- Page 1 HIGH-WALL DUCTLESS AIR CONDITIONING & HEATING SYSTEM OWNER’S MANUAL Models: 3VIR09HP230V1AH 3VIR09HP115V1AH 3VIR12HP230V1AH 3VIR12HP115V1AH 3VIR18HP230V1AH 3VIR24HP230V1AH...
-
Page 2: Table Of Contents
CONTENTS II-V Explanation of Symbols and Statements ............. 01-04 Safety precautions .................. Parts name ....................06-11 Operation and introduction of remote contr oller ......... Clean and maintenance ................Checked items before maintenance ............. 14-15 Installation notice ..................16-18 Installation of indoor unit ................ - Page 3 Explanation of Symbols WARNING This symbol indicates the possibility of death or serious injury. This symbol indicates the possibility of injury or damage to CAUTION property. Indicates important but not hazard-related information, used NOTICE to indicate risk of property damage. Exception Clauses Manufacturer will bear no responsibilities when personal injury or property loss is caused by the following reasons.
- Page 4 Fcc Warning WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Fcc Statement This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received,including interference that may cause undesired operation.
- Page 5 Ic Statement This equipment complies with FCC’s and IC’s RF radiation exposure limits set forth for an uncontrolled environment. The antenna(s) used for this transmitter must be installed and operated to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter.
-
Page 6: Safety Precautions
Safety precautions WARNING Installation Grounding of units must Installation or maintenance comply with the National must be performed by qua- Electrical Code and local lified professionals. codes. The appliance shall be in- Air Conditioner should be stalled in accordance with properly grounded. - Page 7 Safety precautions CAUTION Installation A circuit breaker must be Instructions for installation and use of this product are installed in the line. provided by the manufac- The yellow-green wire is turer. the ground wire it cannot be used for any other Select a location which is purpose.
- Page 8 Safety precautions WARNING Operation and Maintenance to a dedicated circuit breaker. This appliance can be used by children aged from 8 Disconnect power supply years and above and per- when cleaning air condit- ioner, to avoid an sons with reduced physi- electrical shock.
- Page 9 Safety precautions CAUTION Operation and Maintenance frequently. To avoid damaging the A burning smell coming remote controller, do not from the air conditioner. spill water on it. Indoor unit is leaking. To avoid damage when drying the air filter, do not use a flame or hair dryer.
-
Page 10: Parts Name
Parts name Indoor Unit air inlet panel filter aux. button panel upper air guide louver air outlet lower air guide louver ■ If remote controller is lost or damaged, please use aux. button to turn on or turn off the air conditioner. -
Page 11: Operation And Introduction Of Remote Controller
Operation and introduction of remote controller Introduction for icons on display Buttons on remote controller screen I feel Set fan speed Turbo mode Send signal Auto mode Cool mode Dry mode Fan mode Heat mode Sleep mode 8℃ heating function Power limiting operation Health mode ON/OFF... - Page 12 Introduction for buttons on adjust fan blowing angle. remote controller When selecting heating mode, the air condition- er operates under heat mode. Press " " or " " NOTE button to adjust set temperature. Press "FAN" ● This is a general use remote controller. It could be button to adjust fan speed.
- Page 13 turn to quick COOL or quick HEAT mode. " " ically swing up & down at maximum angle. icon is displayed on remote controller. Press this ● When selecting " " , air condition- 、 、 、 、 button again to exit turbo function and " "...
- Page 14 Sleep, circulate between these, after electrified, NOTE Sleep Cancel is defaulted. ● Under on and off status, you can set T-OFF or T-ON Sleep 1 is Sleep mode 1, in Cool modes; sleep ● simultaneously. ● status after run for one hour, the main unit setting Before setting T-ON or T-OFF, please adjust the clock time.
- Page 15 Function introduction for WiFi combination buttons Press " WiFi " button to turn on WiFi function, "WiFi " icon will be displayed on the remote controller; Energy-saving function Hold " WiFi " button for 5s to turn off WiFi function and "...
