Westin OUTLAW NERF STEP BARS Installation Instructions

Westin OUTLAW NERF STEP BARS Installation Instructions

2005-2019 toyota tacoma double cab

Advertisement

ITEM
QUANTITY
1
1
2
1
3
1
4
1
5
1
6
1
7
1
8
1
9
12
10
12
11
12
12
12
13
12
14
12
ANTI-SEIZE LUBRICANT MUST BE USED ON ALL STAINLESS STEEL FASTENERS TO PREVENT THREAD DAMAGE AND GALLING
Passenger Side Opposite
ITEM 1
ITEM 4
Westin Automotive Products, Inc.
320 W. Covina Blvd
San Dimas, Ca. 91773
P.N.: 75-5852775-RevA
ECO #: W18-0157
APPLICATION:
PART NUMBER:
DRIVER FRONT MOUNTING BRACKET
PASSENGER FRONT MOUNTING BRACKET
DRIVER CENTER MOUNTING BRACKET
PASSENGER CENTER MOUNTING BRACKET
DRIVER REAR MOUNTING BRACKET
PASSENGER REAR MOUNTING BRACKET
ITEM 5
INSTALLATION INSTRUCTIONS
OUTLAW NERF STEP BARS
2005-2019 Toyota Tacoma Double Cab
58-52775
CONTENT
DESCRIPTION
DRIVER STEP BAR ASSEMBLY
PASSENGER STEP BAR ASSEMBLY
M8 HEX HEAD CAP SCREW
M8 SPLIT LOCK WASHER
M8 FLAT WASHER
M10 HEX HEAD CAP SCREW
M10 BELLVILLE WASHER
M10 SERRATED FLANGE NUT
ITEM 6
1
ITEM 3
ITEM 7
Thank you for choosing Westin products
for additional installation assistance please call
Customer Service (800) 793-7846
www.westinautomotive.com
TOOLS NEEDED
13MM SOCKET
13MM WRENCH
16MM SOCKET
16MM WRENCH
RATCHET
TORQUE WRENCH
ITEM 8
DATE: 04/16/19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OUTLAW NERF STEP BARS and is the answer not in the manual?

Questions and answers

Summary of Contents for Westin OUTLAW NERF STEP BARS

  • Page 1 ITEM 4 ITEM 5 ITEM 6 ITEM 7 ITEM 8 Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com P.N.: 75-5852775-RevA...
  • Page 2 5. Align and adjust the step bars and brackets as needed, then fully tighten all hardware: M8 to 18 ft-lbs, M10 to 38 ft-lbs. Fig 4 Fig 3 Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com...
  • Page 3 STAINLESS STEEL PRODUCTS CAN BE CLEANED WITH MILD SOAP AND WATER. STAINLESS STEEL POLISH SHOULD BE USED TO POLISH SMALL SCRATCHES.  GLOSS BLACK FINISHES SHOULD BE CLEANED WITH MILD SOAP AND WATER Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com...
  • Page 4 AND SAFETY. DRILLING: Most Westin products do not require drilling for installation. If drilling is defined as required, use caution when drilling a vehicle. FAILURE TO REVIEW AN AREA TO BE DRILLED MAY RESULT IN PERSONAL INJURY AND/OR INJURY TO OTHERS AS WELL AS VEHICLE DAMAGE.
