STOKVIS ENERGY SYSTEMS Evolution Series Options & Systems Planner Manual

Gas -fired, floor standing condensing boiler
Hide thumbs
Table of Contents

Advertisement

Quick Links

R600 (Evolution Range)
Gas-Fired, Floor Standing
Condensing Boiler
Options & System
Planner Manual
STOKVIS ENERGY SYSTEMS
Unit 34 Central Park Estate
34 Central Avenue
West Molesey
Surrey
KT8 2QZ
Tel: 020 8783 3050
Fax: 020 8783 3051
E-Mail:
info@stokvisboilers.com
Website:
www.stokvisboilers.com
2017-03 PL EN v3 Doc202-V2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Evolution Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STOKVIS ENERGY SYSTEMS Evolution Series

Summary of Contents for STOKVIS ENERGY SYSTEMS Evolution Series

  • Page 1 R600 (Evolution Range) Gas-Fired, Floor Standing Condensing Boiler Options & System Planner Manual STOKVIS ENERGY SYSTEMS Unit 34 Central Park Estate 34 Central Avenue West Molesey Surrey KT8 2QZ Tel: 020 8783 3050 Fax: 020 8783 3051 E-Mail: info@stokvisboilers.com Website: www.stokvisboilers.com...

  • Page 2: Table Of Contents

    Contents Models and output ....................4 Gas condensing boiler R600 EVO Application possibilities..................4 Value propositions ....................4 Description ......................4 Technical description Technical data ....................... 5 Product information ErP ..................8 Dimensions ......................9 Declaration of conformity ..................10 Extent of delivery ....................
  • Page 3 Contents System selection ....................24 Accessories Accessories 2x max. Water pressure switch + 1x external high limit thermostat ..... 25 Max. gas pressure switch ..................25 External high limit thermostat ................25 Gas valve leakage tester ..................25 INAIL kit (Italy only) ..................... 25 Plate heat exchanger + connection kit ..............

  • Page 4: Gas Condensing Boiler R600 Evo Models And Output

    Gas condensing boiler R600 EVO Models and output Application possibilities Value propositions Technical description Models and output Application possibilities Value propositions The floor standing gas condensing boi- The gas condensing boiler R600 EVO  Unique reliability ler R600 EVO is available in 7 types is applicable for alle central heating proven technology with exceptional within an output range from 142 until...

  • Page 5: Technical Data

    Technical description Technical data R601 EVO R602 EVO R603 EVO Nominal heat output at 80/60ºC max/min 142,3/31,3 190,4/42,0 237,6/47,0 Nominal heat output at 40/30ºC max/min 151,2/35,4 202,3/47,4 252,3/53,4 Nominal heat input Hi max/min 145,0/32,2 194,0/43,1 242,0/48,4 Efficiency at 80/60ºC 98,2 98,2 98,2 Efficiency at 40/30ºC...
  • Page 6 Technical description Technical data R604 EVO R605 EVO R606 EVO R607 EVO Nominal heat output at 80/60ºC max/min 285,7/56,5 381,3/75,2 476,7/94,6 540,2/120,0 303,3/64,2 404,3/85,6 505,2/106,9 572,8/135,1 Nominal heat output at 40/30ºC max/min Nominal heat input Hi max/min 291,0/58,2 388,0/77,6 485,0/97,0 550,0/122,2 Efficiency at 80/60ºC 98,2...
  • Page 7 Technical description Technical data R600 EVO (Italy only) Nominal heat output at 80/60ºC max/min 113,7/31,3 343,5/75,2 Nominal heat output at 40/30ºC max/min 120,8/35,4 363,6/85,6 Nominal heat input Hi max/min 115,8/32,2 349,0/77,6 Efficiency at 80/60ºC 98,2 98,3 Efficiency at 40/30ºC 104,3 104,2 RAL 40/30 average 110,4...

  • Page 8: Product Information Erp

    Technical description Product information E.r.P. Product information about the directive 2009/125/EG and regulation (EU) 811-813/2013 R601 R602 R603 R604 R605 Symbol Unit 115 * 350 * Condensing boiler Low-temperature boiler B1 boiler Cogeneration space heater Combination heater ErP HEATING 1) by return temperature 30°C 2) by return temperature and feed temperature (60-80°C) Rated heat boiler rated At rated heat output and high-temperature...

  • Page 9: Dimensions

    Technical description Dimensions R601-R602-R603 EVO R601 EVO R602 EVO R603 EVO R604 EVO R605 EVO R606 EVO R607 1349 1499 1649 1348 1496 1646 1769 1165 1315 1465 1152 1302 1452 1602 Ø 130 Ø 150 1.1/2" 2" W1-W2-W3 R2" DN65 PN16 R604-R605-R606-R607 EVO...

