SATO PV3 Connection Manual

Wireless lan connection
Hide thumbs Also See for PV3:

Advertisement

Quick Links

Download this manual
Wireless LAN Connection Manual
BARCODE PRITNER
Rev. 1.00
PV3

Advertisement

loading
Need help?

Need help?

Do you have a question about the PV3 and is the answer not in the manual?

Questions and answers

Related Manuals for SATO PV3

Summary of Contents for SATO PV3

  • Page 1 Wireless LAN Connection Manual BARCODE PRITNER Rev. 1.00...

  • Page 2: Table Of Contents

    Wireless LAN Connection Manua l ■ Table of Contents 1. Manual Information ......................3 2. Precautions ........................3 3. How to Connect ......................4 3-1 Android Soft AP mode (default) .................. 6 3-2 iOS Soft AP mode (default) ..................7 3-3 How to change infrastructure mode ................

  • Page 3: Manual Information

    This Wireless LAN manual provides information on the connection of a wireless network with the mobile printer. We at SATO maintain ongoing efforts to enhance and upgrade the functions and quality of all our products. The following product specifications and/or user manual content may be changed without prior notice.

  • Page 4: How To Connect

    Wireless LAN Connection Manua l 3. How to Connect Wireless LAN can be configured through the printer’s Wireless LAN interface. Likewise, Wireless LAN can also be configured though the printer’s Serial/USB interfaces. (1) Connecting Printer 1) Serial / USB cable Connect Serial/USB cable to Printer, PC device.
  • Page 5 Wireless LAN Connection Manua l (2) Checking Network Setting Self-test Power FEED While the printer is turned off, turn on the printer while pressing the feed button. The printer setting values will then be printed. - 5 - Rev. 1.00...

  • Page 6: Android Soft Ap Mode (Default)

    Wireless LAN Connection Manua l 3-1 Android Soft AP mode (default) 1) Select “Wi-Fi”. 2) Select the printer to connect 3) Select “CONNECT”. 4) Wi-Fi communication is available - 6 - Rev. 1.00...

  • Page 7: Ios Soft Ap Mode (Default)

    Wireless LAN Connection Manua l 3-2 iOS Soft AP mode (default) 1) Select “Wi-Fi”. 2) Wi-Fi ON and Select the printer to connect 3) Wi-Fi communication is available - 7 - Rev. 1.00...

  • Page 8: How To Change Infrastructure Mode

    Wireless LAN Connection Manua l 3-3 How to change infrastructure mode 1) Enter the IP address of the printer in the address bar, and the following login window will pop up. Enter the ID and Password set for the printer, and then click [LOG IN] (Default User Name: admin, Password: password) 2) Select “Wireless”...
  • Page 9 Wireless LAN Connection Manua l 3) Select “infrastructure”, and set SSID, WLAN Security Type. 4) Reboot the Printer. - 9 - Rev. 1.00...

  • Page 10: Factory Reset

    Wireless LAN Connection Manua l 4. Factory Reset This function changes the Wireless LAN settings of the printer to the initial factory settings. Method Select the wireless interface on the printer's LCD screen. Wireless LAN Factory reset is available in WLAN> ON / OFF> Factory Reset When the printer is turned off, the Wireless LAN setting is applied as the factory default Factory Reset Values Printer Name...
  • Page 11 Wireless LAN Connection Manua l WPA 1/2 – Enterprise (EAP-TLS, EAP-TTLS, PEAP, LEAP, EAP-FAST) Management Net Configuration tool, HTTP, Smart connection APP - 11 - Rev. 1.00...
