Gree livo GEN 3 LIVV09HP230V1A Owner's Manual

High-wall ductless air conditioning & heating system
Hide thumbs
Table of Contents

Advertisement

Quick Links

HIGH-WALL DUCTLESS
AIR CONDITIONING & HEATING SYSTEM
OWNER'S MANUAL
Models:
LIVV09HP230V1A
LIVV18HP230V1A
LIVV30HP230V1A
LIVV12HP230V1A
LIVV24HP230V1A
LIVV36HP230V1A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the livo GEN 3 LIVV09HP230V1A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gree livo GEN 3 LIVV09HP230V1A

Summary of Contents for Gree livo GEN 3 LIVV09HP230V1A

  • Page 1 HIGH-WALL DUCTLESS AIR CONDITIONING & HEATING SYSTEM OWNER’S MANUAL Models: LIVV12HP230V1A LIVV09HP230V1A LIVV24HP230V1A LIVV18HP230V1A LIVV36HP230V1A LIVV30HP230V1A...

  • Page 2: Table Of Contents

    Liv Heat Pump System! You can feel confident in your selection because the same pride in craftsmanship and engineering knowledge that goes into millions of other Gree installed products worldwide has gone into your unit. Please read this owner’s manual carefully before operation and retain it for future reference.

  • Page 3: Introduction

    INTRODUCTION Superior Design for Superior Performance Gree’s Liv Inverter-driven, Mini Split Heat Pumps are beautifully designed to deliver effective cooling or heating, while fitting unobtrusively into any decor. The indoor unit’s aesthetically pleasing, minimalist design blends nicely in any home or office.

  • Page 4: Safety Precautions

    • Disconnect electrical power to the indoor and outdoor units before performing any maintenance or cleaning. • Do not attempt to repair the Gree system yourself. Incorrect repairs may cause electric shock or fire. Contact a qualified service technician for all service requirements.
  • Page 5 SAFETY PRECAUTIONS Please read the following before operation. C UTION • Do not put hands or any objects into the air inlets or outlets. This may cause personal injury or damage the unit. • When cleaning, be careful not to splash water on the unit. Doing this may cause electric shock or damage to unit.

  • Page 6: Part Names

    PART NAMES Indoor unit Air inlet Air outlet Part Name 1. Front Panel 2. Aux. Button MODE SWING TURBO 3. Air Filter SLEEP TEMP WiFi CLOCK LIGHT TIMER TIMER 4. Horizontal Louver 5. Remote Controller XE71-44/G Wired Tether Controller (sold separately) 7.

  • Page 7: System Functions

    SYSTEM FUNCTIONS WHISPER QUIET Not only are the Gree systems energy efficient but they are quiet too. Liv High-Wall units operate with sound pressure levels starting as low as dB(A). MULTI FAN SPEEDS Whether operating in either Cooling or Heating mode, the indoor fan can be set to your choice of four different speeds (Low, Medium, High or Turbo) to achieve maximum comfort.
  • Page 8 SYSTEM FUNCTIONS MODE BUTTON The unit can be set to five different operating modes: HEAT, COOL, DRY, FAN ONLY and AUTO. NOTE: AUTO MODE has fixed setpoints of 68° F heating and 77° F cooling, which are not adjustable. The system will automatically select heating or cooling to maintain room temperature within this band.
  • Page 9 SYSTEM FUNCTIONS POLYMERIC AIR FILTER The polymeric mesh filters save energy by preventing the indoor coils from being plugged with dirt and lint. This economical and sturdy filter may be washed, vacuumed and reused. FAHRENHEIT °F / CELSIUS °C The remote controller and indoor wall unit front panel can be set to display in either °F or °C. PRIVACY LOCK MODE The wireless remote controller has a Lock feature.

