- Page 1 Grove - LCD RGB Backlight Release date： 9/20/2015 Version： Wiki: http://www.seeedstudio.com/wiki/Grove_-_LCD_RGB_Backlight Bazaar: http://www.seeedstudio.com/depot/Grove-LCD-RGB-Backlight-p-1643.html...
- Page 2 Document Revision History Revision Date Author Description Sep 21, 2015 Victor.He Create file...
-
Page 3: Table Of Contents
Contents Document Revision History · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2 1. - Page 4 Under the supervision of Seeed Technology Inc., this manual has been compiled and published which covered the latest product description and specification. The content of this manual is subject to change without notice.
-
Page 5: Introduction
1. Introduction Done with tedious mono color backlight? This Grove enables you to set the color to whatever you like via the simple and concise Grove interface. It takes I2C as communication method with your microcontroller. So number of pins required for data exchange and backlight control shrinks from ~10 to 2, relieving IOs for other challenging tasks. -
Page 6: Specification
2. Specification Input Voltage Operating Current <60mA CGROM 10880 bit CGRAM 64*8 bit Colorful RGB Backlight Built-in English and Japanese fonts I2C communication, uses only two IOs Automatic power-on reset Suli-compatible Library... -
Page 7: Demonstration
3. Demonstration This demonstration will show you how to use Grove - LCD RGB Backlight, we need a Seeeduino V3.0 else. Hardware Installation Hardware installation is very easy, because there's an I2C Grove in Seeeduino, so what we need to do is connect it to I2C Grove via a Grove cable. -
Page 8: Change Color Of Backlight
Change Color of Backlight One of Grove - LCD RGB Backlight's most important feature is: you can change the color backlight, and it's a very simple thing, just use the following function: void setRGB(int Then let's try a Red backlight. Modify the code about color into: const int colorR... -
Page 9: Run The Program
# Grovepi + grove RGB LCD module # Example for using the Grove I2C color LCD from grove_rgb_lcd import while(True): setText("Hello world\nLCD test") setRGB(0,128,64) c in range(0,255): setRGB(c,255-c,0) time.sleep(0.01) setRGB(0,255,0) setText("Bye bye, this should wrap") time.sleep(1.5) 3.4.1 Run The Program Find the path to the file(According to your own path) cd GrovePi/Software/Python/grove_rgb_lcd/... - Page 10 Run program: sudo python example.py...
-
Page 11: Related Projects
4. Related Projects The best way to learn something, is to create a project with it. Recipe Community is a place which gathers a lot of amazing projects with step-by-step tutorials. Makers in the community have made a lot of awesome projects with the Grove - LCD RGB Backlight, check this out! Pringles Can antenna with a LinkIt ONE Make a focused antenna with a pringles can. -
Page 12: A Smart Home Monitoring Equipment By Bbg
A Smart home monitoring equipment by BBG Get to know the temperature and pressure around you with a smart DIY home monitor I want make one! Find out even more awesome projects on Recipe. -
Page 13: Share Your Awesome Projects With Us
We cooperate with our Core Users in the development of our new product, which in another word, the Core Users will have the chance to experience any new products of Seeed before its official launch, and in return we expect valuable feedback from them to help us improving the product performance and user experience. -
Page 14: Resources
6. Resources Library LCD Datasheet BackLight Datasheet...
