ES5350.1 Analog Board (10/20-CH)
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ES5350.1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ETAS ES5350.1

Summary of Contents for ETAS ES5350.1

  • Page 1 ES5350.1 Analog Board (10/20-CH) User’s Guide...
  • Page 2 The data in this document may not be altered or amended without special noti- fication from ETAS GmbH. ETAS GmbH undertakes no further obligation in rela- tion to this document. The software described in it can only be used if the customer is in possession of a general license agreement or single license.

  • Page 3: Table Of Contents

    Scope of Supply ..........17 Voltage Supply of ES5350.1 Plug-in Card ......17 Fuses .
  • Page 4 7 ETAS Contact Addresses ........

  • Page 5: Introduction

    Introduction This manual contains the description of the ES5350.1 plug-in card. CAUTION! Some components of the ES5350.1 plug-in card can be damaged or destroyed by electrostatic discharges. Leave the plug-in card in its transport packaging until it is installed. Only remove, configure and install the product at a workplace that is protected against electrostatic discharges.

  • Page 6: Properties

    Introduction ETAS Properties The ES5350.1 plug-in card serves as analog input and output card for the ES5300.1-A or ES5300.1-B Housing. Due to the galvanic isolation of the 10 analog input channels and the five groups each with 4 output channels, the different signals can be acquired or generated without common ground reference point while achieving exact, interference- free measurement results.
  • Page 7 Housing or the ES5300.1-B Housing is done via the ES5300 backplane connector CO200 (see "Backplane Connector CO200" on page 27). There are fuses on the ES5350.1 plug-in card to protect the supply voltages of the ES5300.1-A or the ES5300.1-B backplane. For detailed information about the fuses, see the chapter "Fuses"...

  • Page 8: Basic Safety Notices

    1.2.2 General Safety Information Please observe the Product Safety Notices ("ETAS Safety Notice") and the follow- ing safety notices to avoid health issues or damage to the device. Note The User's Guide must be read prior to the startup of the product! ETAS GmbH does not assume any liability for damages resulting from improper handling, unintended use or non-observance of the safety precautions.

  • Page 9: Intended Use

    ES5300.1-A Housing and the ES5300.1-B Housing and must not be operated as a stand-alone-unit. The intended use of the ES5350.1 plug-in card in an ES5300.1-A Housing or in an ES5300.1-B Housing is as follows: • Use as a component in industrial lab facilities or at industrial workplaces.
  • Page 10 Switch off the ES5300.1-A Housing or the ES5300.1-B Housing and external power supplies, and unplug the power plug and other connectors attached to the plug-in card. Wait at least three minutes before removing the plug-in card. ES5350.1 - User’s Guide...
  • Page 11 To avoid damages to the hardware from electrostatic discharge, please observe the following precautionary measures: CAUTION! Some components of the ES5350.1 plug-in card can be damaged or destroyed by electrostatic discharges. Leave the plug-in card in its transport packaging until it is installed.
  • Page 12 To avoid injuries and hardware damages, please observe the following precau- tionary measures: • Do not apply any voltages to the connections of the ES5350.1 plug-in card that do not correspond to the specifications of the respective connection. The exact specification of the I/O hardware is located in the manuals of the corresponding boards.

  • Page 13: Identifications On The Product

    33. 1.3.1 CE Mark With the CE mark attached to the product or its packaging, ETAS confirms that the product corresponds to the product-specific, applicable European Directives. The CE Declaration of Conformity for the product is available upon request (see "ETAS Contact Addresses"...

  • Page 14: Kc Marking

    Products Regulation) applicable in the People's Republic of China. 1.3.3 KC Marking With the KC mark attached to the product and its packaging, ETAS confirms that the product has been registered in accordance with the product-specific KCC guidelines of the Republic of Korea.

  • Page 15: About This Manual

    This chapter contains information about the design and installation of ES5350.1 plug-in card, as well as information about the fuses. • "Signals" on page 23 This chapter features a description of the signals of the ES5350.1 plug-in card. • "Connections and Connectors" on page 27 This section provides a description of the different connections and con- nectors of the ES5350.1 plug-in card and its pin assignments.
  • Page 16 A conversion between the logical Content-based highlights and newly intro- and arithmetic data types is not duced terms are placed in italics. possible. Important notes for the user are presented as follows: Note Important note for the user. ES5350.1 - User’s Guide...

