Installing the Switch—Installation du commutateur
Installing the Switch—Installation du commutateur
English
These sections explain how to install the switch. See the Hardware Installation Guide for more information.
Caution When installed in a Class I. Div/Zone 2 hazardous location environment, this equipment must be
installed in a min. IP54, ATEX certified enclosure.
Caution Airflow around the switch must be unrestricted. To prevent the switch from overheating, there must be
the following minimum clearances:
- Top and bottom: 2.0 in. (50.8 mm)
- Sides: 2.0 in. (50.8 mm)
- Front: 2.0 in. (50.8 mm)
Contact your Cisco Technical Assistance Centre (TAC) if tighter spacings are required.
Caution When installed in a Class I. Div/Zone 2 hazardous location environment. this equipment must be
installed in a pollution degree 2 environment per IEC 60664-1)
Caution This equipment is suitable for use in Class I. Division 2 . Groups A, B . C. D. or only nonhazardous
locations.
Warning Exposure to some chemicals could degrade the sealing properties of materials used in the sealed
relay device. Statement 381
Warning This unit is intended for installation in restricted access areas. A restricted access area can be
accessed only through the use of a special tool, lock and key, or other means of security. Statement
1017
To prevent the system from overheating, do not operate it in an area that exceeds the maximum
Warning
recommended ambient temperature of : 140°F (60°C) Statement 1047
Warning When you connect or disconnect the power and/or alarm connector with power applied, an
electrical arc can occur. This could cause an explosion in hazardous area installations. Be sure
that all power is removed from the switch and any other circuits. Be sure that power cannot be
accidentally turned on or verify that the area is nonhazardous before proceeding. Statement 1058
Warning In switch installations in a hazardous location, the DC power source could be located away from
the vicinity of the switch. Before performing any of the following procedures, locate the DC
circuit to ensure that the power is removed and cannot be turned on accidentally, or verify that
the area is nonhazardous before proceeding. Statement 1059
Warning This equipment is supplied as "open type" equipment. It must be mounted within an enclosure
that is suitably designed for those specific environmental conditions that will be present and
appropriately designed to prevent personal injury resulting from accessibility to live parts. The
interior of the enclosure must be accessible only by the use of a tool.
The enclosure must meet IP 54 or NEMA type 4 minimum enclosure rating standards. Statement 1063
Warning Use twisted-pair supply wires suitable for 86°F (30°C) above surrounding ambient temperature
outside the enclosure. Statement 1067
Warning When used in a Class I, Division 2, hazardous location, this equipment must be mounted in a
suitable enclosure with a proper wiring method that complies with the governing electrical codes.
Statement 1069
