user documentation
TFT/HB101PR8xxx-yyyy
TFT/HV101PR8xxx-yyyy
Document Ordercode: DOC/PROTOUCH_WIDE-R
Revision
Date
1.0
27.11.2018
1.1
22.03.2019
DOC_PROTOUCH_WIDE-R_V1.0.docx
© 2019 Syslogic Datentechnik AG | All rights reserved
Author
Modification
D. Lagler
D. Lagler
Added VESA mounting version
Page 1 of 41
Advertisement
Table of Contents
Related Manuals for syslogic TFT/HB101PR8 Series
Summary of Contents for syslogic TFT/HB101PR8 Series
- Page 1 TFT/HB101PR8xxx-yyyy TFT/HV101PR8xxx-yyyy Document Ordercode: DOC/PROTOUCH_WIDE-R Revision Date Author Modification 27.11.2018 D. Lagler 22.03.2019 D. Lagler Added VESA mounting version DOC_PROTOUCH_WIDE-R_V1.0.docx Page 1 of 41 © 2019 Syslogic Datentechnik AG | All rights reserved...
-
Page 2: Table Of Contents
CAN 1 Interface (only on selected products) 2.4.7 CAN 2 Interface (only on selected products) 2.4.8 USB Interface 2.4.9 Ethernet LAN Interface 2.4.10 Frontside Status LEDs 2.4.11 Antennas (only on selected products) DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 2 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... - Page 3 EMI / EMC Specification Mechanical Data 4.3.1 HB101PR8xxx-yyyy 4.3.2 HV101PR8xxx-yyyy Use cases 5 Firmware Software Structure Firmware Functions Application Programming Interface (API) 6 Product Revision History Hardware Firmware Errata DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 3 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved...
- Page 4 Fig. 11 Isolated communication link Fig. 12 Non-isolated communication link with common chassis potential Related Documents [1] Syslogic Datentechnik AG, «SL - Industrial PC/COMPACT8,» [Online]. Available: https://www.syslogic.com/ProductDocuments/deu/DOC_COMPACT8_SL_V1.5.pdf. DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 4 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved...
-
Page 5: Introduction
Note that the documentation for the products is constantly revised and improved. The right to change this documentation at any time without notice is therefore reserved. Syslogic is grateful for any help referring to errors or for suggestions for improvements. The following registered trademarks are used:... -
Page 6: Information Pictograms Indicate The Following
Syslogic Datentechnik AG. Syslogic Datentechnik AG does not accept any liability for damages arising from the use of any incorrect or incomplete information contained in this documentation or any information missing. -
Page 7: Items Delivered
Electronic boards are sensitive to Electro-Static Discharge (ESD). Please ensure that the product is handled with care and only in an ESD protected environment. Otherwise a proper operation is not guaranteed. DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 7 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 8: Battery
The main functionality of the product is defined by the application program. The application program is not part of the delivery by Syslogic but is defined, developed and tested by the customer or a system-integrator for each specific application. Refer to the respective documentation for more information. -
Page 9: Rohs
The products of the PROTOUCH-WIDE family are not designed ready for operation for the end-user and are not intended for consumer applications. According to Waste Electrical and Electronic Equipment (WEEE) Directive (2002/96/EC) Syslogic takes back defective devices for proper disposal at the point of sale. -
Page 10: Product Description
10.1” WXGA VESA mounting Intel E3825 dual core 1.3GHz TFT/HV101PR8H19-142E 10.1” WXGA VESA mounting Intel E3845 quad core 1.9GHz Tab. 1 Projected capacitive touch panel versions DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 10 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 11: Accessories
Power Ethernet LAN2 ANT 1 + 2 Supply Fig. 1 HB101PR8xxx-yyyy (Front) Ground Terminal Fig. 2 HB101PR8xxx-yyyy (Side) ANT 3 - 5 Fig. 3 HB101PR8xxx-yyyy (Side) DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 11 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 12: Hv101Pr8Xxx-Yyyy
2.4.2 HV101PR8xxx-yyyy COM2/CAN2 Power COM1/CAN1 USB 1/2 supply Ethernet LAN1 Ground Ethernet LAN2 Terminal Fig. 4 HV101PR8xxx-yyyy (Front) ANT 1 - 3 Fig. 5 HV101PR8xxx-yyyy (Back) DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 12 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 13: Power Supply
