Infinity Beta SW Series Service Manual page 23

CSW-10
Part number Qty
DRIVER PCB
034-330615-301 1 Electrolytic Cap.
031-100144-106F 4 SMD Cap.
031-100343-100F 2 SMD Cap.
031-100344-100F 6 SMD Cap.
031-180344-100F 2 SMD Cap.
031-470244-102F 4 SMD Cap.
031-560243-100F 4 SMD Cap.
031-560343-101F 1 SMD Cap.
Semiconductors
051-000600-100 1 Transistor NPN
051-222200-100 2 Trasistor NPN (ON SEM)
051-555100-000 2 Transistor NPN
053-211100-000 2 IC;DIP,DRIVER
054-000100-100 2 SMD DIODE
054-001002-100 2 SMD ZENER DIODE
054-005501-100 1 SMD ZENER DIODE
054-007200-100L 2 SMD IC; DUAL OP-AMP
054-033906-100 2 SMD PNP Transistor
054-050601-100 2 SMD ZENER DIODE
054-414803-100 5 SMD DIODE
054-540100-100 2 SMD Transistor (PNP)
054-555100-100 1 SMD Transistor (NPN)
Miscellaneous
072-040229-000 1 HEADER Right Angle
072-040230-000 1 HEADER Right Angle
PREAMP/RABOS PCB
021-100398-100 1 MF Resistor
021-100498-100 2 MF Resistor
021-100598-100 9 MF Resistor
021-100798-100 1 MF Resistor
021-100898-100 1 MF Resistor
021-110698-100 1 MF Resistor
021-120598-100 2 MF Resistor
021-140598-100 1 MF Resistor
021-150198-100 1 MF Resistor
021-162398-100 1 MF Resistor
021-267498-100 1 MF Resistor
021-330498-100 1 MF Resistor
021-330598-100 1 MF Resistor
021-340398-100 2 MF Resistor
021-357498-100 1 MF Resistor
021-470598-100 1 MF Resistor
021-549398-100 1 MF Resistor
021-590498-100 1 MF Resistor
021-619498-100 2 MF Resistor
021-680398-100 1 MF Resistor
021-787398-100 2 MF Resistor
021-909398-100 1 MF Resistor
021-931498-100 1 MF Resistor
Description
330uF/16V M (R)0812 P:3.5
0u01/50V K 0805 X7R
100pF/50V J 0805 NPO
0u1/50V K 0805 X7R
0u18/50V K 0805 X7R
0u047/50V K 0805 X7R
56pF/50V J 0805 NPO
560pF/50V J 1206 X7R
PN:MPSW06RLRA TO-92 (ON)
PN:MPS2222ARLRA TO-92
PN:2N5551 TO-92
PN:IR2111 8PIN (IR)
PN:ES1D 200V 1A
PN:BZX84C10 10V SOT-23
PN:BZV55C3V6 (PHILIPS)
PN:M072M-TE1 DMP8 (JRC)
PN:MMBT3906LT1 SOT23 (ON
PN:BZX84C5V6 5.6V SOT-23 TAPIN
PN:LL4148 (Wishay)
PN:MMBT5401 LT1 SOT-23
PN:MMBT5551 LT1 (ON)
PN:211-107-000-400 7PIN
PN:211-111-000-400 11PIN
100R 1/8W F
1K 1/8W F
10K 1/8W F
1M 1/8W F
10M 1/8W F
110K 1/8W F
12K 1/8W F
14K 1/8W F
1K5 1/8W F
162R 1/8W F
2K67 1/8W F
3K3 1/8W F
33K 1/8W F
340R 1/8W F
3K57 1/8W F
47K 1/8W F
549R 1/8W F
5K9 1/8W F
6K19 1/8W F
680R 1/8W F
787R 1/8W F
909R 1/8W F
9K31 1/8W F
22
Reference Designator
C32
C108,118,131,140
C81,84
C75-78,82,85
C80,83
C93,94,101,124
C92,102,105,125
C79
Q31
Q20,22
Q21,23
U7,8
D35,43
D42,49
D60
U9,10
Q34,35
Z7,8
D36,39,46,52,61
Q33,40
Q32
PIN2
PIN1
R339
R363,381
R338,342,343,346,348,353,
R356
R362
R347
R354,369
R380
R341
R384
R336
R204
R383
R357,371
R335
R214
R344
R382
R359,374
R360
R350,364
R385
R351
