Installation Instructions
Mobile Pedestals
Product Numbers
•
PMD6612
•
PMD6666
•
PMD1212
1
Locate the casters and attachment screws in one of the
drawers of the pedestal. Lock or remove the drawers to
ensure that they are not damaged during caster installation.
3
Align the locking swivel casters with the diagonal spaced
holes at the front of the pedestal. Install (4) screws in the
caster plate of each caster using a #2 Phillips Screwdriver.
www.symbiote.com
300 N. Centennial Street
p/n 10012800-02
Required Tools
•
#2 Phillips Screwdriver
Hardware Pack: none
Technical Furniture
Zeeland, MI 49464
2
To avoid injury or damage to the unit use two people to flip
the pedestal upside down or place it on its side to access
the underside of the unit.
4
Repeat step #3 with the non-locking swivel casters at the
rear of the pedestal.
ph: (616) 772-1790
Storage and Display
fx: (616) 772-1797
sheet 1 of 2
