- Page 1 SA650ECO ROBOTIC MOWER ROBOT-TONDEUSE Notice originale Original Instructions MÄHROBOTER ROBOTMAAIER Originele handleiding Originalbetriebsanleitung ROBOT KOSZĄCY ROBOSEKAČKA Oryginalna instrukcja Originální návod...
- Page 2 Read this manual carefully prior to assembling and operating the Robotic Mower. It is dangerous to operate this product without being familiar with these instructions. Keep this manual in a safe place and have it ready for future reference.
- Page 3 INTRODUCTION SA650ECO Original Instructions Congratulations on the purchase of your new machine. During production, this device has been checked for quality and subject to a final inspection. The functionality of your equipment is therefore guaranteed. It cannot be ruled out that residual quantities of water or lubricants CONTENT will remain on or in the equipment/hose lines in isolated cases.
- Page 4 GENERAL DESCRIPTION TECHNICAL DATA Overview Model SA650ECO Max cutting area 650 m The illustration of the principal functioning parts can be found on the front and 862615 / 862621 18650-20Q / 20R Battery back foldout pages. Lithium-Ion battery, 28 V/2.0 Ah, 56Wh...
- Page 5 SAFETY PRECAUTIONS SAFETY PRECAUTIONS This section covers the basic safety instructions when working with this machine. Danger of injury due to flung-out material! Keep bystanders well away from the machine. General notes on safety This machine can cause serious injury if it is WARNING - Do not ride on the machine.
- Page 6 SAFETY PRECAUTIONS SAFETY PRECAUTIONS Warning Symbols on the switching power supply Rated maximum ambient temperature 45 Warning! The charger is for indoor use only. Before use, refer to the corresponding paragraph in the manual. Warning Symbols on the battery pack Double insulation Batteries contain Li-Ion and should not be disposed with general household waste.
- Page 7 SAFETY PRECAUTIONS SAFETY PRECAUTIONS Additional safety instructions for Robotic Mowers Secondly, ensure that the main power switch (11) is switched OFF before you lift up the Robotic Mower. Do not store anything heavy on the top of the Robotic Mower or docking station both during storage or when in use.
- Page 8 SAFETY PRECAUTIONS SAFETY PRECAUTIONS Lightning Protection • Never allow children, persons with reduced physical, In order to prevent lightning damage to the machine, do sensory or mental capabilities or lack of experience not place the docking station under tall trees. and knowledge or people unfamiliar with these instructions use the machine.
- Page 9 SAFETY PRECAUTIONS SAFETY PRECAUTIONS Use: Work interruptions: • Never operate the machine with defective guards or • After the machine has been turned off, the cutting without safety devices, for example deflectors and/or cylinder will continue to rotate for a few seconds. grass catchers, in place.
- Page 10 SAFETY PRECAUTIONS SAFETY PRECAUTIONS • Only use spare parts and accessories that have been • Always keep the extension cable well away from the supplied or recommended by the manufacturer. The cutting tools. If the power cable becomes damaged during work, instantly disconnect the power cable use of alien parts results in the immediate loss of all from the mains.
- Page 11 SAFETY PRECAUTIONS SAFETY PRECAUTIONS Robotic Mower basic operating principles • In the event of leakage of electrolyte, flush with water/ neutralising agent, seek medical help if it comes into • The Robotic Mower chooses its working direction contact with the eyes. randomly.
- Page 12 SAFETY PRECAUTIONS SAFETY PRECAUTIONS • If you need a narrow corridor to connect two patches of Locating the docking station lawn within the boundary, the corridor should be at least • When the battery is running low, the Robotic Mower 2 metres wide and max.
- Page 13 Below is a table showing the signal distances for each Robotic Mower. Please note your model and use this information as your guide when designing the boundary Home layout. Start Model Max field Max. distance to wire SA650ECO 650 m 12 m...
- Page 14 SAFETY PRECAUTIONS SAFETY PRECAUTIONS • Do not use the Robotic Mower during lightning or Robotic Mower cutting information thunder storms. In case of damage to the electronic • The Robotic Mower has a cutting height setting between circuitry, unplug the docking station and - if possible - 20 mm to 60 mm.