- Page 16 When the remote controller is turned off, power ● Child lock function limiting function is cancelled. If you want to acti- vatethe function, please repress this button. Press " " and " " simultaneously to turn on or If the current power is lower than the maximum ●...
-
Page 17: Clean And Maintenance
Clean and maintenance WARNING ■ The filter should be cleaned every three months . If there is much dust in the operation environme- WARNING nt, clean frequency can be increased. ■ Turn off the air conditioner and disconnect the ■ After removing the filter, do not touch fins to power before cleaning the air conditioner to av- avoid injury. -
Page 18: Checked Items Before Maintenance
Checked items before maintenance Phenomenon Solution Check items General phenomenon analysis Whether there’s od- Eliminate the odour Odours are our source, such as Please check below ite ms before asking for source. Clean the furniture and cigare- emitted filter. maintenance. If the malfunction still can’t be tte, etc. -
Page 19: Installation Notice
Installation notice WARNING sure that the unit is running in cooling mode. Then, fully close the valve at high pressure side (liquid valve). About 30-40 seconds later, fully close the valve at low pressure side (gas valve), immediately stop the unit and disconnect power. - Page 20 Selection of installation location Requirements for electric connection Basic requirement 7.If the supply cord is damaged, it must be repla- Installing the unit in the following places may cau- ced by the manufacturer, its service agent or se malfunction. If it is unavoidable, please consu- similarly qualified persons in order to avoid a lt the local dealer: hazard .
-
Page 21: Installation Of Indoor Unit
Installation of indoor unit NOTE Indoor outdoor ● Pay attention to dust prevention Step 1: sures when opening the hole. Choose installation location 2.2 in 5-10 2.75 in Recommend the installation location to the client and then confirm it with the client. Step 2: Step 4: Install wall-mounting frame... - Page 22 Tightening torque (N . m) drain hose Hex nut diameter 1/4'' 15~20 3/8'' 30~40 1/2'' 45~55 insulating pipe 5/8'' 60~65 NOTE 3/4'' 70~75 ● Add insulating pipe in the indoor drain hose in order to prevent condensation. ● The plastic expansion particles are not provided. Wrap the indoor pipe and joint of connection pipe with insulating pipe, and then wrap it Step 7:...
- Page 23 drain hose connection pipe 3. Remove the wire clip; connect the power conn- band ection wire to the wiring terminal according to the color; tighten the screw and then fix the po- wer connection wire with wire clip. indoor power cord Bind them evenly.
-
Page 24: Test And Operation
Test and operation Check after installation ● Check according to the following requirement after finishing installation. Items to be checked Possible malfunction Has the unit been The unit may drop, shake or installed firmly? emit noise. It may cause insufficient Have you done the refri- cooling(heating) capacity. -
Page 25: Configuration Of Connection Pipe
Configuration of connection pipe Additional refrigerant charging amount for R410A Standard length of connection pipe: 15 ft, 25 ft. Piping size Outdoor unit throttle Min. length of connection pipe is 10 ft. Clg and Max. length of connection pipe is shown as below. Liquid pipe Gas pipe htg (oz/ft) - Page 26 B: Remove the burrs smooth surface ● Remove the burrs with shaper and prevent the burrs from getting into the pipe. improper expanding pipe shaper leaning damaged crack uneven surface thickness downwards the length is equal Working temperature range C: Put on suitable insulating pipe 3VIR09HP230V1AH, 3VIR12HP230V1AH, 3VIR18HP230V1AH, 3VIR24HP230V1AH D: Put on the union nut...
-
Page 27: Energy Saving Tips
ENERGY SAVING TIPS 1. Reduce room setpoint at night: During the nighttime hours you don't require the same level of conscious cooling or heating. Try using Sleep Mode to gradually relax room temperature and allow the unit to run less and save energy. 2. -
Page 28: Warranty
Phone No. / E-mail GREE distributor (hereinafter “Company”) warrants this product against failure due to defect in materials or workmanship under normal use and maintenance as follows. All warranty periods begin on the date of original installation. If the date cannot be verified, the warranty period begins one hundred twenty (120) days from date of manufacture.
