Microphone level (MIC)

- When selecting the microphone as Input or recording source, keep in mind
that it will not be possible to use Input 1-2 at the same time.
- It is not necessary to select MIC if you simply whish to use the Talk Over
mode (Mic On-Off) since this function acts directly on the hardware of 4-Mx
by sending the signal of the microphone input to the main output.
We recommend using dynamic microphones with an impedance rating of 1
to 64 ohms. If you wish to use a condenser microphone, please note that
an external power source will be required as the Console doesn't provide
phantom power (+48 V).

Phono Level

Used for:
- Turntables with a Phono level signal.
If necessary, connect the ground between the DJ Console your the turntable.
Note that this setting should not be used if your turntable produces a Line
Level output (Consult the user manual for more details). The same applies if
you are using a Phono/Line level converter.

Line level

Used for:
- Consumer CD players
- MP3 players.
- Musical instruments (keyboard, Effects)
- Turntables with a Line level signal.
- Phono/Line level converter
