Mohawk TP-20 Manual

20,000 lb. capacity two post vehicle lift
Hide thumbs

Advertisement

Quick Links

Download this manual
MOHAWK
MADE IN THE USA
MODEL TP-20
MOHAWK RESOURCES LTD.
P.O. BOX 110
65 VROOMAN AVENUE
AMSTERDAM, NY 12010
TOLL FREE : 1-800-833-2006
LOCAL : 1-518-842-1431
FAX : 1-518-842-1289
INTERNET: WWW.MOHAWKLIFTS.COM
E-MAIL: SERVICE@MOHAWKLIFTS.COM
TP-20-Master.doc
PART #601-800-015
20,000 LB. CAPACITY TWO POST
VEHICLE LIFT MANUAL
REV DATE 4/29/2005
INSTALLATION
OPERATION
MAINTENANCE
PARTS

Advertisement

loading
Need help?

Need help?

Do you have a question about the TP-20 and is the answer not in the manual?

Questions and answers

Related Manuals for Mohawk TP-20

Summary of Contents for Mohawk TP-20

  • Page 1 MOHAWK MADE IN THE USA MODEL TP-20 20,000 LB. CAPACITY TWO POST VEHICLE LIFT MANUAL INSTALLATION OPERATION MAINTENANCE PARTS MOHAWK RESOURCES LTD. P.O. BOX 110 65 VROOMAN AVENUE AMSTERDAM, NY 12010 TOLL FREE : 1-800-833-2006 LOCAL : 1-518-842-1431 FAX : 1-518-842-1289 INTERNET: WWW.MOHAWKLIFTS.COM...
  • Page 2 MOHAWK MODEL TP-20 IMPORTANT SAFETY INSTRUCTIONS When using your garage equipment, basic safety precautions should always be followed, including the following: 1. Read all instructions. 2. Care must be taken as burns can occur from touching hot parts. 3. Do not operate equipment with a damaged cord or if the equipment has been dropped or damaged - until it has been examined by a qualified serviceman.
  • Page 3 MOHAWK MODEL TP-20 APPENDAGE: Rev (8/3/98) NOTE: All accessories (i.e. Lifting Pads, Height Adapters, Wheel Adapters, Turf Adapters) supplied with this lift are to be used on this lift only. Accessories from other lifts are not acceptable and could result in injury to the user.
  • Page 4 MOHAWK MODEL TP-20 HAVE A QUESTION? Call your local Mohawk distributor For parts, service and technical support. Distributor Place Card Here Please have this unit’s model and serial number when calling for service. Model Number ______________________ Serial Number ______________________ OR CONTACT: MOHAWK RESOURCES LTD.
  • Page 5 GENERAL WARRANTY INFORMATION: MOHAWK’S OBLIGATION UNDER THIS WARRANTY IS LIMITED TO REPAIRING OR REPLACING ANY PART OR PARTS RETURNED TO THIS FACTORY, TRANSPORTATION CHARGES PREPAID, WHICH PROVE UPON INSPECTION TO BE DEFECTIVE AND WHICH HAVE NOT BEEN MISUSED. DAMAGE OR FAILURE TO ANY PART DUE TO FREIGHT DAMAGE OR FAULTY MAINTENANCE IS NOT COVERED UNDER THIS WARRANTY.
