Radio / CD
Grenoble RD 169
Operating instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GRENOBLE RD 169 and is the answer not in the manual?

Questions and answers

Related Manuals for Blaupunkt GRENOBLE RD 169

Summary of Contents for Blaupunkt GRENOBLE RD 169

  • Page 1 Radio / CD Grenoble RD 169 Operating instructions...

  • Page 3: Display

    Display The display consists of three fields and varies according to the operating mode and function. Display field 1: Radio mode Memory banks and wavebands Brief indication of preset station (e.g. P1) CD mode Current track Audio Numeric and graphic representation of the volume and audio settings Permanent display for DSC programming.

  • Page 4: Table Of Contents

    Contents Display ... 23 Quick reference ... 25 Important notes ... 29 What you need to know ... 29 Traffic safety ... 29 Installation ... 29 Accessories (optional) ... 29 Additional amplifiers ... 29 Theft protection system / Release panel ... 30 Detaching the release panel ...

  • Page 5: Quick Reference

    Quick reference 1 Detachable operating panel Press the “REL” button to release the detachable operating panel and remo- ve it from the vehicle. To re-attach the panel, set it into the guide on the right-hand side of the chassis. Gently press in the left side of the panel until it snaps into place.
  • Page 6 For FM only: <</>> Scrolls through the broadcast net- works, if AF is on. Example: NDR 1, 2, 4, N-Joy, ... CD mode Select track: Down, is pressed only once the unit will return to the beginning of the track currently playing. >>...
  • Page 7 If you do not make any adjustments to the tone within 8 seconds, the AUD mode will quit automatically. LD - Loudness Loudness boosts the bass frequency at low volume. Loudness on/off: Press AUD until you hear a beep. : DSC (Direct Software Control) Using “DSC”...
  • Page 8 = BA/TS Switches between the wavebands/me- mory banks FM I, FM II, TS (Travelsto- re), MW and LW Extra function: Travelstore To store the six most powerful radio stations in the Travelstore bank: Press BA/TS until a beep sounds or “T-STORE”...

  • Page 9: Important Notes

    If you have any questions about the guar- antee, please contact your dealer. He will be happy to assist you, repair your equip- ment or forward it to an authorised Blaupunkt repair shop. In addition, our employees are there to help you on our service hotline.

  • Page 10: Theft Protection System / Release Panel

    Theft protection system / Release panel To best protect your car audio system from theft, this unit has been equipped with a de- tachable control panel. Detaching the release panel Press the REL button on the top left of the radio to release the control panel.

  • Page 11: Selecting The Operating Mode

    Selecting the operating mode Use the SRC (source) button to select bet- ween radio and CD. The CD mode is not available unless a CD has been inserted. Otherwise, “No CD” will appear in the dis- play. Press SRC to switch between the operating modes.

  • Page 12: Selecting A Waveband

    Selecting a waveband The following wavebands are available: UKW (FM) 87,5 - 108 MHz, - 1602 kHz and - 279 kHz Press the “BA/TS” button to select the desi- red waveband. Station tuning Automatic seek tuning • Press / ; the car radio will automati- cally search for the next station.

  • Page 13: Storing Stations With The Strongest Reception Automatically With Travelstore

    • Press the desired preset button until the radio resumes play after the muting (takes approximately 2 seconds) or un- til you hear a beep. Now the station has been stored. The display will indicate which station has been stored. Note: If you attempt to store a station which is al- ready stored, the corresponding station and...

  • Page 14: Switching Between Stereo/Mono (Fm)

    Switching between Stereo/Mono (FM) You can switch between Stereo/Mono in the “DSC” menu. This can be an advantage when the station reception is poor. The car audio system will select stereo automatical- ly when it is switched on. When reception quality deteriorates, the system will switch to mono playback.

  • Page 15: Storing Programme Types

    When “PTY” is switched on, you can select a programme type using buttons <</>>. • Press << or >>; the programme type selected last will be displayed for 3 se- conds. • During this period press >> (forwards) or << (backwards) to select the desired type.

  • Page 16: Traffic Programme Station Reception With Rds-Eon

    Traffic programme station reception with RDS-EON The abbreviation “EON” stands for Enhan- ced Other Networks, which means that in- formation is exchanged within a radio net- work. Many FM radio stations provide their ser- vice area with traffic messages at regular intervals.

  • Page 17: Cd Operation

    CD operation This car audio system is also equipped with a CD player. Note: Use only perfectly circular CDs with a dia- meter of 12 cm. CDs with a diameter of 8 cm or CDs manu- factured in the shape of a butterfly or a beer mug, for example, are not suitable for use with this equipment.

  • Page 18: Cd-Repeat (Rpt)

    CD-Repeat (RPT) Press the station preset button marked “4” during CD playback to repeat the track cur- rently playing. “REPEAT” will appear briefly in the display and the track will repeat until you press sta- tion button 4/RPT again or press the rocker switch to select a different track.

  • Page 19: Deactivating The Hour Correction Function

    Deactivating the hour correction function In the DSC menu it is possible to switch off the hour correction function with “CLK MAN/ CLK AUTO”. An automatic correction for mi- nutes will continue to take place. This is useful if you would like to display the time for a different time zone, for example.
  • Page 20 CLK. 12/24 Switches between 12-h and 24-h clock display. DISP. ON/OFF. Here you can set the clock to permanent dis- play when the audio system is switched off. The clock display will remain visible until the ignition is switched off. EQ ON/OFF Switches the equalizer functions on and off.

  • Page 21: Overview Of The Dsc Factory Settings

    Overview of the DSC factory set- tings AM ON/OFF BEEP CLK MAN/AUTO AUTO CLK 12/24 DISP ON/OFF HICUT LO-DX SENS DX 1 LOUDNESS MUTE LEVEL PEAK ON/OFF PTY LANG English REG. ON/OFF SCANTIME STEREO/MONO Stereo TA. VOL T. ON VOL Specifications Amplifier Output power:...
  • Page 22 026 130 04 41 026 130 05 14 180 026 6-BLAU 180 026 625 28 006 535 054 47 006 535 053 12 042 175 873 212 042 175 873 229 Blaupunkt-Werke GmbH Bosch Gruppe K7/VKD 8 622 402 055...
