- Page 1 VE-TTLHX32 Hexoval Softbox 32″ for Venture TTL 600 Ws Monolight INSTRUCTIONS...
- Page 2 Introduction Thank you for choosing Impact. The Impact VE-TTLHX32 is a 32″ hexoval softbox for the Venture TTL monolight. The textured silver interior delivers high-contrast light, and the included translucent white interior diffuser and diffuser cover offer control over the level of contrast. Its hexoval...
- Page 3 Precautions • Please read and follow these instructions, and keep this manual in a safe place. • Keep this product away from water and any flammable gases or liquids. • Use only lights with the recommended wattage. • Handle this unit with care. •...
- Page 4 Overview Attachment ring Locking knob Tension rod Locking tab Interior diffuser touch-fastener strips Touch-fastener strips Mounting slots Interior diffuser Interior diffuser touch-fastener pads 10. Diffuser cover 11. Carry sleeve...
- Page 5 Overview (continued)
- Page 6 Assembling the Softbox To attach the softbox to the Venture TTL 600, follow these steps: Place the softbox down on a flat surface, and spread the tension rods. Lock each rod into place by pressing down on base of the rod until the locking tab snaps into position on the ring.
- Page 7 Assembling the Softbox (continued) Once inserted, turn the softbox so the accessory socket is aligned with the locking screw. Tighten the locking screw to secure the softbox to the monolight. To ensure a secure connection, make sure the locking knob screws completely into the accessory socket. Close the softbox around the ring by reattaching the touch-fastener strips.
- Page 8 Disassembling the Softbox To remove the softbox from the Venture TTL monolight, follow these steps: Remove the diffuser cover and interior diffuser from the softbox. Unfasten the touch-fastener strip closest to the locking knob, and unscrew the locking knob so that it is free of the monolight.
-
Page 9: Specifications
Specifications Monolight Diameter 31.5″ (80 cm) Dimensions (in sleeve) Length: 21″ (53.3 cm) Diameter: 6″ (15.24 cm) Weight 1.9 lb. (0.9 kg) - Page 10 Notes...
- Page 11 Notes...
-
Page 12: One-Year Limited Warranty
One-Year Limited Warranty This Impact product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
