLOK™
InSync
L
®
1
x E
r e t
r o i
Locked
Unlocked
Locked
Unloc ked
Interior
Pg. 1 of 2
2
3
E xterior
x E
r e t
r o i
Interior Views
Interior
Unlocked T humb-T urn P osition
WL 5/7/2008
Locked
