- Page 1 FO-14M44 4 x 4 HDMI MATRIX INSTRUCTION MANUAL...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Controls And Functions
DESCRIPTION - 4 x 4 HDMI matrix (4 inputs x 4 outputs) with remote control. It allows the connection of up to 4 HDMI input signals and individual selection of the input to be sent to each of the HDMI outputs to be visualized in 4 monitors, conditioning the signal for optimum playback through the EDID function. -
Page 5: Remote Control
REMOTE CONTROL 1.- Matrix on/standby mode button. 2.- Buttons for assigning the required input in output A. 3.- Buttons for assigning the required input in output B. 4.- Buttons for assigning the required input in output C 5.- Buttons for assigning the required input in output D. CONNECTION AND OPERATING - Connect the HDMI signal sources to the matrix INPUT. - Page 6 RS-232 COMMUNICATION It is possible to control the FO-14M44E HDMI matrix with the software available on our website www.fonestar.com. In order to do so, download the software in your computer and then, connect the matrix to the computer using the serial port with the cable provided.
-
Page 7: Technical Specifications
TECHNICAL SPECIFICATIONS FO-14M44E CHARACTERISTICS 4 x 4 HDMI matrix. Compatible with 4k x 2k, Full HD 1080p, Full 3D. EDID function, automatically or manually selects optimum resolution for all TVs. Remote control. Communication protocol through port RS-232. HDMI amplifier bandwidth 2.97 Gbps. -
Page 8: Warranty
2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