  • Page 10: Declaration Of Conformity

    Technical description Declaration of conformity Declaration of Conformity ELCO BV, Hamstraat 76, 6465 AG Kerkrade (NL), Declares that the product R600 EVO Is in conformity with the following standards: EN 15502-1 EN 15502-2-1 EN 55014-1 / -2 EN 61000-3-2 /-3 EN 60 335-1/ -2 And in accordance with the guidelines of directives: 92 / 42 / EEC (boiler efficiency directive)

  • Page 11: Extent Of Delivery

    Technical description Extent of delivery Boiler transport Boiler installation Standard boiler A boiler delivery package contains the following components: Component Package Pcs. Boiler fully assembled and tested On wooden pallet, sealed in PE foil Syphon for condensate connection In plastic bag on back of boiler Conversion kit for propane incl.

  • Page 12: Norms And Regulations Regulations

    Norms and regulations This documentation contains This boiler is CE approved and applies - EN 60335-2-102: 2016 Household important information, which is a base to the following European standards: - 1992 / 42 / EEC Boiler efficiency for safe and reliable installation, com- and similar appliances - Safety - Part missioning and operation of the boiler.

  • Page 13: Maintenance

    Norms and regulations Maintenance Fuel Combustion air Water quality Maintenance Fuel Combustion air Regular maintenance is necessary to The gas condensing boiler R600 EVO The gas condensing boiler R600 EVO secure a safe and economical operati- is applicable for gases G20, G25, G30 can be used in both non-roomsealed on of the installation.

  • Page 14: Noise Protection

    Norms and regulations Noise protection Antifreeze Noise protection The R600 EVO is supplied with ad- The gas condensing boiler R600 EVO justable feet, which also prevent the is equipped with a patented premix transmission of vibration noise from the burner. The noise level of this very boiler into the building.

  • Page 15: Flue Gas System Requirements And Regulations

    Flue gas system Requirements and regulations Materials Flue gas data Requirements and regulations Materials Plastic Stainless Regulations for the construction of flue Exclusively materials, which are heat steel gas systems are very different for each resistant and resistant to flue gases Temperature country.

  • Page 16: Dimensioning

    Flue gas system Dimensioning Dimensioning VERSION 1 When dimensioning a flue gas system, Calculation base: it’s necessary to perform a calculation Total connection length in boiler room ≤ 1.5 m; check of the flue gas system in order to 2x 87°-bend verify if the choosen system is appli- Maximum permissible height (h) of cable.

  • Page 17: Neutralisation General

    Neutralisation General Neutralisation systems Standard neutralisation system (DN) Neutralisation system with pump (HN) General The maximum amount of condensate Condensate, created by the R600 EVO, for each boiler type can be found in the should be drained into the public drai- chapter „Technical data“.

  • Page 18: Hydraulic Connection Hydraulic Resistance

    Hydraulic connection Hydraulic resistance ∆T-measurement ∆p-measurement Water flow data Hydraulic resistance The hydraulic resistance depends on 100,0 the flow rate through the boiler and the boiler type. In the graph the resistance for a specific flow rate can be found. The R600 EVO is able to control a speed controlled pump via PWM or a 0-10VDC signal.

  • Page 19: Hydraulic Connection Into A System

    Hydraulic connection Hydraulic connection into a system Standard Bypass Hydraulic connection into a system  Details to the 3 possibilities mentioned Standard, with low loss header or The R600 EVO must be connected in above, can be found in the next sec- plate heat exchanger such a way, that a minimum flow rate of tions.

  • Page 20: Split System

    Hydraulic connection Split System Split System The split system boiler enables the connection of two returns with different water temperatures. By evasing the low loss header the cold return water enters the condensor of the boiler directly, without mixing with the high temepra- ture return water (f.e.

  • Page 21: Controls Basic Controls And Connections

    Controls Basic controls and connections Control by building managemant system Boiler enable signal Temperature or capacity setpoint Basic controls and connections   Electronic high limit thermostat Weather compensation (with optional The standard version of the R600 EVO  outdoor sensor) Electronic flue gas temperature limiter is equipped with a LMS14 boiler ma- ...

  • Page 22: Capacity Feedback Signal

    Controls Capacity feedback signal OK/Alarm output signal Capacity feedback signal, terminals Capacity feedba ck 120-121 (0-10VDC) This signal is available at the mentio- ned terminals, when the burner is acti- ve. The following graph shows the valu- e of the signal. [VDC] Alarm output signal, terminals 9 (L) - 10 (N) (230VAC) or extension...