  • Page 17: Design, Installation And Fuses

    You can find the scope of supply in chapter "Ordering Data" on page 36. Voltage Supply of ES5350.1 Plug-in Card The ES5350.1 plug-in card is supplied via the backplane of the ES5300.1-A or ES5300.1-B housing. The electrical connection is done via backplane connector CO200.

  • Page 18: Fuses

    The supply voltages of the backplane of the ES5300.1-A or the ES5300.1-B Housing are protected with fuses on the ES5350.1 plug-in card. In case of a fuse defect, we recommend sending the board to ETAS for further testing. For this purpose, the device should be sent to ETAS (see "ETAS Contact Addresses"...

  • Page 19: Position Of Fuses

    ETAS Design, Installation and Fuses 2.3.1 Position of Fuses Fig. 2-2 shows the position of the fuses on the ES5350.1 plug-in card. FU201 FU200 Fig. 2-2 Position of fuses on the ES5350.1 plug-in card 2.3.2 Specification of Fuses The specification of the fuses is as follows:...

  • Page 20: Installation In The Es5300.1-A And The Es5300.1-B Housing

    A description for installing the ES5350.1 plug-in card in the ES5300.1-A Housing or the ES5300.1-B housing is located in the manual for the ES5300.1-A Housing or the ES5300.1-B housing. The installation of the ES5350.1 plug-in card may be performed only by trained personnel in an ESD-safe area. CAUTION! Do not install the ES5350.1 plug-in card while the ES5300.1-A Hous-...
  • Page 21 ETAS Design, Installation and Fuses 5. Carefully push in the ES5350.1 plug-in card until the backplane connector of the ES5350.1 plug-in card is completely inserted in the socket of the backplane. Note Watch for cables in the insertion area while pushing in the board –...
  • Page 22 Design, Installation and Fuses ETAS ES5350.1 - User’s Guide...

  • Page 23: Signals

    ETAS Signals Signals This chapter features a description of the signals of the ES5350.1 plug-in card. • "Analog Inputs - I/O interface X1_ANALOG_IO" on page 23 – "Block Diagram of Analog Inputs" on page 23 • "Analog Outputs - I/O interface X1_ANALOG_IO" on page 24 –...

  • Page 24: Analog Outputs - I/O Interface X1_Analog_Io

    Analog Ground (ANA_OUT_GROUP*_GND) Fig. 3-2 Block diagram of analog outputs of the ES5350.1 plug-in card Group represents the five galvanically isolated groups (A...E) X represents the respective channel number (0...3) For more detailed information about the analog outputs, see the Technical Data in the chapter "Analog Outputs (I/O interface X1_ANALOG_IO)"...
  • Page 25 ETAS Signals ES5350.1 - User’s Guide...
  • Page 26 Signals ETAS ES5350.1 - User’s Guide...

  • Page 27: Connections And Connectors

    – "Pin Assignment - I/O Interface X1_ANALOG_IO" on page 30 Backplane Connector CO200 The connection of the ES5350.1 plug-in card to the ES5300.1-A Housing or the ES5300.1-B Housing is done via the PCIe plug connector "CO200" (Fig. 4-1 on page 27), which is used for the voltage supply (see "Voltage Supply of ES5350.1 Plug-in Card"...

