Summary of Contents for Avnet MAAXBOARD
- Page 1 Quad Core, 2GB RAM, micro-SD Slot avnet.me/MAAXBOARD-oob...
- Page 2 QUICK START GUIDE WHAT YOU WILL NEED Essential (for general use) – SD card - A minimum of 8GB class 4 or class 10 microSD card, 16GB is recommended – Display and connectivity cable - Any HDMI monitor or TV – Keyboard and mouse –...
- Page 3 SET UP YOUR SD CARD Download operating system images – Visit the downloads page: avnet.me/MAAXBOARD-oob to download Debian Linux or Android 9 image Flash the SD Card – Download and install the flash tool - Etcher from: https:/ /www.balena.io/etcher – Flash the SD card with Etcher...
- Page 4 CONNECT YOUR MAAXBOARD MAAXBOARD Connection Block Diagram 40-Pins GPIO Header - Raspberry Pi HAT Compatible Audio Expansion Button (Back) Button (Home) HDMI Monitors Button (Power On/Off/ Suspend/Resume) Gigabit Ethernet LED0 LED1 MIPI-DSI Touch Displays USB 3.0 802.11 b/g/n/ac Wi-Fi & Bluetooth 4.2...
- Page 5 9. If you want to connect to the internet via Ethernet, use an Ethernet cable to connect the Ethernet port on MAAXBOARD to an Ethernet socket on the wall or on your internet router. You don’t need to do this if you want to use wireless...
- Page 6 1. Plug the USB Type-C power supply into a socket and connect into the powerport 2. You should see a green LED(LED0) light on the MAAXBOARD, which indicates that it is connected to power and bootloader (U-Boot) is loaded. As it starts up (this is also called booting), you will see the other green LED (LED1) blink and many character lines are printed on your screen.
- Page 7 1. Plug the USB Type-C power supply into a socket and connect it to the power port 2. You should see a green LED(LED0) light on the MAAXBOARD, which indicates that it is connected to power and bootloader(U-Boot) is loaded. As it starts up(this is also called booting), you will see the other green LED(LED1) blink and many character lines are printed on your screen.
- Page 8 Check out the help section and the troubleshooting guide at: Avnet.com/MAAXBOARD-help Check out the documentation at: Avnet.com/MAAXBOARD Email: Technical issues: support@embest-tech.com avnet.me/maaxboard-forum Sales: globalsales@embest-tech.com Copyright 2019 EMBEST/Avnet, Inc. The Avnet logo is a registered trademarks of Avnet, Inc. All other brands are the property of their respective owners. P20_014_KL...
