Assembly Instructions for TV Trolley Stand
V1.0
PSTVMCO4
Thank you for choosing our product! We strive to provide the best quality
and services for our customers. Would you kindly share your experience
on Amazon if you are satisfied? Should you have any issues, please don't
hesitate to contact us.
Telephone：800-5566-806 Mon-Fri 10am - 6pm (PST) (USA) (CAN)
Email：supportus@perlesmith.com (US/CA/DE/UK/FR/IT/ES/JP/AU)
Advertisement
Related Manuals for Perlesmith PSTVMCO4
Summary of Contents for Perlesmith PSTVMCO4
- Page 1 Assembly Instructions for TV Trolley Stand V1.0 PSTVMCO4 Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satisfied? Should you have any issues, please don't hesitate to contact us.
-
Page 2: Supplied Parts
Thanks for choosing our stand. This stand was designed for mounting flat panel televisions weighing up to 25 kg. The height of TV can be easily adjusted. The integrated wheels provide ease of movement. Safety Warning: If you do not understand these directions, or have any doubts about the safety of the installation, please call a qualified contractor. - Page 3 Picture Description Quantity M6x60 allen head bolt M6 socket plate M6x10 allen head bolt Shelf support connecting plate Shelf Shelf support M6 nut Square plate connector & Rubber Pad Square plate M6 washer TV arm set Tool kit M4x30 bolt M6x15 bolt(x4) M6x30 bolt(x4)
- Page 4 Picture Description Quantity M8x15 bolt(x4) M8x45 bolt(x4) M4 washer M6 washer M8 washer M4 spacer M6/M8 spacer(5mm) Step 1 Install Wheels On The Square Tube Use Tool Kit(21) Attach wheels (9) to the long and short square tube (1, 2) by using the provided wrench (21) Turn this nut to adjust the height of wheel.
- Page 5 Step 2 Attach Square Tubes Use Tool Kit(21) Attach the square tubes (1, 2) to the tube connection (3) by using M6x60 bolts (10) and socket plate (11) Step 3 Attach Tube Connector Cover And Poles Use Tool Kit(21) 1.Attach tube connector cover (4) to the tube 2.Attach the base pole (5) to the tube connector (4) by using M6x10 bolts (12).
- Page 6 Step 4 Attach Shelf To Pole Use Tool Kit(21) Use Tool Kit(21) 240mm 12 13 Attach shelf connecting plate (13) to the Attach shelf supports (15) to the shelf (14) pole (5) by using M6x10 bolts (12) by using M6 nuts (16) Use Tool Kit(21) Attach shelf (14) to the shelf connecting plate (13) by using M6x10 bolts (12)
- Page 7 Step 5 Attach Square Plate Attach the square plate (18) by using M6x10 bolts (12) and M6 washers (19) Put the rubber pad in the square plate connector (17) then use tool kit tighten Use Tool Kit(21) the small hole Use Tool Kit(21) Step 6 Secure The TV Brackets Screw and washer...
-
Page 8: Step 8 Wire Management
Step 7 Secure Your TV Tighten the safety bolt on the bottom of the TV brackets Hang the TV on the plate Safety bolt Step 8 Wire Management Option A... - Page 9 Option B Option C...
