SMART-AVI V2V-AV2HV User Manual

TECHNICAL SPECIFICATIONS

INPUT
Input Video YPbPr: 1080p@50/60Hz, 1080i@50/60Hz,
Resolution 720p@50/60Hz, 576i/p, 480i/p
Input Video 0.5-1.0 volts p-p
Signal
Input DDC 5 volts p-p (TTL)
Signal
OUTPUT
Video HDMI Set 720p or 1080p output format
with integrated audio, VGA
Audio Stereo Audio 3.5mm jack socket
OPERATING FREQUENCY
Vertical 50/60Hz
Frequency
Range
Video 1.65Gbps/165MHz
Amplifier
Bandwidth
OTHER
Power Switching Power Supply 110/220v
5VDC2A
Operating 0 to +70°C (32 to + 158°F)
Temperature
Range
Operating 5 to 95 % RH (no condensation)
Humidity
Range
Dimensions 4.3 in. W x 1.1 in. H x 3.1 in. D
WHAT'S IN THE BOX?
PART NO. QTY DESCRIPTION
V2V-AV2HV-S 1 HD Video Converter with Stereo
Audio
PS5VDC2A 1 Power Supply
NOTICE
The information contained in this document
is subject to change without notice. SmartAVI
makes no warranty of any kind with regard to
this material, including but not limited to,
implied warranties of merchantability and
fitness for particular purpose.
SmartAVI will not be liable for errors con-
tained herein or for incidental or consequen-
tial damages in connection with the furnish-
ing, performance or use of this material.
No part of this document may be photocop-
ied, reproduced, or translated into another
language without prior written consent from
SmartAVI Technologies, Inc.
Many industry-leading companies have recognized the innova-
tion and power of SmartAVI's technologies and have success-
fully implemented them within their systems. Users of Smar-
tAVI technology include:
800.AVI.2131
Tel: (818) 503-6200 Fax: (818) 503-6208
11651 Vanowen St. North Hollywood, CA 91605
SmartAVI.com
Designed and Manufactured in the USA
V2V-AV2HV
HD Video Converter with
Stereo Audio
YPBPR, CVBS, S-Video and R/L
Audio to HDMI or VGA and Stereo
Audio Converter
USER MANUAL
