Access the custom setting
The number following the FAT
is the available memory for
logging.
Set the logging interval, or turn
off logging. The interval can
be set as 1sec, 5sec, 10sec,
15sec, 30sec, 1min., 2min,
5min, 10min, 20min and 30min.
Disable means turn off the
logging.
10 sec. is the default.
Turn on the Bluetooth
connection or turn it off.
CH GMAX ** means the name
of the device. The name can
be set as 00, 01, 02, 03, 04,
05, 06, 07, 08, 09, 10, 11, 12,
13, 14, and 15.
The number following the bAT
is the current voltage of the
battery.
The number following the SAT
is the firmware version of the
GPS/BDS chip.
The number following the bLE
is the version of the Bluetooth.
Restore the receiver to factory
settings.
20
