Symbiote SCA Installation Instructions

INSTALLATION INSTRUCTIONS
Storage Cabinet Assemblies
Product Numbers
• SCA
Hardware Pack: included in box
1
The top of each end panel has a set of three front
and three rear holes. Install a #10-12x3/8" Phillips
pan head screw in the center hole of each set, leav-
ing a 1/8" gap between the panel and underside of
the screw head, on both the left- and right-hand end
panel.
3
Align the slots in the side flanges of the top panel
with the screws installed at the top of the end
panels. Slide the top panel down and back towards
the frame/panel.
p/n 03120306 rev C
#10-12x3/8" screw
STORAGE AND DISPLAY
Required Tools
• #2 Phillips Screwdriver or #2 Phillips Bit
• Cordless Drill/Driver
2
Install end panels on the left and right sides of the
frame/panel at the desired height. Ensure the panels
are firmly seated in the hanger frame slots.
4
#10-12x3/8" screw
Install two more #10-12x3/8" Phillips pan head screws
in the top of each end panel to lock the top panel
into position and fully tighten all screws with a #2
Phillips screwdriver/bit with driver.
SYMBIOTE.COM
sheet 1 of 2
