- Page 1 MPX-8800 ALLOCATION MATRIX WITH 8 INPUT CHANNELS TO 8 OUTPUT ZONES N Instruction Manual...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Controls And Functions Front Panel
DESCRIPTION The MPX-8800 model is a preamplifier with allocation matrix. It has 8 inputs channels to 8 output zones with independent volume control, increasable to 32 zones. There are 8 output zones with independent volume control and line level outputs for amplifying each zone separately. -
Page 5: Back Panel
18.- LED power indicator. BACK PANEL 1.- AC power supply socket. 2.- INPUT VOLTAGE SELECTOR: power supply voltage selector between 115 and 230 V AC. 3.- EXTENSION LINK: data input and output connectors, for amplifying the system with several MPX-8800 - 5 -... - Page 6 If there is only one matrix model MPX-8800, this selector must be moved to the MASTER position. The rest of the matrices must be set in the SLAVE 1, SLAVE 2 and SLAVE 3 positions in the case of the system having 16, 24 or 32 zones respectively.
- Page 7 8.- FIRE ALARM CONTACT CLOSURE: for activating the alarm with priority in each zone independently. On closing these contacts an alarm siren will go off in the selected zone, with selectable volume using the TONE OUTPUT control. Euroblock terminals. 9.- EVAC FIRE SYSTEM INTERFACE: euroblock terminals for selecting the emergency tone using contact closure and emergency power supply selection.
- Page 8 It is possible to set up systems from 8 to 32 zones with the MPX-8800 model matrix. The basic 8-zone system consists of just one MPX-8800 mod. matrix. The matrix needs to be set up as MASTER using the selectors on the back panel. In this case up to 8 selectable inputs, 8 remote sources, 2 microphones with zone selector mod M-880, 1 dynamic microphone with priority, 8 remote controls mod.
- Page 9 All the input connections must be made in the MASTER matrix and the remote sources must be connected to each one of the corresponding zones. The connection of a 4-matrix model MPX-8800 system with a total of 32 output zones appears below: - 9 -...
- Page 10 If the output zones have the zone control model MCR-90E, it is also possible to connect the remote source directly to the microphone or line inputs integrated in the control itself. Remember to disconnect the input on the back panel of the matrix model MPX-8800 and check that the ENABLE control on the back panel is active.
-
Page 11: Rs-485 Communication Protocol
The musical source can be selected for each one of the zones separately from the front panel on the matrix or from the remote control. These audio inputs must be connected to the MPX-8800 model matrix set up as MASTER. - Page 12 AA = Start of instruction. Always 0xAA. XX = Instruction identifier. PAYLOAD = Charge data for the instruction, it could be 1 or 2 bytes depending on the instruction. AM = date checksum. TYPES OF INSTRUCTION Data request from the matrix to the M-880 model microphones. XX = 0 x10 PAYLOAD = 0x00 Data sending from the M-880 model mics.
-
Page 13: Specifications
SPECIFICATIONS MPX-8800 CHARACTERISTICS Preamplifier with allocation matrix for 8 input channels to 8 output zones with independent volume control, can be increased to 32 zones. 8 output zones with independent volume control, display for showing the selected source, microphone volume and background music. -
Page 14: Declaration Of Conformity
This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los...