- Page 15 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Installation Guide Trees This chapter explains how to install the Robotic Mower. Please read this completely before The Robotic Mower treats trees as common obstacles, but if the roots of the tree are exposed you start the installation. and lower than 100mm, this area should be excluded using boundary wire in order to protect the tree root, cutting blades or rear wheels from damage.
- Page 16 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS The boundary wire should never run perpendicular to a gradient of more than 10°. If the driveway and lawn are at the same level, feel free to use the boundary wire to create a Likewise, please allow a corridor of at least 2m between a 10° or steeper slope and the boundary corridor.
- Page 17 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Flowerbeds Ponds and Pools Use the boundary wire to exclude any flowerbeds from the cutting area. There are two options While the Robotic Mower is protected against rain and spray water, being submerged is likely to cause severe damage to the electronic parts. for the two lengths of boundary wire running between the flowerbed and the outer boundary: Therefore, it is imperative to exclude any pools from the cutting area.
- Page 18 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Keep in mind that flowers, bushes and surrounding shrubbery will change in size over a season. The docking station (5) must be placed on a flat surface, at ground level. Please allow sufficient space between boundary wire and other plants to avoid interference year- around.
- Page 19 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Pegging out the boundary wire Do not place the docking station too close to a slope, such as at the top of a hill or the bottom of a furrow. Avoid left and right inclination in excess of 5 degrees. We strongly recommend mowing the lawn to 60 mm or less before laying out the boundary wire.
- Page 20 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Prepare the boundary wire for the docking station Only use the included waterproof boundary wire connectors (17) to join together two pieces of boundary wire. Use a wire stripper to remove 10-15 mm insulation from each end. Twist the threads tight.
- Page 21 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS After connecting the “F” and "B" connectors to the docking station, the docking station Press down on the large STOP button (2) to open the top cover and access the controls. can be fixed down with the boundary pegs. Activate the button marked "...
- Page 22 OPERATION OPERATION Control Panel Lock Control panel will be locked when the Robotic Mower is restarted using the mains power switch. Once the Robotic Mower is fully charged, it is ready for programming. While the default factory settings will suit the majority of users, it is worth familiarising yourself with the options available.
- Page 23 OPERATION OPERATION Status indicator LEDs Working time setting Lift signal A red LED above this symbol shows that the lift sensor has triggered. The above buttons let you choose the mower's daily working hours. Please refer to the below table for the recommended working time per day, depending on the Note: Vibrations or collisions can also trigger the lift sensor.
- Page 24 OPERATION OPERATION Edge cutting Press S1 or S2 on the control panel to match the Robotic Mower's signal to the docking station's. The button of the currently active signal is illuminated. As the first cutting action of each day, the Robotic Mower will trim the lawn edge. Therefore, while cutting, it follows the boundary wire in clockwise direction.
- Page 25 CLEANING/MAINTENANCE CLEANING/MAINTENANCE Preparing for spring Work that has not been described in these instructions must be carried out by a servicing agency authorised by the manufacturer. Only use original parts. After winter storage, please clean the charging contacts on both the Robotic Mower and the docking station.
- Page 26 CLEANING/MAINTENANCE CLEANING/MAINTENANCE Cleaning the underside Your Robotic Mower has three blades, fixed to the blades disk. Unless damaged by hard obstacles, these blades can last for up to five months of everyday Ensure the main power switch (11) is in OFF position. Wear protective gloves. Turn the Robotic use.
- Page 27 CLEANING/MAINTENANCE TROUBLESHOOTING Troubleshooting for the docking station Description Blue light on Normal Blue flash, Red off Docking station internal error, boundary wire OK Docking station OK; boundary wire connection is poor or the Red flash, Blue off Robotic Mower is charging. Docking station internal error;...
- Page 28 3. Check if the boundary wire is connected in (Robotic Mower placed Description: 28V Robotic Mower the correct direction. inside boundary area.) Model No. SA650ECO 4. Disconnect the boundary wire from the Function: Cutting grass docking station, and reconnect it the opposite way.
- Page 29 Escrick, York YO 19 6FD Declare that the product: Declare that the product: Description: 28V Robotic Mower Description: 28V Robotic Mower Model No. SA650ECO Model No. SA650ECO Function: Cutting grass Function: Cutting grass Conforms to the following directives and standards...
