Mangar AB0030 User Instructions

Bamboo Corner Shower Stool - User Instructions
(Model: AB 0030)
The Bamboo Corner Shower Stool by Mangar International is intended to be used in a shower or bath to provide
a stable, seated support, where a user is unable to stand for long periods.

Contents

2 x Adjustable leg assemblies.
5 x Wing screws (A).
5 x Saddle washers (B).
1 x Seat.
1 x User instructions.

Assembly

1. Place the seat upside down on a flat surface
and position the legs as shown (fig.1).
2. Fit the saddle washers (B) to the screws (A)
before securing the legs to the underside of the
seat. Ensure that the screws are fully tightened.

Height Adjustment

1. Adjust the legs to the desired height by
depressing the snap button (C fig. 2) and sliding
the leg extension up or down the frame tube until
the button snaps into the appropriate adjustment
hole.
2. Ensure that all four leg extensions are secured
to the same adjustment holes to ensure even
height.
WARNING: Ensure that all four legs are adjusted to
the same height and that each snap button is fully
located.
freedom through lightweight solutions
A
B
C
MI0257 issue 3
Fig. 1
Fig. 2
