Quickstart Guide

Social distancing with your ZEISS CIRRUS: Extended cable connection

This Quickstart Guide provides an overview on how to setup and operate CIRRUS using an extended cable connection.

This option is intended for the Operator and Patient to be in the same room at a safe distance. You will need a table,

monitor, extended cable, keyboard, and mouse.

Step 1

Power down your CIRRUS.

Step 3

Once you remove the backcover, the available ports for

connection will be exposed.

Step 2

Remove back cover from Instrument by pressing down on

two tabs.

Step 4

Locate the port you will use to connect your device.

(Please see available ports in the Compatibility section

of this Quickstart Guide).

Table of Contents

Need help?

Do you have a question about the CIRRUS and is the answer not in the manual?

Page 1 Social distancing with your ZEISS CIRRUS: Extended cable connection This Quickstart Guide provides an overview on how to setup and operate CIRRUS using an extended cable connection. This option is intended for the Operator and Patient to be in the same room at a safe distance. You will need a table, monitor, extended cable, keyboard, and mouse.
Page 2 Available Ports and Compatibility and Recommended Cable Lengths If you would like to operate your CIRRUS at a safe social distance, you have the option to use peripheral accessories to help you do so. All you need is an external monitor, keyboard, and mouse.
Page 3 For complete operating instructions, warnings, cautions, and important safety information, refer to the CIRRUS Instructions for Use. Please always refer to User Manual for any further instruction on operation of device. EN_31_025_0407I;CIR.12396 ©Carl Zeiss Meditec, Inc. 2020. All rights reserved.