Serial port 1 has standard RS232 signals on a standard DSUB-9 connector on the front (COM1). Device Connection RS232 The Serial Port COM1 is available on DSUB-9 Pin Number Signal Pin Number Signal Tab. 4 Serial Port COM1 DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 13 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 14: Com 2 (Only On Selected Products)
CAN Low CAN High CAN Ground no connection no connection no connection no connection Tab. 6 CAN port on DSUB-9 male (9 pin) DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 14 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 15: Can 2 Interface (Only On Selected Products)
P20 top USB port 2 Pin Number Signal Pin Number Signal VBUS VBUS SSRX- SSRX+ SSGND SSTX- SSTX+ Tab. 8 USB1/2 Interface Connector P20 (Dual Type A) DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 15 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 16: Ethernet Lan Interface
Ethernet Twisted Pair Interface Connector P18 and P19 (M12 D) Fig. 7 M12 D-coded female pinout (front view) Important Note Do not apply any supply voltage to this port. DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 16 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 17: Frontside Status Leds
Depending on the installed PC board the PROTOUCH-WIDE-R offers several internal USB connectors whereof one is used to connect the touchpanel. Please contact technical support for further details and assistance. DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 17 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 18: Mpcie Slot
PETn0 SMB_DATA PETp0 USB_D- USB_D+ +3.3V +3.3V LED_WWAN# LED_WLAN# LED_WPAN# +1.5V +3.3V Tab. 11 Pinout mPCIe slot Availability of SIM interface depends on installed PC board DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 18 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 19: Touch Screen
In the Advanced/Graphics menu select Backlight settings and enter desired value Press [F10] key and confirm to safe changings to quit Fig. 8 Modify default value of backlight DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 19 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 20: Maintenance
Disconnect device from power. Remove the two knurled screws highlighted and remove the cover. After removing the cover the C-Fast and the battery slot are accessible. DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 20 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 21: Tft/Hvxxxpu8Yyy-Zzzz
After removing the cover the battery and the C-Fast slot are accessible. Battery C-Fast holder Please install the service cover before operating the Projected Capacitive Touch Panel. DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 21 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 22: Replace Main Fuse
Carefully remove the PC box Important Note Be careful not to tear the cables for display and touch Detach the cables to the display and touch DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 22 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 23: Tft/Hvxxxpu8Yyy-Zzzz
Carefully remove the PC box Important Note Be careful not to tear the cables for display and touch Detach the cables to the display and touch DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 23 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 24: Replace Fuse
Do not use a coarse scouring cloth, scouring powder or solvent. Cleaning should only be carried out when the device is switched off! Make sure the device has cooled down to room temperature DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 24 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 25: Spare Parts
24V Desktop Power Supply 60W - 4 pole PSU/DT24V60W-4 CMOS battery CR2450N(3V, 540mAh) CPN/CR2450N CMOS battery CR2477(3V, 950mAh) CPN/CR2477N Fuse 4A slow-blow Littelfuse 452004.MRL Tab. 12 Spare parts DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 25 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 26: Installation Description
Fig. 10 Required Cut out HB101PR8xxx-yyyy Mounting Angle: Mounting Angle must be 90° Cooling Space: To ensure cooling leave at least 10cm of free space around product. DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 26 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... - Page 27 Reattach the mounting frame and fix it into place by reattaching the screws highlighted in red. Required torque: 1.3Nm The product is now installed properly. Wall Projected capacitive touch panel Fig. 12 Fully installed PROTOUCH-WIDE-R DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 27 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved...
