Item Qty Reference
1 0 C1-C8,C14,C19,C23-C28,C36,C37,R5-R8,R16
2 0 C9
3 7 C10,C11,C31-C35
4 6 C12,C18,R10,R12,R17,R18
5 1 C13
6 5 C15,C38-C41
7 1 C16
8 1 C17
9 4 C21,C22,C29,C30
10 10 E1-E6,E8-E10,E13
11 3 E7,E11,E12
12 6 J1-J6
13 1 JP1
14 6 XJP1 (6 LOCATION FOR JP1)
15 8 L1-L4,R1-R4
16 1 L5
17 1 L6
18 5 PT1,PT2,PT3,PT4,PT5
19 4 R9,R11,R13,R14
20 1 R15
21 2 T1,T2
22 1 U1
Preliminary
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
Part Description
OPT, 0402
OPT, 0603
CAP., X7R, 0.1µF, 10%, 16V, 0402
RES., CHIP, 0 Ohm, 0402
CAP., COG, 2.2pF, +/- 0.05pF, 50V, 0402
CAP., X5R, 0.01uF, 10%, 50V, 0402
CAP., X7R, 4.7uF, 10%, 16V, 0805
CAP., COG, 1.5pF, +/- 0.05pF, 50V, 0402
CAP., X5R, 1µF, 10%, 10V, 0402
TESTPOINT, TURRET, .063"
TESTPOINT, TURRET, .094"
CONN., SMA, 50-OHM, EDGE-LANCH
HEADER, 6 X 2 PIN, 2mm
SHUNT
RES., CHIP, 0 Ohm, 0805
IND., MULTILAYER, 3.9nH, +/-0.3nH, 0402
IND., MULTILAYER, 5.6nH, +/-0.3nH, 0402
POT., 4mm SMD, 500 Ohm
RES., CHIP, 100 Ohm, 1%, 1/16W, 0402
RES., CHIP, 1 Ohm, 1%, 1/8W, 0805
TRANSFORMER, RF, 1:1, 4.5-3000MHz
IC, LTC5584IUF#PBF, QFN 4mm X 4mm
Linear Technology Confidential
Manufacturer / Part #
MURATA, GRM155R71C104KA88D
VISHAY, CRCW04020000Z0ED
MURATA, GJM1555C1H2R2WB01D
MURATA, GRM155R71H103KA88D
MURATA, GRM21BR71C475KA73L
MURATA, GJM1555C1H1R5WB01D
MURATA, GRM155R61A105KE15D
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
E.F.JOHNSON, 142-0701-851
SAMTEC TMM-106-02-L-D
SAMTEC 2SN-BK-G
VISHAY, CRCW08050000Z0EA
MURATA, LQG15HS3N9S02D
MURATA, LQG15HS5N6S02D
BOURNS, 3214X-1-501-E
VISHAY, CRCW0402100RFKED
VISHAY, CRCW08051R00FNEA
MINI-CIRCUITS, TC1-1-13M+
LINEAR TECH., LTC5584IUF#PBF