  • Page 10: Operation Of Wireless Remote Contoller

    OPERATION OF WIRELESS REMOTE CONTROLLER Remote Controller ON/OFF button MODE button FAN button SWING button TURBO button MODE ▲/ button SWING TURBO SLEEP button TEMP SLEEP TEMP button WiFi CLOCK LIGHT WiFi button TIMER TIMER LIGHT button CLOCK button TIMER ON / TIMER OFF button Introduction for icons on display screen Set fan speed...
  • Page 11 OPERATION OF WIRELESS REMOTE CONTROLLER Note: ● This is a general use remote controller, it could be used for the air conditioners with multifunction; For some function, which the model doesn't have, if press the corresponding button on the remote controller that the unit will keep the original running status.
  • Page 12 OPERATION OF WIRELESS REMOTE CONTROLLER ● When selecting fan mode, the air conditioner will only blow fan, no cooling and no heating. Press "FAN" button to adjust fan speed. Press "SWING" button to adjust fan blowing angle. ● When selecting heating mode, the air conditioner operates under heat mode. Heat indicator on indoor unit is ON(This indicator is not available for some models).
  • Page 13 OPERATION OF WIRELESS REMOTE CONTROLLER ● When selecting " ", air conditioner is blowing fan automatically. Horizontal louver will automatically swing up & down at maximum angle. ● When selecting " 、 、 、 、 ● When selecting " 、 、 ●...
  • Page 14 OPERATION OF WIRELESS REMOTE CONTROLLER ● When selecting " " or no display with remote controller, temperature indicator on indoor unit displays set temperature. ● When selecting " " with remote controller, temperature indicator on indoor unit displays indoor ambient temperature. ●...
  • Page 15 OPERATION OF WIRELESS REMOTE CONTROLLER ● TIMER ON button "TIMER ON" button can set the time for timer on. After pressing this button, " " icon disappears and the word "ON" on remote controller blinks. Press "▲" or " "button to adjust TIMER ON setting. After each pressing "▲" or " "...
  • Page 16 OPERATION OF WIRELESS REMOTE CONTROLLER Auto clean function Under unit off status, hold "MODE" and "FAN" buttons simultaneously for 5s to turn on or turn off the internal clean function. When the internal clean function is turned on, indoor unit displays “CL”. (This function is applicable for some models) During the self-cleaning process of evaporator, the unit will perform fast cooling or fast heating.
  • Page 17 OPERATION OF WIRELESS REMOTE CONTROLLER will automatically adjust the indoor temperature according to the detected tempera- ture. Press this two buttons simultaneously again to close I FEEL function and " " will disappear. ● Please put the remote controller near user when this function is set. Do not put the remote controller near the object of high temperature o r low temperature in order to avoid detecting inaccurate ambient temperature.When I FEEL function is turned on, the remote controller should be put within the area where indoor...

  • Page 18: Damaged Or Lost Remote Controller

    DAMAGED OR LOST REMOTE CONTROLLER If remote controller is lost or damaged, the Liv system can be turned off directly from the in- door unit. Lift the front panel of the indoor wall unit, then press the AUX button to turn on or turn off.

  • Page 19: Care And Cleaning

    CARE AND CLEANING W RNING Take notice of the following items before cleaning your Liv indoor wall unit. • To avoid electric shock or injury, do not attempt to clean the unit unless it has been turned off and the indoor and outdoor units have been disconnected from the main power supply. •...

  • Page 20: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE/SOLUTION System does not restart. Cause: The system has a built-in three-minute delay to prevent short and/or rapid cycling of the compressor. Solution: Wait three minutes for the protection delay to expire. Indoor unit emits unpleasant odor Cause: Typically unpleasant odors are the result of mold or mildew forming on when started.
  • Page 21 TROUBLESHOOTING PROBLEM CAUSE/SOLUTION Water leaking from the indoor Cause: While it is normal for the system to generate condensate water in cooling unit into the room. mode, it is designed to drain this water via a condensate drain system to a safe location. Solution: If water is leaking into the room, it may indicate one of the following.

  • Page 22: Energy Saving Tips

    ENERGY SAVING TIPS 1. Reduce room setpoint at night: During the nighttime hours you don't require the same level of conscious cooling or heating. Try using Sleep Mode to gradually relax room temperature and allow the unit to run less and save energy. 2.

  • Page 23: Warranty

    Phone No. / E-mail GREE distributor (hereinafter “Company”) warrants this product against failure due to defect in materials or workmanship under normal use and maintenance as follows. All warranty periods begin on the date of original installation. If the date cannot be verified, the warranty period begins one hundred twenty (120) days from date of manufacture.