-
Page 28: Tft/Hvxxxpr8Yyy-Zzzz
To ensure cooling leave at least 10cm of free space around product. For best thermal performance use spacer M4 x 5mm between the VESA mounting frame and the device DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 28 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 29: Installation And Cabling
The AC/DC power supply must fulfil the requirements for EMI/RFI -certification. 3.2.3 Cabling the interfaces Use appropriate cabling for all interfaces. Shielded cabling is required to meet the EMI/EMC limits. DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 29 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 30: Grounding
It is better to clamp the shields onto a grounded copper rail. IIndustrial PC System Cabinet Clamping screw nonisolated Chassis shield Cables Fig. 13 Additional grounding of the cable shields at the entry point of a cabinet DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 30 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 31: Cabling Of Communication Links
Copper-wire for Potential Adjustment, min. 10 mm Zentraler Erdpunkt am Chassis Zentraler Erdpunkt am Chassis Central Grounding Point Central Grounding Point Fig. 15 Non-isolated communication link with common chassis potential DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 31 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 32: Technical Data
RS232 <30m USB 2.0 <3m USB 3.0 <3m Ethernet <100m Tab. 17 Maximum cable length Cold start up: -20°C depending on specific use case; see 4.4 DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 32 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 33: Tab. 18 General Electrical Characteristics
2 x ETH, 50%Cpu load, 30% Backlight, ~250cd/m 2 x ETH, 50%Cpu load, 100% Backlight, ~850cd/m 2 x ETH, 50%Cpu load, 70% Backlight, ~600cd/m 2 x ETH, 50%Cpu load, 30% Backlight, ~250cd/m DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 33 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 34: Emi / Emc Specification
EN61000-6-2 / EN61000-6-1 Important Note The PROTOUCH-WIDE system is a class A system for industrial applications. It is not indented for use in residential or home applications. DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 34 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 35: Mechanical Data
Mechanical Data 4.3.1 HB101PR8xxx-yyyy DOC_PROTOUCH_WIDE-R_V1.0.docx Page 35 of 41 © 2019 Syslogic Datentechnik AG | All rights reserved... -
Page 36: Hv101Pr8Xxx-Yyyy
Protouch-wide-R: user documentation DOC/PROTOUCH-WIDE-R; V1.1 4.3.2 HV101PR8xxx-yyyy DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 36 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 37: Use Cases
Maximum ambient temperature is highly dependent on mounting, air flow and CPU/GPU load; with the Technologies the processor automatically reduces the internal CPU when the critical thermal trip points are reached to prevent damage. DOC_PROTOUCH_WIDE-R_V1.0.docx Page 37 of 41 © 2019 Syslogic Datentechnik AG | All rights reserved... -
Page 38: Firmware
Application Programming Interface (API) The RSL8 system does not contain any special API beside the installed BIOS. Refer to the BIOS and Operating System documentation for API specifications. DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 38 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 39: Product Revision History
Therefore, this information may be incompatible with the prototyping board hardware. Board Identification (see product BIOS Build Date Remarks label) Version TFT/Hx101PR8G13-N142E #1.0 L1R021BA 09.03.2018 TFT/Hx101PR8H19-N142E #1.0 L2R021BA 09.03.2018 Tab. 21 Firmware Revision State DOC_PROTOUCH_WIDE-R_V1.0.docx Seite 39 von 41 © 2018 Syslogic Datentechnik AG | All rights reserved... -
Page 40: Errata
BIOS. It is important therefore that neither the application software nor the operating systems reprograms the processor chipset's configuration registers. Note that prototype board errata (boards with revision #0) are not listed here. Contact Syslogic technical support for prototype board information. -
Page 41: Doc_Protouch_Wide-R_V1.0.Docx Seite 2 Von
RMA Service Syslogic offers a Return Material Authorization process to simplify handling of devices that needs to be returned to the manufacturer. Please follow the instructions on our web page: https://www.syslogic.com...