  • Page 6 WARRANTY. TO QUALIFY FOR THIS WARRANTY, THE FOLLOWING CONDITIONS MUST BE MET: ♦ ALL LIFTS MUST BE REGISTERED WITH MOHAWK RESOURCES, LTD., P.O. BOX 110, 65 VROOMAN AVENUE, AMSTERDAM, NY 12010, WITH THE ORIGINAL CUSTOMER NAME, ADDRESS AND PHONE NUMBER, WITHIN 30 DAYS OF INSTALLATION.
  • Page 7 PRE - OPERATION CHECK LIST / LIFTING PROCEDURES MAINTENANCE PROCEDURES TROUBLE SHOOTING 10 - 11 SERVICE CHART MAINTENANCE CHART FIGURES / DIAGRAMS TP-20 INSTALLATION & LAYOUT SPECIFICATIONS TP-20 TP-20 ELECTRICAL SCHEMATIC 007-007-091 TP-20 HYDRAULIC SCHEMATIC 020-000-080 BAY SIGHT LAYOUT MAN 2014...
  • Page 8 SPECIFICATIONS AND THE USES SET FORTH IN THE DESCRIPTIVE PASSAGES. ANY OTHER PROPOSED APPLICATION OF THIS INSTALL THIS EQUIPMENT ON CONCRETE ONLY EQUIPMENT SHOULD BE DOCUMENTED AND SUBMITTED IN WRITING TO MOHAWK RESOURCES LTD. FOR EXAMINATION. IF, FOR ANY REASON, A NEW CONCRETE SLAB SECTION IS USER ASSUMES...
  • Page 9 DO NOT INSTALL ANY MOHAWK LIFT ON EXPANSION SEAMS OR OBTAINED FROM THE FIRM WHO SUPPLIES THE CONCRETE ON CRACKED, OR DEFECTIVE CONCRETE. MIXTURE AT THE TIME OF THE POUR. SEE THE TP-20 FLOOR MODIFICATION DRAWING. DO NOT INSTALL ANY MOHAWK LIFT ON SECONDARY FLOOR...
  • Page 10 MOHAWK MODEL TP-20 RECOMMENDED TOOL LIST SIZE / QTY DESCRIPTION USED IN 2 - 1/4 IN WRENCH & SOCKET SWING ARM PINS 1 - 1/2 IN SOCKET POST MOUNTING BOLTS 1 - 1/8 IN SOCKET POWER UNIT MOUNTING BRACKET 1 - 1/6 IN...
  • Page 11 BEFORE INSTALLING A LIFT IMPORTANT BEFORE INSTALLING A MOHAWK LIFT THERE ARE A FEW ITEMS THAT MUST BE INSPECTED. EACH REPAIR SHOP BAY IS DIFFERENT. IN AN ATTEMPT TO PREVENT OVERSIGHTS, ALL OF THE FOLLOWING INFORMATION IS TO BE VERIFIED.
  • Page 12 UNDERSTANDING OF HOW THIS UNIT IS TO BE ASSEMBLED AND OF HOW INDIVIDUAL PARTS OPERATE, BEFORE ASSEMBLING THE UNIT. INSTALLING THE LIFT THE AIR CYLINDERS IN THE POST AS SHOWN IN THE TP-20 PNEUMATIC SYSTEM DIAGRAM. USE THE PACKING LIST IN THIS MANUAL TO VERIFY ALL SUPPLIED PARTS.
  • Page 13 MOHAWK MODEL TP-20 INSTALLATION INSTRUCTIONS CONTINUED AT THIS TIME PERFORM THE PRE-OPERATION CHECK LIST AND AT THIS TIME HAVE A QUALIFIED ELECTRICIAN MAINTENANCE PROCEDURES ( DAILY - WEEKLY - MONTHLY ) CONNECT THE POWER SUPPLY TO THE UNIT MAKE ALL ADJUSTMENTS PERTAINING TO THESE PROCEDURES.
  • Page 14 PLEASE POST THE ( A COPY IS INCLUDED IN THE PARTS BOX ) WHERE THEY WILL BE CONSTANTLY REMINDED TO YOUR LIFT OPERATOR. FOR INFORMATION SPECIFIC TO THE LIFT, ALWAYS REFER TO THE MOHAWK MANUAL. • UNOBSTRUCTED CLEARANCE. DO NOT HIT OR INSPECT YOUR LIFT DAILY.
