- Page 1 Model SA600H ROBOMOWER Original Instructions Hotline: +49(0)2154 8253 251006 Fax : +49(0)2154 8253 251007 Mail: yardforce@merotec-service.de www.yardforce.de Merotec GmbH Hanns-Martin-Schleyer-Str. 18a 47877 Willich / Deutschland...
- Page 2 Read this manual carefully prior to assembling and operating the Robomower. It is dangerous to operate this product without being familiar with these instructions. Keep this manual in a safe place and have it ready for future reference.
- Page 3 INTRODUCTION SA600H Original Instructions Congratulations on the purchase of your new device. During production, this equipment has been checked for quality and subject to a final inspection. The functionality of your equipment is therefore guaranteed. It cannot be ruled out that residual quantities of water or lubricants CONTENT will remain on or in the equipment/hose lines in isolated cases.
- Page 4 GENERAL DESCRIPTION TECHNICAL DATA Overview Max cutting area 600 m 862615 18650-20Q Battery The illustration of the principal functioning parts can be found on the front and Lithium-Ion battery, 28 V/2.0 Ah, 56Wh back foldout pages. FY3201500 Power supply Input 100-240V AC, 50/60 Hz Robomower x 1 Output 32 V DC, CC1.5A STOP button...
- Page 5 SAFETY PRECAUTIONS SAFETY PRECAUTIONS This section covers the basic safety instructions when working with this machine. Danger of injury due to flung-out material! Keep bystanders well away from the machine. General notes on safety This machine can cause serious injury if it is WARNING - Do not ride on the machine.
- Page 6 SAFETY PRECAUTIONS SAFETY PRECAUTIONS Warning Symbols on the charger Warning Symbols on the battery pack Warning! Batteries contain Li-Ion and should not be disposed with general household waste. Contact your local authority for disposal advice. Before use, refer to the corresponding paragraph in the manual.
- Page 7 SAFETY PRECAUTIONS SAFETY PRECAUTIONS Additional safety instructions for Robomowers Secondly, ensure that the main power switch (11) is switched OFF before you lift up your Robomower. Do not store anything heavy on the top of the Robomower or charging station both during storage or when in use. Never use the device if the main power switch (11) is damaged or does not work properly.
- Page 8 SAFETY PRECAUTIONS SAFETY PRECAUTIONS Lightning Protection • Never allow children, persons with reduced physical, In order to prevent lightning damage to the machine, do sensory or mental capabilities or lack of experience and knowledge or people unfamiliar with these not place the charging station under tall trees. instructions use the machine.
- Page 9 SAFETY PRECAUTIONS SAFETY PRECAUTIONS • If the blades no longer cut correctly or if the motor is • Do not use the Robomower with defective blade discs, overloaded, check all the parts of your equipment and body, defective blades, screws, nuts etc. replace the worn parts.
- Page 10 SAFETY PRECAUTIONS SAFETY PRECAUTIONS • Inspect the machine before each use. Never operate • Before each use, carry out a visual inspection of the the machine if safety devices (e.g. impact protector, power and extension cord for any signs of damage parts of the cutting facility or bolts) are missing, worn or ageing.
- Page 11 SAFETY PRECAUTIONS SAFETY PRECAUTIONS • Ensure that batteries are charged using the charger Robomower basic operating principles supplied or recommended by the manufacturer. • The Robomower chooses its working direction randomly. Incorrect use may result in electric shock, overheating It will mow your garden completely without leaving or leakage of corrosive liquid from the battery.
- Page 12 SAFETY PRECAUTIONS SAFETY PRECAUTIONS • If you need a narrow corridor to connect two patches of Locating the charging station lawn within the boundary, the corridor should be at least • When the battery is running low, the Robomower 2 metres wide and max. 8 m long. will automatically return to the charging station.
- Page 13 > 10 m Below is a table showing the signal distances for each Robomower. Please note your model and use this information as your guide when designing the boundary layout. Model Max field Max. distance to wire SA600H 600 m 12 m...
- Page 14 SAFETY PRECAUTIONS SAFETY PRECAUTIONS NOTE! When the working area is less than 100 m total boundary wire less than 40 m, please integrate the supplied 10 Ω / 20 W cement resistance to the boundary wire. ＜100 m • Do not use the Robomower during lightning or thunder storms.
- Page 15 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Installation Guide Trees This chapter explains how to install the Robomower. Please read this completely before you Uneven lawn areas may cause the blades to touch the ground. We recommend leveling lawn before using your Robomower or excluding uneven areas with he boundary start the installation.
- Page 16 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS The boundary wire should never run perpendicular to a gradient of more than 10°. If the driveway and lawn are at the same level, feel free to use the boundary wire to create a Likewise, please allow a corridor of at least 2m between a 10° or steeper slope and the boundary corridor.
