Connection and installation

2.2.2

MicroLink dLAN USB

The MicroLink dLAN USB adapter has three indicator lights (LEDs) and a USB

port:

COL: Flashes faster as the network load increases.

ACT: Flashes when data is being sent or received over the electrical lines.

LNK: Steady when connected to power.

USB port: This is the connection point on the MicroLink dLAN USB adapter

for connecting it to a computer with the USB cable (included).

2.3

2.3.1

Before connecting the dLAN adapter please note its security ID and keep it

available for configuration of the network. The security ID can be found on the

bottom of the dLAN adapter.

devolo MicroLink dLAN Ethernet - devolo MicroLink dLAN USB

With the computer running connect the MicroLink dLAN Ethernet adapter

to an Ethernet port of the computer with the network cable (included).

Plug the MicroLink dLAN Ethernet adapter into a convenient power

socket.