  • Page 15 MOHAWK MODEL TP-20 PRE - OPERATION CHECK LIST TRAINED OPERATOR NO LOAD PERFORMANCE CHECK • • THE OPERATOR MUST BE FULLY TRAINED AND QUALIFIED ALL MECHANICAL SAFETIES OPERATE PROPERLY AND TO SAFELY AND EFFECTIVELY OPERATE THIS EQUIPMENT CONSISTENTLY. OF THIS SPECIFIC MAKE AND MODEL.
  • Page 16 MOHAWK MODEL TP-20 MAINTENANCE PROCEDURES QUALIFIED MAINTENANCE PERSONNEL ONLY DAILY MONTHLY • PERFORM THE PRE-OPERATION CHECK LIST. • • INSPECT ALL HYDRAULIC COMPONENTS FOR LEAKS, REPORT ANY AND ALL EQUIPMENT MALFUNCTIONS DEFORMATION, WEAR OR CORROSION. IMMEDIATELY. • • TIGHTEN ALL FASTENERS, HYDRAULIC / PNEUMATIC CLEAN ALL MOVING PARTS.
  • Page 17 • THE HYDRAULIC SAFETY CHECK IS TO BE PERFORMED WITH NO VEHICLE ON THE UNIT. • CONTACT YOUR LOCAL MOHAWK DISTRIBUTOR OR THE MOHAWK FACTORY IF EITHER TEST FAIL. HYDRAULIC SAFETY CHECK MAIN SIDE SAFETY CHECK: OFF SIDE SAFETY CHECK:...
  • Page 18 REMOVE THE HYDRAULIC LINE AND INSPECT FLAIR AND FITTING FOR DEFORMATION. REPLACE IF NEEDED. BAD O-RING ( O-RING TYPE FITTINGS ) CHANGE O-RING LOOSE PIPE FITTING REMOVE, RESEAL, AND RE-INSTALL FITTING. SEAL ALL PIPE FITTING CONNECTIONS WITH THREAD SEALANT MOHAWK PART # 601-610-002 NOTE: DO NOT USE TEFLON TAPE.
  • Page 19 MOHAWK MODEL TP-20 SERVICE CHART MODEL TP-20 SERIAL NUMBER: ________________________________ DATE OF INSTALLATION: _________________________ DATE PART REPLACED / SERVICED SERVICE SERVICED BY COMPANY...
  • Page 20 MOHAWK MODEL TP-20 MAINTENANCE CHART DATE MAINTENANCE PERFORMED SERVICE SERVICED BY COMPANY...
  • Page 21 MOHAWK MODEL TP-20 MOHAWK MADE IN THE U.S.A. MODEL TP-20 PARTS MANUAL MOHAWK RESOURCES LTD. P.O. BOX 110 65 VROOMAN AVENUE AMSTERDAM, NY 12010 TOLL FREE : 1-800-833-2006 LOCAL : 1-518-842-1431 FAX : 1-518-842-1289 INTERNET: WWW.MOHAWKLIFTS.COM E-MAIL: SERVICE@MOHAWKLIFTS. COM...
  • Page 44 MOHAWK NEW SLAB RECOMMEDATIONS MOHAWK RESOURCES LTD. 65 VROOMAN AVE. AMSTERDAM, NY 12010 TOLL FREE : 1-800-833-2006 LOCAL : 1-518-842-1431 FAX : 1-518-842-1289 INTERNET: www.MOHAWKLIFTS.com E-MAIN: Service@MOHAWKLIFTS.com...
  • Page 45 New Slab Recommendations: The information contained in this appendage supercedes any other information given in the accompanied manual. This information is presented for design recommendations for a new concrete slab in the event that the pre-existing floor does not meet minimum requirements of the applicable lift type. Please read all instructions below carefully before producing new slab.
  • Page 46 3/4 in 6 in 18 - #4 - Main Bars 4 in - Long Bars 24 - #4 - Temperature Bars 8 in - Short Bars TP-20 6 Ft 16 Ft 3/4 in 6 in 18 - #4 - Main Bars...
