M15W Instruction Manual
PACKAGE CONTENTS
The items below are included with this product. If any item is
missing, contact the dealer from whom you purchased this product.
Power adapter/
M15W unit
Power plug
Instruction manual
Wi-Fi Dongle
OPTIONAL ACCESSORIES
Carrying Bag
Anti-glare Sheet
MORE HELP
For FAQs, technical support, software and instruction manual
download, please visit:
https://www.averusa.com/education/support/
P/N: 300APW00-???
HARDWARE PARTS
USB cable
1. Camera head
3. Arm
5. Wi-Fi dongle
7. HDMI output
CONTROL PANEL
1
2
3
1. Power indicator
2. Wi-Fi indicator
3. Battery indicator
4. Power button
(on/off/standby)
5. Freeze
2
3
4
5 6 7
8
2. LED lighting
4. Control panel
6. USB port
8. DC power jack
4
6
8
5
7
9
6. Lamp(on/off)
7. Auto focus
8. Zoom in
9. Zoom out
10. Built-in MIC
LED INDICATOR
1
Power
Solid green: Power on
No light: Power off
Solid red: Standby mode
Solid blue: AP Mode Ready / STA connected
Wi-Fi
Slow flashing blue: Software connection
with camera
Short flashing blue: Create AP mode / STA
connecting
Solid green: Miracast mode ready
Slow flashing green: Miracast streaming
start
Quick flashing green: Miracast device scan /
connecting
Solid green(x3): Battery is full(100% ~ 60%)
Battery
Solid green(x2): Battery is 60% ~ 30%
Solid green(x1): Battery is 30% ~ 5%
Solid red (x1): Battery is 5% ~ 0%
Flashing red (x1): Battery is out of power
Solid orange(x3): Battery is abnormal
[Note]
1. The battery will be exhausted for long-term usage. Do not
replace the battery by yourself. Please contact your dealer.
2. To complete turn off camera,
button.
10
COMPOUND KEY
Snapshot the current
screen image to software
or cloud.
press and long press the power
