impact Cruiser TTL-500 Instructions Manual

Ac/dc 500ws battery powered ttl monolight
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ACDC-500-TTL
Cruiser AC/DC 500 Ws
TTL Monolight
INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cruiser TTL-500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for impact Cruiser TTL-500

Summary of Contents for impact Cruiser TTL-500

  • Page 1 ACDC-500-TTL Cruiser AC/DC 500 Ws TTL Monolight INSTRUCTIONS...
  • Page 2 An adjustable 10 Ws LED modeling light draws minimal power and gives off nominal heat. The Cruiser is easy to transport. With the included universal-voltage battery charger, you can use the Cruiser TTL-500 at home or abroad.

  • Page 3: Box Contents

    Features • 500 Ws monolight • Supports TTL and HSS when used with the Cruiser Wireless Controller • Wireless TTL, optical slave, and direct sync options • Flash duration from 1/1000 to 1/9000 sec. • 10 Ws LED modeling lamp •...
  • Page 4 Overview Optical slave eye Optical sensor Group button Selects group A, B, or C. Channel button Selects channel 1 to 8. Model button Turns the modeling light on and off, and selects between 100% and 50% brightness. Power dial Adjusts the flash output from 2 to 10, in 1/10-stop increments.
  • Page 5 Overview (continued)
  • Page 6 Overview (continued) Top/side view: Battery: S-type reflector 17. Charge indicator lights/ button Glass dome 18. Battery release button Flashtube 19. Battery contacts Modeling LED 20. DC power input Accessory release Battery compartment / LCD screen: Battery contacts 21. Channel and group Umbrella locking screw 22.
  • Page 7 Overview (continued)
  • Page 8 Cruiser Wireless Controller Group buttons Power button Press to select group A, B, or C. Channel button The selected group is outlined. Selects channels 1 to 8. Press and hold to enable or Test button disable a group. Fires a test flash. Mode button Modeling light button Selects Manual or TTL mode.
  • Page 9 Cruiser Wireless Controller (continued)
  • Page 10 Cruiser Wireless Controller (continued) LCD screen: Modeling light Channel Output power Sound Manual/TTL Group FCS, SCS, HSS indicators MODE SYNC CHANNEL Firmware Notice The latest firmware updates are available on impactstudiolighting.com. If there are compatibility or performance issues with your camera, make sure your unit has the latest firmware version.
  • Page 11 Precautions ⚠⚡ Before using the Cruiser TTL, please cause damage to the retina and read the following safety notices may even lead to blindness. carefully and thoroughly. This will • If the flashtube or modeling light ensure safe use and help prevent becomes cracked or damaged in damage to your flash and injury to any way, replace immediately.
  • Page 12 Precautions ⚠⚡ (continued) • Use only the correct, • Always wear cotton gloves recommended battery. when handling the flashtube. • If you detect excessive • Keep this product away from heat, smoke, or a burning children. smell coming from the flash, •...

  • Page 13: Charging And Installing The Battery

    Charging and Installing the Battery A rechargeable battery and multivoltage charger are included with the Cruiser TTL 500. Note: Impact recommends fully charging the battery before its initial use and after an extended period of inactivity (more than two months).
  • Page 14 Wall Outlet Operation The Cruiser is equipped with a universal power input so it can be used in the US and abroad with the proper plug adapter. For AC operation: Remove the protective cap from the AC power port. Insert the 4-pin plug into the power port, and then turn the locking collar clockwise to secure the plug in place.

  • Page 15: Preparing For Use

    Preparing for Use Mounting on a Light Stand The Cruiser TTL-500 features a 5/8-inch baby receiver. If your light stand or mounting plate does not have a 5/8-inch post, make sure to use the appropriate adapter to mount the Cruiser.
  • Page 16 Preparing for Use (continued) Mounting an Umbrella Loosen the umbrella locking screw, and insert the umbrella shaft through the two mounting loops. Tighten the locking screw to secure the umbrella. Connecting Your Camera to the Cruiser The Cruiser has a 3.5 mm sync input for a wired connection to your camera or a wireless receiver (other than the Cruiser Wireless Controller).
  • Page 17 Attaching the Cruiser Wireless Controller to Your Camera Loosen the locking wheel by turning it counterclockwise. Slide the mounting foot all the way into your camera’s hot shoe. Turn the locking wheel clockwise to tighten until secure. Note: Make sure your camera has the appropriate settings. Consult the camera’s user manual to set features for TTL and HSS modes.

  • Page 18: Configuring The Settings

    Configuring the Settings Selecting Channels and Groups Via the Cruiser The Cruiser and the wireless remote must be set to thesame channel. Press the CH button repeatedly to cycle through channels 1 to 8. Selecting “–” (dash) disables wireless communication. Press the Group button repeatedly to select group A, B, or C.

  • Page 19: Alert Sound

    Configuring the Settings (continued) Press the Model button again for a modeling light power of 100%. Pressing the Model button a third time to turn the modeling light off. Note: The wireless remote can set modeling light power on each group individually.
  • Page 20 Using the Cruiser in Manual Mode The Cruiser’s flash power output level can be set manually in 1/10-stop increments over a 9-stop range. 10 is the full-power flash, and each stop halves the light output. To use the Cruiser in manual mode, follow these steps: Connect the sync cord to the Cruiser and to your camera.
  • Page 21 Using the Cruiser in TTL Mode TTL mode can be used only when the Cruiser is paired with the Cruiser Wireless Controller. When the wireless controller is mounted on a compatible camera, the camera’s TTL metering system automatically sends the Cruiser the appropriate flash output level.

  • Page 22: Using High-Speed Sync (Hss)

    Using High-Speed Sync (HSS) High-speed sync lets you use shutter speeds as fast as 1/8000 second. It gives you the option to shoot under bright sunlight while using a wider aperture to darken the background, or to freeze motion. Activating HSS Canon: Press the Sync button repeatedly to scroll to HSS.
  • Page 23 Second-Curtain Sync (SCS) For Canon cameras: Activate SCS mode on your camera. On the wireless remote, press the Sync button repeatedly until SCS ( ) is selected. To deactivate SCS, press the Sync button to select first-curtain sync ( ) or HSS. For Nikon and Sony cameras: SCS is enabled on the camera.

  • Page 24: Replacing The Flashtube

    Replacing the Flashtube Turn off the power, remove the battery, and wait at least 10 minutes for the flashtube to cool. Remove the glass cover by gently pulling it off of the flash head. Using white cotton gloves or a clean cloth, remove the retention wire wrapped around the top of the flashtube.

  • Page 25: Fcc Declaration Of Conformity

    FCC Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 26: Specifications

    Specifications Monolight Maximum power 500 Ws ISO 100, direct flash @ 10 ft. (3 m) f 16.8 TTL compatibility Canon, Nikon, Sony HSS compatibility Canon, Nikon, (1/8000 on available models) Trigger modes Wireless controller, manual, photocell, and sync cord Recycle speed 3.0 sec.
  • Page 27 Specifications (continued) Battery & Charger Battery type Li-ion Voltage 14.4 V No. of flashes @ full power Charging time (approximate) 3 hr. Charger Input: AC 100 to 240 V, 50/60 Hz Output: DC 16.8 V, 2.5 A Overheat limit Battery: 3.7 × 4.2 × 2.6 in. (9.4 × 10.7 × 6.6 cm) Dimensions Weight Battery: 1.5 lb.

  • Page 28: One-Year Limited Warranty

    One-Year Limited Warranty This Impact product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
