6

Manufacturing

6.1

Top and Bottom View of SIM6216C

These test points are only used for module manufacturing and testing. They are not for customer's using.
6.2

Moisture Sensitivity Level (MSL)

SIM6216C is qualified to Moisture Sensitivity Level (MSL) 3 in accordance with IPC/JEDEC J-STD-033.

Appendix

A. SIM6216C GPIOs List
Table 41: SIM6216C GPIOs list
Name GPIO Index
PCM_DIN 0
GPIO1 1
PCM_SYNC 2
PCM_CLK 3
GPIO4 4
PCM_DOUT 5
CAM_D2 6
CAM_D3 7
CAM_D4 8
CAM_D5 9
SIM6216C_Hardware Design_V1.00
Figure 46: Top and bottom view of SIM6216C
Default Function
GPIO Interrupt [LEVEL/LOW]
Status led
GPIO [IN]
GPIO [OUT/LOW]
RF Switch
GPIO [OUT/LOW]
Data bit 0 (YUV or RGB)
Data bit 1 (YUV or RGB)
Data bit 2 (YUV or RGB)
Data bit 3 (YUV or RGB)
59
Smart Machine Smart Decision
Alternate Function
PCM_DIN
GPIO
PCM_SYNC
PCM_CLK
Enable/Disable RF subsystem
PCM_OUT
GPIO
GPIO
GPIO
GPIO
2013-4-18