  • Page 28: Pin Assignment - Backplane Connector Co200

    The assignment of the pins is located in Tab. 4-1 on the next page (the maxi- mum possible pin assignment for the ES5300.1-A Housing and ES5300.1-B Housing is listed): CO200 Fig. 4-2 Pin assignment of the plug connector CO200 to the backplane ES5350.1 - User’s Guide...
  • Page 29 GBLI_TX_n_0 GBLI_TX_p_0 GBLI_RX_n_0 GBLI_RX_p_0 M_LVDS_n_7 M_LVDS_p_7 BN_5 BN_4 12-shield GBLI_TX_n_1 GBLI_TX_p_1 GBLI_RX_n_1 GBLI_RX_p_1 M_LVDS_n_6 M_LVDS_p_6 SPI_CS_B_n SPI_CS_A_n 11-shield GBLI_TX_n_2 GBLI_TX_p_2 GBLI_RX_n_2 GBLI_RX_p_2 M_LVDS_n_5 M_LVDS_p_5 SPI_MOSI SPI_CLK 10-shield GBLI_TX_n_3 GBLI_TX_p_3 GBLI_RX_n_3 GBLI_RX_p_3 M_LVDS_n_4 M_LVDS_p_4 PCIE_WAKEn SPI_MISO 9-shield GBLI_PRESENT_n GEO_ADDR_4 PCIE_REFCLK_n PCIE_REFCLK_p M_LVDS_n_3 M_LVDS_p_3 n.c.

  • Page 30: I/O Interface X1_Analog_Io

    The following figure shows the position of the plug connector on the ES5350.1 plug-in card. X1_ANALOG_IO Fig. 4-3 I/O interface X1_ANALOG_IO of the ES5350.1 plug-in card Type: DIN 41612, type C Counterplug Type: DIN 41612 plug connector, without crimp contacts Manufacturer: e.g.
  • Page 31 Ground pins of ANA_OUT_C_GND CH[3...0] of Group C Group C ANA_OUT_C_1 A/C10 ANA_OUT_C_0 A/C9 ANA_OUT_B_3 A/C8 ANA_OUT_B_2 A/C7 analog output Ground pins of ANA_OUT_B_GND CH[3...0] of Group B Group B ANA_OUT_B_1 A/C6 ANA_OUT_B_0 A/C5 ES5350.1 - User’s Guide...
  • Page 32 For this purpose, observe the signal and ground pin mapping in Tab. 4-2 on page 32. Note The ES5350.1 does not have a separate input channel for an external reference voltage. If the output voltage range of the analog output channels shall be configured as dependent on an external reference voltage, one of the analog input chan- nels ANA_IN_0...ANA_IN_9 must be used for the external reference voltage.

  • Page 33: Technical Data And Standards

    ETAS Technical Data and Standards Technical Data and Standards This chapter contains the technical data of the ES5350.1 plug-in card. It also contains information about the norms and standards met as well as the ordering data. • "Technical Data" on page 33 –...

  • Page 34: Analog Outputs (I/O Interface X1_Analog_Io)

    Use only inside enclosed and dry rooms Max. contamination level Temperature during operation 5 °C to 40 °C (41 °F to 104 °F) Relative humidity 0% to 95% (non-condensing) Operating altitude -200 m to 2000 m above sea level ES5350.1 - User’s Guide...

  • Page 35: Norms And Standards Met

    Height Width 5 HP Weight 0,5 kg Norms and Standards met The ES5350.1 plug-in card meets the following norms and standards: Standard Test IEC 61326-1 Electrical equipment for measurement, control and laboratory use – EMC requirements (industrial setting) IEC 61010-1...

  • Page 36: Ordering Data

    Ordering Data ETAS Ordering Data The ordering data for the ES5350.1 plug-in card are as follows: Order name Short name Order number Analog board (10/20-CH) ES5350.1 F-00K-110-272 Calibration Service for ES5350 K_ES5350 F-00K-110-270 Scope of Supply Quantity Analog board (10/20-CH)

  • Page 37: Etas Contact Addresses

    Germany WWW: www.etas.com ETAS Subsidiaries and Technical Support For details of your local sales office as well as your local technical support team and product hotlines, take a look at the ETAS website: ETAS subsidiaries WWW: www.etas.com/en/contact.php ETAS technical support WWW: www.etas.com/en/hotlines.php...
  • Page 38 ETAS Contact Addresses ETAS Es5350 - User’s Guide...

  • Page 39: Index

    ETAS Index Index Accident prevention 9 Ordering data Application areas 5 Backplane connector CO200 27 ES5350.1 plug-in card 36 Fuses 19 CE Declaration of Conformity 13 I/O interface X1_ANALOG_IO 30 Connecting devices 8 Connections Backplane connector 27 Product exclusion if liability 8...
  • Page 40 Index ETAS ES5350.1 - User’s Guide...