  • Page 23: Heating Zone Control

    Controls Heating zone control Cascade control Heating zone control Cascade control The R600 EVO can be extended with The R600 EVO can be controlled in a an AVS75 controller for extended hea- cascade system of maximum 8 boilers. ting zone control. The AVS75 enables This can be done by using the in- weather compensated operation of one tegrated Master/Slave cascade functio-...

  • Page 24: Accessories System Selection

    Accessories System selection The R600 EVO is supplied from the factory with LMS14 boiler manage- ment unit. Additional a wide variation of accessory kits is available. The accessory kits are specially designed for the R600 EVO and are very easy to combine with the boiler to create a complete system solution. System selection The plug &...

  • Page 25: Accessories

    Accessories Safety devices 2x max. Water pressure switch + Max. gas pressure switch External high limit thermostat pressure gauge The kit includes a gas pressure There is a connection point for the The pre-assembled kit can be con- switch, which can be connected di- high limit stat on the boiler flow pipe.

  • Page 26: Plate Heat Exchanger + Connection Kit

    Accessories Hydraulics Data secundary circuit PHE Plate heat exchanger + connection ΔT=10K ΔT=15K ΔT=20K The kit contains a plate heat ex- /h] [kPa] [m /h] [kPa] [m /h] [kPa] changer including connection materi- al, automatic de-aerator, expansion R601 12,3 28,7 13,1 vessel and flow pipe.

  • Page 27: Bend 90

    Accessories Hydraulics R601-R603 EVO R604-R607 EVO DUO Weiche DUO Weiche (DN150) (DN200) 2x Bends 90 Flow adapter + NRV 2nd Return connection The kit contains 2 90° bends to allow The kit contains a flow adapter The kit contains a pipe which can be (extension part for the flow pipe) and used as 2nd (hot) return connection a flexible set up.

  • Page 28: Safety Valve (3-6 Bar) + Manometer

    Accessories Hydraulics Safety valve (3-6 bar) + pressure Bypass gauge The kit includes a bypass pump inclu- The kit includes a safety valve (3 or 6 ding connection material. The kit is to bar) and a pressure gauge. be connected between the flow and 2nd return connection of the boiler.
  • Page 29 Accessories Hydraulics...

  • Page 30: Receiver Wireless Avs71

    Accessories Controls Receiver wireless AVS71 Outdoor sensor wireless AVS13 Room unit QAA75 The kit contains an AVS71 wireless The kit contains an outdoor sensor The kit contains a QAA75 room unit, receiver. When connected to the QAC34 and a wireless transmitter which communicates with the boiler boiler, it can transmit data between AVS13.

  • Page 31: Header/Hot Water Sensor Qaz36

    Accessories Controls Header/hot water sensor QAZ36 Heating zone sensor QAD36 Outdoor sensor QAC34 The kit contains a header/hot water The kit contains a clamp sensor The kit contains an outdoor sensor sensor QAZ36 with 6m cable and a QAD36 with 4m cable. QAC34.

  • Page 32: Gas Filter

    Accessories Other Gas filter Gas pressure regulator 100mbar Air filter + connection kit The kit contains a gas filter which can The kit contains an air filter which can be connected directly to the gas pipe The kit contains a gas pressure regu- be connected directly to the air intake of the boiler.

  • Page 33: Installation Examples 2-A-C: 1 Heating Zone + Low Loss Header

    Installation examples 2-A-C: 1 heating zone + low loss header 2-A-C: 1 heating zone + low loss header Description  R600 EVO with low loss header  Weather compensated control  1 mixed heating zone Tips  Complete accessory kits with low loss header are available for ∆T=10-20K (see chapter „Accessories“).

  • Page 34: 2-5-A-C: 1 Heating Zone And Sanitary Hot Water + Low Loss Header

    Installation examples 2-5-A-C: 1 heating zone and sanitary hot water + low loss header 2-5-A-C: 1 heating zone and sanitary hot water + low loss header Description  R600 EVO with low loss header  Weather compensated control  1 mixed heating zone ...

  • Page 35: 4-A-C: 2 Heating Zones + Low Loss Header

    Installation examples 4-A-C: 2 heating zones + low loss header 4-A-C: 2 heating zones + low loss header Description  R600 EVO with low loss header  Weather compensated control  2 mixed heating zones Tips  Complete accessory kits with low loss header are available for ∆T=10-20K (see chapter „Accessories“).

  • Page 36: 4-5-A-C: 2 Heating Zones And Sanitary Hot Water + Low Loss Header

    Installation examples 4-5-A-C: 2 heating zones and sanitary hot water + low loss header 4-5-A-C: 2 heating zones and sanitary hot water + low loss header Description  R600 EVO with low loss header  Weather compensated control  2 mixed heating zones ...

