Summary of Contents for SystemAir Topvex RB-CEM15
- Page 1 Pre-heater Topvex counterflow units Installation instructions Document in original language | 134351 · A003...
- Page 2 134351 | A003...
-
Page 3: Table Of Contents
Contents Warnings............1 General ............1 Installation.............1 Outdoor air sensor ........1 Wiring diagram ........2 Corrigo..........3 134351 | A003... -
Page 5: Warnings
General A a pre-heater is available as an accessory for Systemair Topvex units with counterflow heat exchanger. A pre-heater can be installed in the outdoor duct to prevent icing in the heat exchanger. The kit contains of 1 expansion module, 1 pre-heater, 1 outdoor air sensor and 1 instruction. -
Page 6: Wiring Diagram
| Installation Wiring diagram CB 250-90-3-MQXL Corrigo CB 315-90-3-MQXL CEM15 CB 400-120-3-MQXL 400V 3N~ G G0 Fig. 2 Wiring CB-CEM15 RB 50-25-12-MQXL RB 50-30-17-MQXL RB 60-30-17-MQXL Corrigo RB 60-40-21-MQXL CEM15 RB 60-50-27-MQXL 400V 3N~ G G0 Fig. 3 Wiring RB-CEM15 * See chapter 3.1 Blue Orange... -
Page 7: Corrigo
Installation | Corrigo Function via expansion unit. Log on with admin rights in Corrigo. Main menu item Sub-menu item 1 Sub-menu item 2 Explanations → Access rights → Log on Log on Log on to service level by entering Enter password xxxx a 4-digit code. - Page 8 | Installation Example 1: Run if defrosting. If pre-heater is used in order to maintain supply temperature at desired level. For example, desired supply temperature is +20°, the outside air is -4° and the heater has an capacity of 10°. This is enough during normal operation on these units but during bypass defrosting the heater needs an capacity of 24°.
- Page 9 134351 | A003...
- Page 10 Systemair Sverige AB Industrivägen 3 SE-739 30 Skinnskatteberg, Sweden Phone +46 222 440 00 Fax +46 222 440 99 www.systemair.com...
