Error and Status Register summarizes the valid status and error value for all the CF-ATA Command set.

SMART Command Set

SMART Command Set
D0h Read Data
D1h Read Attribute Threshold
D2h Enable/Disable Autosave
D3h Save Attribute Values
1. If reserved size is below the Threshold, the status can be read from Cylinder register by Return Status command
(DAh).
Transcend Information Inc.
1 3 3
1 3 3
1 3 3
SMART Feature Register Values
D4h Execute OFF-LINE Immediate
D8h Enable SMART Operations
D9h Disable SMART Operations
DAh Return Status
80
133X CompactFlash Card
