- Page 1 NewRider™ 5000 Airless Riding Field Line Striper NewRider™ 5000 Manual / 3033.0618...
-
Page 2: Table Of Contents
1016907 and above only. For Cleaning Procedure ........Page 7 units with serial numbers below (Extended Periods or Winter Storage) 1016907, please contact Newstripe for the correct manual. Maintenance ..........Page 8 Parts List ............ Page 9 Airless Pump Detail ....... Page 11 Detailed parts pictures ...... -
Page 3: Precautionary Warning
NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! PRECAUTIONARY WARNING PRECAUTIONARY WARNING! Please read and understand all operation instructions as detailed in this manual. Failure to follow specified instructions may result in equipment damage or serious injury to personnel up to and including death! ... -
Page 4: Assembly
NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! ASSEMBLY Check for any damage that may have occurred Insert the two ½” x 3-1/3” long bolts in the holes during shipment. Advise factory immediately if from the front. - Page 5 NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! ASSEMBLY (CONTINUED) Attach one end of the spray hose to the pump Always check the oil level in the engine before outlet with a 3/4” wrench and the other end to starting (SAE 10W30).
- Page 6 NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! SPRAY OPERATIONS First time use or after extended periods of not using the machine use water to test operations and settings. The NewRider™ 5000 is designed to be used with water based athletic field marking paints 1.
-
Page 7: Operation
NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! OPERATIONAL NOTE! NOTE: If the pump primes and air bubbles continue to appear in the hose after one minute, the suction hose fitting may not be tight enough or the rubber washer may be worn. -
Page 8: Spray Tip Cleaning
NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! SPRAY TIP CLEANING DURING USE 1. Place the Spray Control Knob in the 4. Reverse the tip so the spray tip arrow on the re-circulating position and press spray trigger spray gun points towards the ground. -
Page 9: Cleaning Procedure
NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! CLEANING FOR EXTENDED PERIODS OF NON-USE OR IN FREEZING CONDITIONS 1. Clean as indicated in CLEANING 4. Remove as much fuel from the engine gas PROCEDURES, but drain purge tank then add tank as you can, or add fuel stabilizer to fuel. -
Page 10: Maintenance
NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! MAINTENANCE ITEM CHECK MAINTENANCE ACTION Engine Oil Before each use Change oil after first 20 hours of operation 10W30 and then, every 100 hours. Spray Pump Before and after each use Use pump protector every time you store the... -
Page 11: Parts List
NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! PARTS LIST Item# Description Part Number Battery, ytx20 10003163 Transaxle oil reservoir 10003000 Transaxle release/engaging lever 10003727 Spring, seat 10001756 Empty seat safety switch 10002437 Not Shown Neutral switch (under deck on shift linkage) - Page 12 NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! PARTS LIST CONTINUED Item # Description Part Number Rear wheels 10002991 Purge tank feed selector valve 10004110 Purge hose 10004816 In-line filter 10000369 Not Shown Filter screen for in-line filter...
-
Page 13: Airless Pump Detail
NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! AIRLESS PUMP PARTS Item Description Part Number Return/bypass hose 10003235 Spray pump 10000407 Pump inlet hose 10004117 Pressure control knob Inlet Valve 10002745 Outlet push button * available in kit only. -
Page 14: Detailed Parts Pictures
NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! Picture 7 Picture 6 Empty seat safety switch (5) Purge Tank (11) Seat retention Air filter pins (6) housing (8) Fuel shut off (7) Transaxle release/engaging... - Page 15 NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! Picture 12 Shifter Pedal (33) Picture 13 Column release/lock lever (32) Front bumper Spray head lifting (14) lever/ Spray head support (35) Spray trigger Spray head pedal (34)
- Page 16 NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! Picture 17 Picture 18 Tank Outlet hose (45) Pump inlet hose (75) Belt, Main Drive pulley (51) drive (46) Tensioner pulley (47) Tensioner spring (48) Tie Rod...
-
Page 17: Transaxle Service
12. Top off the reservoir with to the “FULL COLD” mark. **Warning: Use ONLY Mobil 1 Full Synthetic 15W50 Motor Oil and Newstripe Filter Part Number 10003778 in the transaxle of this machine. Failure to use the correct filter and oil will cause damage to the transaxle and void the warranty NewRider™... -
Page 18: Maintenance
NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! TRANSAXLE SERVICE AND MAINTENANCE (CONTINUED) External Maintenance 1. Check oil level in reservoir under seat daily. 2. Inspect the vehicle drive belt, idler pulleys, and idler springs. Insure that no belt slippage can occur. Slippage can cause low input speed to the transaxle. -
Page 19: Troubleshooting Guide
NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! TROUBLESHOOTING GUIDE PROBLEM REMEDY Oil flows out at dipstick when STOP! DO NOT START ENGINE. Call Factory immediately. checking oil. Fuel lever was left in on position and fuel has drained into sump. Engine will not turn over Check that the battery is connected and charged. - Page 20 NewRider™ 5000 Airless Riding Field Line Striper ALWAYS wear safety goggles or protective eye-wear when operating the unit! TROUBLESHOOTING GUIDE (CONTINUED) PROBLEM REMEDY Pump primes and is running, but Check spray control knob is in spray position, check pressure control gun does not spray knob is turned to high pressure (clockwise until it stops).
-
Page 21: Warranty
The CUSTOMER MUST NOTE DAMAGES on the Bill of Lading of Trucking Company or Railroad; and Newstripe, Inc. will furnish to the customer the cost or parts and labor. The customer can then bill the common carrier for the damages by placing his signature on the documents.