- Page 17 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Flowerbeds Ponds and Pools Use the boundary wire to exclude any flowerbeds from the cutting area. There are two While the Robomower is protected against rain and spray water, being submerged is likely to options for the two lengths of boundary wire running between the flowerbed and the cause severe damage to the electronic parts.
- Page 18 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Keep in mind that flowers, bushes and surrounding shrubbery will change in size over a season. The included supply cord has a length of 9 m. Please keep sufficient space between boundary wire and other plants to avoid interference year- The charging station (5) must be placed on a flat surface, at ground level.
- Page 19 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Pegging out the boundary wire Do not place the charging station too close to a slope, such as at the top of a hill or the bottom of a furrow. Avoid left and right inclination in excess of 5 degrees. We strongly recommend mowing the lawn to 60 mm or less before laying out the boundary wire.
- Page 20 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Prepare the boundary wire for the charging station Only use the included waterproof boundary wire connectors (17) to join together two pieces of boundary wire. Use a wire stripper to remove 10-15 mm insulation from each end. Twist the threads See below for some further sketches giving more distance guidelines.
- Page 21 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS After connecting the “F” and "B" connectors to the charging station, the charging station Press down on the large STOP button (2) to open the top cover and access the controls. can be fixed down with the boundary pegs. Activate the button marked "...
- Page 22 Flashing ! This means “Outside”.In this case Robomower stops cutting. Set key: To enable a certain function or start adjust machine setting. Lift signal Home key: The YARD FORCE Robomower will go directly to charge when you Home press Home button.
- Page 23 OPERATION OPERATION Battery and charging Security PIN code This symbol means the battery has a remain capacity of 100%. This symbol means the battery has a remain capacity of 75%. This symbol means the battery has a remain capacity of 50%. This symbol means the battery has a remain capacity of 30%.
- Page 24 OPERATION OPERATION Set cutting time Press S1 or S2 on the touch screen, make sure it same with charging station wire connection. Note: please set the time and date before any other setting operation. Set the weekday and daytime you want by touching the information on the screen. The Cutting currently selected days and times are framed.
- Page 25 OPERATION OPERATION Charging Unlock After successfully dock into the charging station, the symbol will flash. Meanwhile, the Note: When the user press down “Stop” button and the open the top cover, the screen battery symbol will display step by step with reference to the is locked.
- Page 26 OPERATION OPERATION When all three button has been pressed down wait the screen display change to the PIN Press still and then press , it will display: code page. Input old PIN code, when display The left digits show the fault happen time. Right digits, circled by dots show the fault code. Rain sensor Mowing in the rain is not recommended.
- Page 27 CLEANING/MAINTENANCE OPERATION Charging Information Work that has not been described in these instructions must be carried out by a servicing agency authorised by the manufacturer. Only use original parts. The Mower will go back to charging station by itself along the boundary wire in the following Maintenance situations: When you press the Home button and close the keypad top cover, Robomower will go...
- Page 28 CLEANING/MAINTENANCE CLEANING/MAINTENANCE Preparing for spring Cleaning the underside Ensure the main power switch (11) is in off position. Wear protective gloves. Turn the After winter storage, please clean the charging contacts on both the Robomower and the Robomower onto its side to expose its underside. Clean the blade disc and frame using a soft charging station.
-
Page 29: Replacing The Battery
CLEANING/MAINTENANCE CLEANING/MAINTENANCE Your Robomower has three blades, fixed to the blades disk. Unless damaged by hard obstacles, these blades can last for up to five month of everyday use. Weekly inspection of the blades and the fixing screws is required. Note that the blades are double-edged. - Page 30 TROUBLESHOOTING TROUBLESHOOTING Troubleshooting For Charging Station Type of No. Message Symptom Action message Check if there is high power cable Description close to Boundary wire or underneath Blue light on Normal it, if there is then avoid the area by Blue flash, Red off Charging station internal wire break, main Boundary is OK The mower turns...
- Page 31 TROUBLESHOOTING TROUBLESHOOTING Type of Type of No. Message Symptom Action No. Message Symptom Action message message Check if the charging station indicator This message is light is blue. Warning Please take mower to flat area and run only display in error Check if charging station is connected message again.
- Page 32 TROUBLESHOOTING TROUBLESHOOTING Hot key Type of No. Message Symptom Action message Normally if voltage is low, the mower Hot key operation Function should automatically return to the Battery voltage is Warning charging station. Display software version number too low to perform message If not, please carry your mower normal mowing...
- Page 33 To the provisions of Council Directives MEROTEC GmbH Hanns-Martin-Schleyer-Str. 18a 47877 Willich / Germany Declare that the product: Machine Description: Robomower Machine Type: SA600H Charger Model: FY3201500 Function: Cutting grass Complies with essential health and safety requirements of the following directives: EC Machinery Directive: 2006/42/EC EC Directive of Electromagnetic Compatibility 2014/30/EU EC Noise Directive 2000/14/EC &...