  • Page 37: A-C: Boiler Control Via 0-10Vdc + Low Loss Header

    Installation examples A-C: Boiler control via 0-10VDC + low loss header A-C: Boiler control via 0-10VDC + low loss header Description  R600 EVO with low loss header Tips  Complete accessory kits with low loss header are available for ∆T=10-20K (see chapter „Accessories“).

  • Page 38: 2-B-C: 1 Heating Zone + Plate Heat Exchanger

    Installation examples 2-B-C: 1 heating zone + plate heat exchanger 2-B-C: 1 heating zone + plate heat exchanger Description  R600 EVO with plate heat exchanger  Weather compensated control  1 mixed heating zone Tips  Complete accessory kits with plate heat exchanger are available for ∆T=10-20K (see chapter „Accessories“).

  • Page 39: 2-5-B-C: 2 Heating Zones And Sanitary Hot Water + Plate Heat Exchanger

    Installation examples 2-5-B-C: 2 heating zones and sanitary hot water + plate heat exchanger 2-5-B-C: 2 heating zones and sanitary hot water + plate heat exchanger Description  R600 EVO with plate heat exchanger  Weather compensated control  1 mixed heating zone ...

  • Page 40: 4-B-C: 2 Heating Zones + Plate Heat Exchanger

    Installation examples 4-B-C: 2 heating zones + plate heat exchanger 4-B-C: 2 heating zones + plate heat exchanger Description  R600 EVO with plate heat exchanger  Weather compensated control  2 mixed heating zones Tips  Complete accessory kits with plate heat exchanger are available for ∆T=10-20K (see chapter „Accessories“).

  • Page 41: 4-5-B-C: 2 Heating Zones And Sanitary Hot Water + Plate Heat Exchanger

    Installation examples 4-5-B-C: 2 heating zones and sanitary hot water + plate heat exchanger 4-5-B-C: 2 heating zones and sanitary hot water + plate heat exchanger Description  R600 EVO with plate heat exchanger  Weather compensated control  2 mixed heating zones ...

  • Page 42: B-C: Boiler Control Via 0-10Vdc + Plate Heat Exchanger

    Installation examples B-C: Boiler control via 0-10VDC + plate heat exchanger B-C: Boiler control via 0-10VDC + plate heat exchanger Description  R600 EVO with plate heat exchanger Tips  Complete accessory kits with plate heat exchanger are available for ∆T=10-20K (see chapter „Accessories“).

  • Page 43: 4-5-A-C-E: 2 Heating Zones And Sanitary Hot Water + Cascade Via Low Loss Header

    Installation examples 4-5-A-C-E: 2 heating zones and sanitary hot water + cascade via low loss header 4-5-A-C-E: 2 heating zones and sanitary hot water + cascade via low loss header Description  2x R600 EVO with low loss header  Cascade control + weather compen- sation ...

  • Page 44: Extension 2 Heating Zones

    Installation examples Extension 2 heating zones Extension 2 heating zones Description  Weather compensated controller with wall hung box LOGON B  Extension of 2 heating zones Tips  The extension controller should al- ways be used in combination with the integrated boiler controller LMS14 ...

  • Page 45: Technical Data Country Specific

    Technical Data Country specific Germany/Austria/Switzerland: EnEV (Anlagenaufwandzahl, DIN V4701-10) R601 R602 R603 R604 R605 R606 R607 Nominal heat output at 80/60°C 142,3 190,4 237,6 285,7 381,3 476,7 540,2 113,7 343,0 Nominal heat output at 40/30°C 151,2 202,3 252,3 303,3 404,3 505,2 572,8 120,8...
  • Page 46 Technical Data Country specific RT2012 (France only) R601 R602 R603 R604 R605 R606 R607 Nominal heat output at 80-60ºC 142,3 190,4 237,6 285,7 381,3 476,7 540,2 113,7 343,0 Minimal heat output at 80-60ºC 31,3 42,0 47,0 56,5 75,2 94,6 120,0 31,3 75,2 Efficiency at 80/60ºC full load...

  • Page 47: Norms

    Norms Germany: Austria: Italy:   Sicurezza degli impianti DIN EN 483 ÖNORM H 5152: Brennwert-   Legge 5 marzo 1990 n. 46 Feuerungsanlagen, Planungshilfen DIN EN 677    ÖNORM M 7443: Gasgeräte mit D.P.R. 6/12/91 n. 447 DIN EN 13384-1 ...
  • Page 48 STOKVIS ENERGY SYSTEMS Unit 34 Central Park Estate 34 Central Avenue West Molesey Surrey KT8 2QZ Tel: 020 8783 3050 Fax: 020 8783 3051 E-Mail: info@stokvisboilers.com Website: www.stokvisboilers.com 420010719800 03/2016 – Doc202-V2...
