Fortin EVO-CAN Suggested Wiring Configuration
Camaro, cruze, equinox, sonic, terrain, lacrosse, regal
Hide thumbs
Also See for EVO-CAN:
- Manual (11 pages) ,
- Quick start manual (6 pages) ,
- Quick start manual (5 pages)
Advertisement
Quick Links
1 / 4
Page
Camaro, Cruze, Equinox,
Sonic, Terrain, LaCrosse, Regal
ATTENTION
FIRMWARE VERSION
VERSION DU LOGICIEL
HARDWARE VERSION : 3
FIRMWARE VERSION : 4.0+
Date: xx-xx
EVO-CAN
INTERFACE MODULE
PATENTS PENDING US: 2007-228827-A1
Made in Canada
www.fortinbypass.com
Service No :
000 102 04 2536
Minimum
Sonic:
Minimum
CHEVROLET
Camaro
Cruze
Equinox
Orlando
Sonic
GMC
Terrain
BUICK
LaCrosse
Regal
Input
Entrée
Output
Sortie
INSTALLATION WITH DATA-LINK
INSTALLATION AVEC DATA-LINK
Remote
Starter/Alarm with
the Fortin Data-link
protocol.
Démarreur à
distance/alarme
avec le protocole
Data-link Fortin
4 Pin
Rev. 20120504
ADDENDUM - SUGGESTED WIRING CONFIGURATION
3.06
4.02
2010-2012
2011-2012
2010-2011
2012
2012
2010-2012
2010-2012
2011-2012
Connection always required
Branchement toujours requis
Connection not required with Data-link
Branchement non requis avec Data-Link
INSTALLATION WITHOUT DATA-LINK
INSTALLATION SANS DATA-LINK
Guide # 3306
SCHÉMA DE BRANCHEMENT SUGGÉRÉ
Connect to vehicle
Branchement au véhicule
Connect to Remote-Starter/Alarm
Branchement au démarreur à
distance/Alarme
Remote
Cut off one plug of the 4 Pin
1
Starter/Alarm
Data-Link connector
Démarreur à
2
distance/alarme
Connect the Red wire to +12V
3
Connect the Black wire to
Red | Rouge +12V
Ground
Black | Noir Ground
Coupez l'extrémité du connecteur
1
4 pins Data-Link
2
Connectez le fil rouge au 12V
4 Pin
3
Connectez le fil noir à la masse
du véhicule.
