Installing Your Coolbot Pro To Your A/C - Store It Cold CoolBot Pro Manual

INSTALLING YOUR COOLBOT PRO TO YOUR A/C (See Diagram on page 4)
STEP 1 Plug the cables into the corresponding labeled ports at the bottom of the CoolBot Pro except for the Data Cable. If you are
replacing an existing CoolBot with "removable" cables, use all your new cables and save the old cables as spare parts. The
CoolBot Pro works with both black and blue Temperature Sensor Cables.
STEP 2 Mount the CoolBot Pro on the wall next to the A/C.
Remove the air filters from the front of the A/C – DO NOT use them!
STEP 3
Find and free the A/C's Temperature Sensor. It's the only thing attached to the front grill of the A/C. Take the sensor out of
STEP 4
the mounting clip - DO NOT use the mounting clip for this installation.
Using ONLY a 2" square piece of Aluminum foil, place the CoolBot Heater Cable (Red Tip) next to the A/C's Temperature
STEP 5
Sensor. Hold them together and wrap them tightly with the foil. You can use a Zip-tie or a piece of tape 1 inch below the foil
to keep them together. Make sure the foil connection is NOT in front of the A/C.
STEP 6 If you have a Window LG A/C (except Inverter Models) or a Window HAIER A/C unit skip to STEP 7.
Most brands of Window A/C units and ALL Mini-Split units have Secondary Sensors.
To find the A/C's Secondary Sensor please visit our support page at: www.storeitcold.com/support.
If you found a Secondary Sensor, place the sensor on top of the foil from step 5 (not inside) and hold it in place with a small
piece of electrical tape – do not over insulate the foil while doing this.
Use a pen or a pencil to open a small gap in the front of the fins of the A/C about 1" from the bottom and near the center,
STEP 7
between the bottom and second Cooling pipes.
Insert ONLY ¼" of the tip of the CoolBot Fins Sensor into the small gap.
DO NOT force the sensor in, you will damage it! DO NOT touch any Cooling Pipes with the sensor.
Pinch the fins lightly around the sensor to keep it in place.
STEP 8 If you do not have Wi-Fi Skip this Step and go to Step 9. Mount the CoolBot Jumper outside of your cooler in a location close
enough for the provided Data Cable to connect the CoolBot Pro to the CoolBot Jumper. The CoolBot Jumper is not
weatherproof. If it is to be mounted outdoors where rain, snow, and sunlight may get to it then install it inside of a
weatherproof nonmetallic container. After your CoolBot Jumper is mounted, connect the CoolBot Pro and the CoolBot
Jumper using ONLY the provided Data Cable. The provided Data Cable is specific to the CoolBot Pro/Jumper – standard phone
cable will not work and may damage your CoolBot Pro/Jumper.
Turn your A/C ON. Set the A/C on "COOL" Mode and set the Fan on "HIGH" speed. Set the A/C temperature to the lowest
STEP 9
setting.
Plug in your CoolBot Pro power supply. To set the temperature on your CoolBot Pro, press the checkmark button – the current
STEP 10
set temperature will blink. Use the right or left arrows to set the temperature to the desired value. Press the checkmark to
save the value.
Detailed CoolBot Pro Videos, Instruction Manual, App Features, and Troubleshooting at:
https://www.instagram.com/storeitcold
https://www.youtube.com/storeitcold
CoolBot Pro Quick Start Set Up Guide Rev 2019 – 03A
